Datasheet> All Categories > Discrete semiconductor> diode> SB220

Preview

SB220: DescriptionRectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 20V V(RRM), Silicon, PLASTIC, DO-15, 2 PIN; CategoryDiscrete semiconductor diode; File Size141KB，3 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric Compare View All

SB220 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SB220	-	-	View	Buy Now

SB220 Overview

Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 20V V(RRM), Silicon, PLASTIC, DO-15, 2 PIN

SB220 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Micro Commercial Components (MCC)
Parts packaging code	DO-15
package instruction	PLASTIC, DO-15, 2 PIN
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	FREE WHEELING DIODE
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	O-PALF-W2
JESD-609 code	e0
Maximum non-repetitive peak forward current	50 A
Number of components	1
Phase	1
Number of terminals	2
Maximum output current	2 A
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	20 V
surface mount	NO
technology	SCHOTTKY
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

MCC

TM

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

SB220

Thru

SB260

2 Amp Schottky

Rectifier

20V-60V

DO-15

Features

Schottky Barrier Rectifier

Guard Ring Protection

High Surge Current Capability

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

For Use in Low Voltage, High Frequency Inverters, Free

Wheeling, and Polarity Protection Applications

Maximum Ratings

Operating Temperature: -65 to +150

Storage Temperature: -65 to +150

Maximum Thermal Resistance: 15

K

/W Junction To Lead

50

K

/W Junction to Ambient*

D

MCC

Part Number

SB220

SB230

SB240

SB250

SB260

Maximum

Recurrent

Peak Reverse

Voltage

20V

30V

40V

50V

60V

Maximum

RMS Voltage

14V

21V

28V

35V

42V

Maximum DC

Blocking

Voltage

20V

30V

40V

50V

60V

A

Cathode

Mark

B

D

Electrical Characteristics @ 25 C Unless Otherwise Specified

Average Rectified

T

L

= 100

2A

I

O

Output current*

Maximum surge

50A

8.3ms, half sine

I

FSM

current

Max peak forward

voltage

.50V

I

FM

= 2.0A

SB220-SB240

V

FM

.70V

SB250-SB260

0.5mA T

A

= 25

Max peak reverse

I

RM

10mA

current

T

A

= 100

Typical junction

capacitance

SB220-SB240

C

J

170pF

V

R

= 4.0V,

SB250-SB260

140pF

f=1.0MHz

*Valid provided that leads are kept at ambient temperature at a

distance of 9l5mm from the case

C

DIMENSIONS

INCHES

MIN

.230

.104

.026

1.000

MM

MIN

5.80

2.60

.70

25.40

DIM

A

B

C

D

MAX

.300

.140

.034

---

MAX

7.60

3.60

.90

---

NOTE

Revision: 2

www.mccsemi.com

1 of 3

2006/05/29

SB220 Related Products

	SB220	SB240	SB230	SB260
Description	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 20V V(RRM), Silicon, PLASTIC, DO-15, 2 PIN	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 40V V(RRM), Silicon, PLASTIC, DO-15, 2 PIN	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 30V V(RRM), Silicon, PLASTIC, DO-15, 2 PIN	Rectifier Diode, Schottky, 1 Phase, 1 Element, 2A, 60V V(RRM), Silicon, PLASTIC, DO-15, 2 PIN
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible
Maker	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)
Parts packaging code	DO-15	DO-15	DO-15	DO-15
package instruction	PLASTIC, DO-15, 2 PIN	PLASTIC, DO-15, 2 PIN	PLASTIC, DO-15, 2 PIN	PLASTIC, DO-15, 2 PIN
Contacts	2	2	2	2
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Other features	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE
application	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell connection	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JESD-30 code	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
JESD-609 code	e0	e0	e0	e0
Maximum non-repetitive peak forward current	50 A	50 A	50 A	50 A
Number of components	1	1	1	1
Phase	1	1	1	1
Number of terminals	2	2	2	2
Maximum output current	2 A	2 A	2 A	2 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	ROUND	ROUND	ROUND	ROUND
Package form	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	20 V	40 V	30 V	60 V
surface mount	NO	NO	NO	NO
technology	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal surface	TIN LEAD	TIN LEAD	TIN LEAD	TIN LEAD
Terminal form	WIRE	WIRE	WIRE	WIRE
Terminal location	AXIAL	AXIAL	AXIAL	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
