5962F9563101QXC: DescriptionQUAD LINE RECEIVER, CDFP16, CERAMIC, FP-16; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size51KB，2 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Related ProductsFound6parts with similar functions to 5962F9563101QXC

Download Datasheet Parametric Compare View All

5962F9563101QXC Overview

QUAD LINE RECEIVER, CDFP16, CERAMIC, FP-16

5962F9563101QXC Parametric

Parameter Name	Attribute value
Maker	Renesas Electronics Corporation
Parts packaging code	DFP
package instruction	DFP, FL16,.3
Contacts	16
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	TTL COMPATIBLE INPUTS
Differential output	NO
Input properties	DIFFERENTIAL SCHMITT TRIGGER
Interface integrated circuit type	LINE RECEIVER
Interface standards	GENERAL PURPOSE
JESD-30 code	R-CDFP-F16
JESD-609 code	e4
Number of functions	4
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Maximum output low current	0.006 A
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Encapsulate equivalent code	FL16,.3
Package shape	RECTANGULAR
Package form	FLATPACK
power supply	5 V
Certification status	Not Qualified
Maximum receive delay	40 ns
Number of receiver bits	4
Filter level	MIL-PRF-38535 Class Q
Maximum seat height	2.92 mm
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	GOLD
Terminal form	FLAT
Terminal pitch	1.27 mm
Terminal location	DUAL
total dose	300k Rad(Si) V
width	6.73 mm

Preview

Download Datasheet

View All

HS-26CT32RH

Data Sheet

October 1999

File Number

2930.3

Radiation Hardened Quad Differential Line

Receiver

tle

-

T3

)

-

ia-

d-

d

er-

al

eiv

tho

-

ds

r-

po-

n,

i-

or,

ia-

d-

,

The Intersil HS-26CT32RH is a differential line receiver

designed for digital data transmission over balanced lines

and meets the requirements of EIA standard RS-422.

Radiation hardened CMOS processing assures low power

consumption, high speed, and reliable operation in the most

severe radiation environments.

The HS-26CT32RH has an input sensitivity typically of

200mV over the common mode input voltage range of

±7V.

The receivers are also equipped with input fail safe circuitry,

which causes the outputs to go to a logic “1” when the inputs

are open. Enable and Disable functions are common to all

four receivers.

Specifications for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed here must be used when ordering.

Detailed Electrical Specifications for these devices are

contained in SMD 5962-95631. A “hot-link” is provided

on our homepage for downloading.

http://www.intersil.com/spacedefense/space.htm

Features

• Electrically Screened to SMD # 5962-95631

• QML Qualified per MIL-PRF-38535 Requirements

• 1.2 Micron Radiation Hardened CMOS

- Total Dose . . . . . . . . . . . . . . . . . . . .Up to 300kRAD(Si)

• Latchup Free

• EIA RS-422 Compatible Outputs

• TTL Compatible Inputs

• Input Fail Safe Circuitry

• High Impedance Inputs when Disabled or Powered Down

• Low Power Dissipation Standby (Max). . . . . . . . . .138mW

• Single 5V Supply

• Full Military Temperature Range . . . . . . . -55

o

C to 125

o

C

Pinouts

HS1-26CT32RH (SBDIP) CDIP2-T16

TOP VIEW

AIN 1

16 VDD

15 BIN

14 BIN

13 BOUT

12 ENABLE

11 DOUT

10 DIN

9 DIN

Logic Diagram

ENABLE

ENABLE DIN DIN

CIN CIN

BIN BIN

AIN AIN

AIN 2

AOUT 3

ENABLE 4

COUT 5

+

-

+

-

+

-

+

-

CIN 6

CIN 7

GND 8

DOUT

COUT

BOUT

AOUT

HS9-26CT32RH (FLATPACK) CDFP4-F16

TOP VIEW

Ordering Information

ORDERING NUMBER

5962F9563101QEC

INTERNAL

MKT. NUMBER

HS1-26CT32RH-8

HS9-26CT32RH-8

HS0-26CT32RH-Q

HS1-26CT32RH-Q

HS9-26CT32RH-Q

TEMP.

