Cross Reference Guide
TR9771 / SM9771*
* Part number for additional environmental screening.
Performance Data
Frequency
Gain
Noise Figure
P
1dB
3
rd
Order Intercept
2
nd
Order Intercept
VSWR
Reverse Isolation
Power Supply
Operating Temperature
1200.0 - 1700.0 MHz
27.0 dB Typical
25.0 dB Min
1.0 dB Typical
1.8 dB Max
15.0 dBm Typical
14.0 dBm Min
26.0 dBm Typical
40.0 dBm Typical
1.8/2.0 Input Typ/Max
1.8/2.0 Output Typ/Max
-38.0 dB Typical
-36.0 dB Min
15.0 Volts
60.0 mA
-55.0 - 85.0 °C
Package Drawing
Gain
dB
Frequency (MHz)
Noise Figure
dB
Frequency (MHz)
P
1dB
Compression Point
dBm
Frequency (MHz)
Reverse Isolation
dB
Frequency (MHz)
Input VSWR
Frequency (MHz)
Output VSWR
Frequency (MHz)
S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
1200.0
1300.0
1400.0
1500.0
1600.0
1700.0
0.210
0.150
0.100
0.080
0.100
0.220
57.00
52.00
51.00
36.00
11.00
-28.00
24.560
23.860
22.900
23.130
22.890
22.820
-163.00
171.00
146.00
121.00
93.00
61.00
0.011
0.013
0.017
0.017
0.017
0.015
118.00
96.00
79.00
54.00
32.00
-5.00
0.030
0.030
0.040
0.050
0.060
0.060
-4.00
-37.00
-69.00
-101.00
-128.00
-164.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
13.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
200.0 mW
