BZY93C68R datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BZY93C68R

BZY93C68R: DescriptionZener Diode, 68V V(Z), 20W, Silicon, Unidirectional, DO-4; CategoryDiscrete semiconductor diode; File Size60KB，2 Pages; ManufacturerCrydom; Websitehttp://www.crydom.com/en/index.shtml

Download Datasheet Parametric View All

BZY93C68R Overview

Zener Diode, 68V V(Z), 20W, Silicon, Unidirectional, DO-4

BZY93C68R Parametric

Parameter Name	Attribute value
Maker	Crydom
package instruction	O-MUPM-D1
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	ANODE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	11 Ω
JEDEC-95 code	DO-4
JESD-30 code	O-MUPM-D1
Number of components	1
Number of terminals	1
Maximum operating temperature	175 °C
Package body material	METAL
Package shape	ROUND
Package form	POST/STUD MOUNT
polarity	UNIDIRECTIONAL
Maximum power dissipation	20 W
Certification status	Not Qualified
Nominal reference voltage	68 V
surface mount	NO
technology	ZENER
Terminal form	SOLDER LUG
Terminal location	UPPER
Working test current	200 mA

Preview

Download Datasheet

View All

Zeners/Studs

BZY93

Series

Quality, Affordable Voltage Regulation

Whether you need stable, steady state

voltage regulation for a new design, or in

support of an existing product, you can

rely on Crydom Zeners/Studs for high

quality and performance, short delivery

times, and competitive pricing.

MAXIMUM RATINGS

FEATURES

• Glass passivated junction

• 1500 watt surge capability at 1 ms

• Typically IR less than 5 µA above 10 V

• Excellent clamping capability

• Stud cathode and stud anode

• 100% tested

• Operating temperature: -55°C to +175°C

• Voltage range: 7.5-75 V

• 1500 watt peak pulse power

• 20 watt steady state @ 75°C

• 15 watt steady state @ 100°C

PART

NUMBER

ZENER VOLTAGE

(V) @ I

TYP.

MAX.

ZENER RESISTANCE

(Ω) @ I

TYP.

MAX.

MAXIMUM REVERSE

LEAKAGE I

@ V

(mA)

(V)

(A)

BZY93C7V5

BZY93C8V2

BZY93C9V1

BZY93C10

BZY93C11

BZY93C12

BZY93C13

BZY93C15

BZY93C16

BZY93C18

BZY93C20

BZY93C22

BZY93C24

BZY93C27

BZY93C30

BZY93C33

BZY93C36

BZY93C39

BZY93C43

BZY93C47

BZY93C51

BZY93C56

BZY93C62

BZY93C68

BZY93C75

7.0

7.7

8.5

9.4

10.4

11.4

12.4

13.8

15.3

16.8

18.8

20.8

22.7

25.1

28.0

31.0

34.0

37.0

40.0

44.0

48.0

52.0

58.0

64.0

70.0

7.9

8.7

9.6

10.6

11.6

12.7

14.1

15.6

17.1

19.1

21.2

23.3

25.9

28.9

32.0

35.0

38.0

41.0

46.0

50.0

54.0

60.0

66.0

72.0

79.0

2.0

1.0

0.5

0.2

0.04

0.05

0.07

0.09

0.08

0.10

0.18

0.20

0.21

0.22

0.25

0.30

0.75

0.85

0.90

1.0

1.2

1.3

1.5

1.8

2.0

0.3

0.5

1.0

1.2

1.5

1.8

2.0

2.5

4.0

5.0

6.5

7.0

7.5

8.0

9.0

10.0

11.0

15.0

0.1

0.05

5.1

5.6

6.2

6.8

7.5

8.2

9.1

10.0

11.0

12.0

13.0

15.0

16.0

18.0

20.0

22.0

24.0

27.0

30.0

33.0

36.0

39.0

43.0

47.0

51.0

Note: Suffix “R” denotes stud anode reverse. Electrical specification @ 25°C.
