AN6650G-S08-R datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Other integrated circuit (IC)> The signal circuit> AN6650G-S08-R

AN6650G-S08-R: DescriptionMOTOR SPEED CONTROL CIRCUIT; CategoryOther integrated circuit (IC) The signal circuit; File Size141KB，6 Pages; ManufacturerUNISONIC TECHNOLOGIES CO.,LTD; Websitehttp://www.unisonic.com.tw/; Environmental Compliance

Download Datasheet Parametric Compare View All

AN6650G-S08-R Overview

MOTOR SPEED CONTROL CIRCUIT

AN6650G-S08-R Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	UNISONIC TECHNOLOGIES CO.,LTD
Parts packaging code	SOIC
package instruction	HALOGEN FREE, SOP-8
Contacts	8
Reach Compliance Code	compli
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DISK DRIVE MOTOR CONTROLLER
JESD-30 code	R-PDSO-G8
length	4.92 mm
Number of functions	1
Number of terminals	8
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	1.96 mm
Maximum supply voltage (Vsup)	7 V
Minimum supply voltage (Vsup)	1.8 V
Nominal supply voltage (Vsup)	6 V
surface mount	YES
Temperature level	COMMERCIAL
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.95 mm

Preview

Download Datasheet

View All

UNISONIC TECHNOLOGIES CO.,

AN6650

MOTOR SPEED CONTROL

CIRCUIT

DESCRIPTION

The UTC

AN6650

is a monolithic integrated circuit, designed for the

tape recorder.

LINEAR INTEGRATED CIRCUIT

FEATURES

*Wide Operating Supply Voltage: V

=1.8V-7V

*Few External Components

*Easy Speed Control Mode

ORDERING INFORMATION

Normal

AN6650-S08-R

AN6650-D08-T

Ordering Number

Lead Free

AN6650L-S08-R

AN6650L-D08-T

Halogen Free

AN6650G-S08-R

AN6650G-D08-T

Package

SOP-8

DIP-8

Packing

Tape Reel

Tube

www.unisonic.com.tw

QW-R109-002.D

AN6650G-S08-R Related Products

	AN6650G-S08-R	AN6650-D08-T	AN6650L-S08-R	AN6650-S08-R	AN6650
Description	MOTOR SPEED CONTROL CIRCUIT	MOTOR SPEED CONTROL CIRCUIT	MOTOR SPEED CONTROL CIRCUIT	MOTOR SPEED CONTROL CIRCUIT	MOTOR SPEED CONTROL CIRCUIT
Maker	UNISONIC TECHNOLOGIES CO.,LTD	UNISONIC TECHNOLOGIES CO.,LTD	UNISONIC TECHNOLOGIES CO.,LTD	UNISONIC TECHNOLOGIES CO.,LTD	-
Parts packaging code	SOIC	DIP	SOIC	SOIC	-
package instruction	HALOGEN FREE, SOP-8	DIP,	LEAD FREE, SOP-8	SOP,	-
Contacts	8	8	8	8	-
Reach Compliance Code	compli	compli	compli	compli	-
ECCN code	EAR99	EAR99	EAR99	EAR99	-
Analog Integrated Circuits - Other Types	DISK DRIVE MOTOR CONTROLLER	DISK DRIVE MOTOR CONTROLLER	DISK DRIVE MOTOR CONTROLLER	DISK DRIVE MOTOR CONTROLLER	-
JESD-30 code	R-PDSO-G8	R-XDIP-T8	R-PDSO-G8	R-PDSO-G8	-
length	4.92 mm	9.2 mm	4.92 mm	4.92 mm	-
Number of functions	1	1	1	1	-
Number of terminals	8	8	8	8	-
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	-
Package body material	PLASTIC/EPOXY	UNSPECIFIED	PLASTIC/EPOXY	PLASTIC/EPOXY	-
encapsulated code	SOP	DIP	SOP	SOP	-
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	-
Package form	SMALL OUTLINE	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	-
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-
Maximum seat height	1.96 mm	4.31 mm	1.96 mm	1.96 mm	-
Maximum supply voltage (Vsup)	7 V	7 V	7 V	7 V	-
Minimum supply voltage (Vsup)	1.8 V	1.8 V	1.8 V	1.8 V	-
Nominal supply voltage (Vsup)	6 V	6 V	6 V	6 V	-
surface mount	YES	NO	YES	YES	-
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	-
Terminal form	GULL WING	THROUGH-HOLE	GULL WING	GULL WING	-
Terminal pitch	1.27 mm	2.54 mm	1.27 mm	1.27 mm	-
Terminal location	DUAL	DUAL	DUAL	DUAL	-
width	3.95 mm	7.62 mm	3.95 mm	3.95 mm	-