RANGE (

o

C)

-55 to 125

25

-55 to 125

AIN

AOUT

ENABLE

1

2

3

4

5

6

7

8

16

15

14

13

12

11

10

9

VDD

BIN

BOUT

ENABLE

DOUT

DIN

d,

L,

l-

,

5962F9563101QXC

5962F9563101V9A

5962F9563101VEC

5962F9563101VXC

COUT

CIN

GND

HS1-26CT32RH/PROTO HS1-26CT32RH/PROTO

HS9-26CT32RH/PROTO HS9-26CT32RH/PROTO

1

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

5962F9563101QXC Related Products

	5962F9563101QXC	5962R9563101TXC	5962F9563101VXC	5962F9563101V9A	5962F9563101QEC	5962F9563101VEC
Description	QUAD LINE RECEIVER, CDFP16, CERAMIC, FP-16	QUAD LINE RECEIVER, CDFP16, CERAMIC, DFP-16	QUAD LINE RECEIVER, CDFP16, CERAMIC, FP-16	QUAD LINE RECEIVER, UUC16, DIE-16	QUAD LINE RECEIVER, CDIP16, SIDE BRAZED, CERAMIC, DIP-16	QUAD LINE RECEIVER, CDIP16, SIDE BRAZED, CERAMIC, DIP-16
Parts packaging code	DFP	DFP	DFP	DIE	DIP	DIP
package instruction	DFP, FL16,.3	DFP, FL16,.3	DFP, FL16,.3	DIE, DIE OR CHIP	DIP, DIP16,.3	DIP, DIP16,.3
Contacts	16	16	16	16	16	16
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Input properties	DIFFERENTIAL SCHMITT TRIGGER	DIFFERENTIAL SCHMITT TRIGGER	DIFFERENTIAL SCHMITT TRIGGER	DIFFERENTIAL SCHMITT TRIGGER	DIFFERENTIAL SCHMITT TRIGGER	DIFFERENTIAL SCHMITT TRIGGER
Interface integrated circuit type	LINE RECEIVER	LINE RECEIVER	LINE RECEIVER	LINE RECEIVER	LINE RECEIVER	LINE RECEIVER
Interface standards	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
JESD-30 code	R-CDFP-F16	R-CDFP-F16	R-CDFP-F16	R-XUUC-N16	R-CDIP-T16	R-CDIP-T16
Number of functions	4	4	4	4	4	4
Number of terminals	16	16	16	16	16	16
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Maximum output low current	0.006 A	0.006 A	0.006 A	0.006 A	0.006 A	0.006 A
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	UNSPECIFIED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP	DFP	DFP	DIE	DIP	DIP
Encapsulate equivalent code	FL16,.3	FL16,.3	FL16,.3	DIE OR CHIP	DIP16,.3	DIP16,.3
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLATPACK	FLATPACK	FLATPACK	UNCASED CHIP	IN-LINE	IN-LINE
power supply	5 V	5 V	5 V	5 V	5 V	5 V
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum receive delay	40 ns	40 ns	40 ns	40 ns	40 ns	40 ns
Number of receiver bits	4	4	4	4	4	4
Filter level	MIL-PRF-38535 Class Q	MIL-PRF-38535	MIL-PRF-38535 Class V	MIL-PRF-38535 Class V	MIL-PRF-38535 Class Q	MIL-PRF-38535 Class V
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V	4.5 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES	NO	NO
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY	MILITARY
Terminal form	FLAT	FLAT	FLAT	NO LEAD	THROUGH-HOLE	THROUGH-HOLE
Terminal location	DUAL	DUAL	DUAL	UPPER	DUAL	DUAL
total dose	300k Rad(Si) V	100k Rad(Si) V	300k Rad(Si) V	300k Rad(Si) V	300k Rad(Si) V	300k Rad(Si) V
Maker	Renesas Electronics Corporation	-	Renesas Electronics Corporation	-	Renesas Electronics Corporation	Renesas Electronics Corporation
Other features	TTL COMPATIBLE INPUTS	-	TTL COMPATIBLE INPUTS	TTL COMPATIBLE INPUTS	TTL COMPATIBLE INPUTS	TTL COMPATIBLE INPUTS
Differential output	NO	-	NO	NO	NO	NO
JESD-609 code	e4	e4	e4	-	e4	e4
Maximum seat height	2.92 mm	2.92 mm	2.92 mm	-	5.08 mm	5.08 mm
Terminal surface	GOLD	GOLD	GOLD	-	GOLD	GOLD
Terminal pitch	1.27 mm	1.27 mm	1.27 mm	-	2.54 mm	2.54 mm
width	6.73 mm	6.73 mm	6.73 mm	-	7.62 mm	7.62 mm
