KBPC2505N THRU KBPC2510N

Preview

Download Datasheet

View All

MASTER INSTRUMENT CORPORATION

KBPC2505N THRU KBPC2510N

FEATURES

Low cost

This series is UL recognized under component

index, file number E127707

High forward surge current capability

Integrally molded heatsink provide very low thermal resistance

High isolation voltage from case to lugs

High temperature soldering guaranteed:

260

C/10 second, at 5 lbs. (2.3kg) tension.

MECHANICAL DATA

Case: Molded plastic body

Terminal: Lead solderable per MIL-STD-202E

method 208C.

Polarity: Polarity symbols molded on case

Mounting: Thru hole for #6 screw, 5.0 in.-lbs torque max.

Weight:0.55ounce, 15.6 grams

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

C ambient temperature unless otherwise specified.

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load derate current by 20%.

SYMBOLS

VOLTAGE RANGE

CURRENT

50 to 1000 Volts

25 Amperes

1.13( 28.8)

1.11( 28.2)

0.666( 16.9)

0.626( 15.9)

BR-35N

1.13( 28.8)

1.11( 28.2)

0.728( 18.5)

0.688( 17.5)

0.666( 16.9)

0.626( 15.9)

0.570( 14.5)

0.530( 13.5)

0.205( 5.2)

0.197( 5.0)

DIA

METAL HEAT SINK

EXOPY CASE

0.32( 8.2)

0.30( 7.8)

0.0

) D

2.3

0.512( 13.0)

0.413( 10.5)

0.033( 0.84)

0.028( 0.71)

0.252( 6.4)

0.248( 6.3)

0.252( 6.4)

0.248( 6.3)

Dimensions in inches and (millimeters)

KBPC

25005N

KBPC

2501N

KBPC

2502N

KBPC

2504N

KBPC

2506N

KBPC

2508N

KBPC

2510N

UNITS

Volts

Amps

Volts

µAmps

mAmps

℃/W

℃

Maximum Repetitive Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward

Rectified Output Current, at T

=50℃(Note1, 2)

Peak Forward Surge Current 8.3ms single half sine-wave

superimposed on rated load (JEDEC Method)

Rating for Fusing(t<8.3ms)

Maximum Instantaneous Forward Voltage at 12.5A

Maximum DC Reverse Current at rated T

=25℃

DC blocking voltage

=150℃

Isolation Voltage from case to leads

Typical Thermal Resistance (Note 1, 2)

Operating Temperature Range

Storage Temperature Range

RRM

RMS

(AV)

FSM

ISO

θJC

STG

100

200

140

200

400

280

400

300

373

1.1

1.0

2500

2.0

-55 to +150

600

420

600

800

560

800

1000

700

1000

NOTES:

Unit mounted on 5”×6”×4.9” thick (12.8mm×15.2mm×12.4mm) Al. plate.

Bolt down on heat-sink with silicone thermal compound between bridge and mounting surface for maximum heat transfer efficiency with #10 screw.

Web Site:

WWW.PS-PFS.COM
