SD104CWS/S5/D6 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> SD104CWS/S5/D6

SD104CWS/S5/D6: DescriptionMixer Diode, Ultra High Frequency, Silicon, MICRO MINIATURE, PLASTIC, SOD-323, 2 PIN; CategoryDiscrete semiconductor diode; File Size81KB，3 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

SD104CWS/S5/D6 Overview

Mixer Diode, Ultra High Frequency, Silicon, MICRO MINIATURE, PLASTIC, SOD-323, 2 PIN

SD104CWS/S5/D6 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Vishay
Parts packaging code	SOD
package instruction	R-PDSO-G2
Contacts	2
Manufacturer packaging code	SOD-323
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	SINGLE
Maximum diode capacitance	1 pF
Diode component materials	SILICON
Diode type	MIXER DIODE
frequency band	ULTRA HIGH FREQUENCY
JESD-30 code	R-PDSO-G2
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	2
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
surface mount	YES
technology	SCHOTTKY
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	40

Preview

Download Datasheet

View All

SD104AWS thru SD104CWS

New Product

Vishay Semiconductors

formerly General Semiconductor

Schottky Diodes

SOD-323

.012 (0.3)

Cathode Band

.112 (2.85)

.100 (2.55)

.076 (1.95)

.065 (1.65)

Top View

Dimensions in inches

and (millimeters)

Mounting Pad Layout

.059 (1.5)

.004 (0.1)

max.

.043 (1.1)

.049 (1.25)

max.

.006 (0.15)

max.

0.055

(1.40)

0.062

(1.60)

0.047 (1.20)

.010 (0.25)

min.

Features

Low turn-on voltage

Low capacitance

Ultrafast switching

Microminiature plastic package

Single, double, and ring balanced mixer in narrow-

band receivers up to 1 GHz.

• Detectors and fast switching up to 1 GHz

• Phase detectors

• Suitable for radios, TV, CTV, and hyper band tuners

•

Mechanical Data

Case:

SOD-323 plastic case

Weight:

approximately 0.004g

Marking

SD104AWS = S3

Code:

SD104BWS = S4

SD104CWS = S5

Packaging Codes/Options:

D5/10K per 13” reel (8mm tape), 30K/box

D6/3K per 7” reel (8mm tape), 30K/box

Maximum Ratings and Thermal Characteristics

Parameter

Continuous Reverse Voltage

Forward Current

Power Dissipation T

= 25°C

Thermal Resistance Junction to Ambient Air

Junction Temperature

Storage Temperature Range

Note:

(1) Valid provided that electrodes are kept at ambient temperature

= 25°C unless otherwise noted)

Symbol

SD104AWS

SD104BWS

SD104CWS

tot

θJA

Value

150

(1)

650

(1)

125

–55 to +150

Unit

°C/W

°C

Document Number 88247

13-May-02

www.vishay.com
