S/FTP-Kabel / S/FTP cable

b

Kennzeichnung/marking:

Cat.7 S/FTP 4x2xAWG27/7 PVC LI02YSCY PIMF IEC 60332-1 -40°C ~ +75°C

(sequential length in metres)

Kabelmantel / cable jacket: PVC grün / green RAL 6018

a

angespritzte Tülle / moulded strain relief: PVC grün / green RAL 6018

vollgeschirmter Stecker A

fully screened plug A

12,4

24

Rasthebelschutz

latch protection

AWM STYLE 20276 30V 75°C E81280

vollgeschirmter Stecker B

fully screened plug B

49

8,35

Ansicht / view

ohne IP67 Stecker

without IP67 plug

13,2

22

13,5

L 50

1

7

Stecker A

plug A

Paar 2

pair 2

Schaltbild / Connection Diagram 1:1

W-O 1

O

2

W-G 3

BL

4

W-BL 5

1 W-O

2 O

3 W-G

4 BL

Stecker B

plug B

Paar 2

pair 2

SW20

Paar 3

pair 3

Paar 1

pair 1

Norm / Specification

DIN EN 60603-7-5

IEC 61076-3-106

IEC 61935-2 / Edition 2

Paar 4

pair 4

6

W-BR 7

BR

8

S

Schirm / screen

G

5 W-BL

6 G

Paar 1

pair 1

Paar 3

pair 3

7 W-BR Paar 4

BR

pair 4

8

S

Geprüft mit Fluke DSP 4300, DTX 1800, Software CLC-C6 und Patch Cord Interface

Tested with Fluke DSP 4300, DTX 1800, software CLC-C6 and patch cord interface

2006

Gez.

Gepr.

Norm

Maßstab

Benennung

Tag

Name

Werkstoff

20.03.

21.03.06

BM

HI

Oberfläche

1:1

b

a

Änd.-

Zust.

Modular Patch Cable S/FTP Cat.7

PVC RJ45/IP20- RJ45/IP67

18387

18101

Änderungs-

Mitteilung

12.12.06 BM

05.09.06 BM

Tag

Name

Maße ohne Unterl.-

Art

Toleranz-

ang. nach

K

Zeichn.-

Nr.

L00000A0147

Telegärtner

Original : DIN A4

Blatt 1 von 2

Ersatz für

47,3

8,7

8
