Ordering number : ENA1796
BFL4004
SANYO Semiconductors
DATA SHEET
BFL4004
Features
•
•
•
N-Channel Silicon MOSFET
General-Purpose Switching Device
Applications
ON-resistance RDS(on)=1.9
Ω
(typ.)
Input capacitance Ciss=710pF (typ.)
10V drive
Specifications
Absolute Maximum Ratings
at Ta=25°C
Parameter
Drain-to-Source Voltage
Gate-to-Source Voltage
Drain Current (DC)
Drain Current (Pulse)
Allowable Power Dissipation
Channel Temperature
Storage Temperature
Avalanche Energy (Single Pulse) *4
Avalanche Current *5
Symbol
VDSS
VGSS
IDc*1
IDpack*2
IDP
PD
Tch
Tstg
EAS
IAV
Limited only by maximum temperature Tch=150°C
Tc=25°C (SANYO’s ideal heat dissipation condition)*3
PW≤10μs, duty cycle≤1%
Tc=25°C (SANYO’s ideal heat dissipation condition)*3
Conditions
Ratings
800
±30
6.5
4.3
13
2.0
36
150
--55 to +150
241
6.5
Unit
V
V
A
A
A
W
W
°C
°C
mJ
A
Note :
*1
Shows chip capability
*2
Package limited
*3
SANYO’s condition is radiation from backside.
The method is applying silicone grease to the backside of the device and attaching the device to water-cooled radiator made of aluminium.
*4
VDD=99V, L=10mH, IAV=6.5A (Fig.1)
*5
L
≤
10mH, single pulse
Package Dimensions
unit : mm (typ)
7509-002
10.0
3.2
3.5
7.2
4.5
2.8
Product & Package Information
• Package
: TO-220FI(LS)
• JEITA, JEDEC
: SC-67, SOT-186A, TO-220F
• Minimum Packing Quantity : 100 pcs./bag or 50pcs./magazine
Marking
Electrical Connection
2
16.1
16.0
FL4004
LOT No.
0.9
1.2
0.75
14.0
0.6
3.6
1.2
0.7
1
1 2 3
2.4
1 : Gate
2 : Drain
3 : Source
SANYO : TO-220FI(LS)
3
2.55
2.55
http://semicon.sanyo.com/en/network
70710QB TK IM TC-00002398 No. A1796-1/5
BFL4004
Electrical Characteristics
at Ta=25°C
Parameter
Drain-to-Source Breakdown Voltage
Zero-Gate Voltage Drain Current
Gate-to-Source Leakage Current
Cutoff Voltage
Forward Transfer Admittance
Static Drain-to-Source On-State Resistance
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Turn-ON Delay Time
Rise Time
Turn-OFF Delay Time
Fall Time
Total Gate Charge
Gate-to-Source Charge
Gate-to-Drain “Miller” Charge
Diode Forward Voltage
Reverse Recovery Time
Reverse Recovery Charge
Symbol
V(BR)DSS
IDSS
IGSS
VGS(off)
|
yfs
|
RDS(on)
Ciss
Coss
Crss
td(on)
tr
td(off)
tf
Qg
Qgs
Qgd
VSD
trr
Qrr
Conditions
ID=10mA, VGS=0V
VDS=640V, VGS=0V
VGS=±30V, VDS=0V
VDS=10V, ID=1mA
VDS=20V, ID=3.25A
ID=3.25A, VGS=10V
VDS=30V, f=1MHz
VDS=30V, f=1MHz
VDS=30V, f=1MHz
See Fig.2
See Fig.2
See Fig.2
See Fig.2
VDS=200V, VGS=10V, ID=6.5A
VDS=200V, VGS=10V, ID=6.5A
VDS=200V, VGS=10V, ID=6.5A
IS=6.5A, VGS=0V
See Fig.3
IS=6.5A, VGS=0V, di/dt=100A/μs
2.0
1.7
3.4
1.9
710
120
42
17
44
130
44
36
6.2
18
0.85
780
5400
1.2
2.5
Ratings
min
800
1.0
±100
4.0
typ
max
Unit
V
mA
nA
V
S
Ω
pF
pF
pF
ns
ns
ns
ns
nC
nC
nC
V
ns
nC
Fig.1 Avalanche Resistance Test Circuit
L
≥50Ω
RG
Fig.2 Switching Time Test Circuit
10V
0V
VIN
VDD=200V
ID=3.25A
RL=61Ω
D
VOUT
VIN
BFL4004
PW=10μs
D.C.≤0.5%
G
10V
0V
50Ω
VDD
BFL4004
P.G
RGS=50Ω
S
Fig.3 trr Reverse Recovery Time Test Circuit
D
500μH
S
VDD=50V
BFL4004
G
Driver MOSFET
No. A1796-2/5
