Technical Data Sheet - Preliminary
Full Color Top View LEDs
67-03/BHGHR6W-B11/2T/MS
Features
․P-LCC-4
package.
․White
package and black surface.
․Optical
indicator.
․Ideal
for backlight and light pipe application.
․Inter
reflector.
․Wide
viewing angle.
․Suitable
for vapor-phase reflow, Infrared reflow and
wave solder processes.
․Available
on tape and reel (8mm Tape).
․Pb-free.
․The
product itself will remain with RoHS
compliant version
Descriptions
․The
67-03 series is available in soft orange, green, blue and yellow. Due to the package design,
the LED has wide viewing angle and optimized light coupling by inter reflector. This feature
makes the LED ideal for light pipe application. The low current requirement makes this
device ideal for portable equipment or any other application where power is at a premium.
Applications
․Telecommunication:
indicator and backlighting in telephone and fax.
․Flat
backlight for LCD’s, switches and symbols.
․Light
pipe application.
․General
use.
Device Selection Guide
Chip
Emitted Color
Type
R6
GH
BH
Material
AlGaInP
InGaN
InGaN
Brilliant Red
Brilliant Green
Blue
White Diffuse
Resin Color
Everlight Electronics Co., Ltd.
Device No. DSE-0000547
http://www.everlight.com
Prepared date: 15-Dec-2008
Rev. 1
Page: 1 of 14
Prepared by: Josh Chou
Revision
:1
Release Date:2008-12-17 10:03:15.0
Expired Period: Forever
LifecyclePhase:
Technical Data Sheet - Preliminary
Full Color Top View LEDs
67-03/BHGHR6W-B11/2T/MS
Package Outline Dimensions
C
L
3
0.7±0.1
2.2±0.1
2.8±0.2
3
C
L
4
1
3.2±0.2
3.5±0.2
0.5±0.1
2
2
4
1
2.8±0.2
2.4±0.1
0.15±0.05
0.8±0.1
1.9±0.2
2.7±0.2
Recommended soldering pad design
0.8±0.1
1.8
1.6
1.8
Notes:
1. All dimensions are in millimeters
2. Tolerance unless mentioned is ±0.1mm
Everlight Electronics Co., Ltd.
Device No. DSE-0000547
http://www.everlight.com
Prepared date: 15-Dec-2008
0.7
Rev. 1
Page: 2 of 14
Prepared by: Josh Chou
Revision
:1
Release Date:2008-12-17 10:03:15.0
Expired Period: Forever
LifecyclePhase:
2.2
Technical Data Sheet - Preliminary
Full Color Top View LEDs
67-03/BHGHR6W-B11/2T/MS
Absolute Maximum Ratings (Ta=25
℃
)
Parameter
Reverse Voltage
Symbol
V
R
R6
Forward Current
I
F
GH
BH
R6
Peak Forward Current (Duty 1/10 @ 1KHz)
I
FP
GH
BH
R6
Power Dissipation
Pd
GH
BH
R6
Electrostatic Discharge(HBM)
ESD
Topr
Tstg
GH
BH
Operating Temperature
Storage Temperature
Rating
5
50
25
25
100
100
100
120
95
95
2000
2000
2000
℃
℃
V
mW
mA
mA
Unit
V
-40 ~ +85
-40~ +90
Soldering Temperature
Tsol
Reflow Soldering : 260
℃
for 10 sec.
Hand Soldering : 350
℃
for 3 sec.
Everlight Electronics Co., Ltd.
Device No. DSE-0000547
http://www.everlight.com
Prepared date: 15-Dec-2008
Rev. 1
Page: 3 of 14
Prepared by: Josh Chou
Revision
:1
Release Date:2008-12-17 10:03:15.0
Expired Period: Forever
LifecyclePhase:
Technical Data Sheet - Preliminary
Full Color Top View LEDs
67-03/BHGHR6W-B11/2T/MS
Electro-Optical Characteristics (Ta=25
℃
)
Parameter
Symbol
R6
Luminous Intensity
I
V
GH
BH
R6
Peak Wavelength
λp
GH
BH
R6
Dominant Wavelength
λd
GH
BH
Spectrum Radiation
Bandwidth
R6
△
λ
GH
BH
R6
Forward Voltage
V
F
GH
BH
Viewing Angle
2θ1/2
R6
Reverse Current
I
R
GH
BH
Min.
210
575
210
-----
-----
-----
618
524
466.5
-----
-----
-----
1.75
2.9
2.9
-----
-----
-----
-----
Typ.
-----
-----
-----
632
518
468
-----
-----
-----
20
35
35
-----
-----
-----
120
-----
-----
-----
Max.
300
825
300
-----
-----
-----
627
531.5
474
-----
-----
-----
2.35
3.5
3.5
-----
10
50
50
μA
V
R
=5V
deg
I
F
=20mA
V
I
F
=20mA
nm
I
F
=20mA
nm
I
F
=20mA
nm
I
F
=20mA
mcd
I
F
=20mA
Unit
Condition
Note:
1. Tolerance of Luminous Intensity:
±10%
2. Tolerance of Dominant Wavelength:
±1nm
3. Tolerance of Forward Voltage:
±0.1V
Everlight Electronics Co., Ltd.
Device No. DSE-0000547
http://www.everlight.com
Prepared date: 15-Dec-2008
Rev. 1
Page: 4 of 14
Prepared by: Josh Chou
Revision
:1
Release Date:2008-12-17 10:03:15.0
Expired Period: Forever
LifecyclePhase:
Technical Data Sheet - Preliminary
Full Color Top View LEDs
67-03/BHGHR6W-B11/2T/MS
Bin Range of Luminous Intensity
Symbol
Bin Code
5a
R6
5b
6a
6b
10b
Iv
GH
11a
11b
12a
5a
BH
5b
6a
6b
Note:
1. Tolerance of Luminous Intensity:
±10%
Min.
210
230
252
275
575
630
690
756
210
230
252
275
Max.
230
252
275
300
630
690
756
825
230
252
275
300
mcd
I
F
=20mA
Unit
Condition
Everlight Electronics Co., Ltd.
Device No. DSE-0000547
http://www.everlight.com
Prepared date: 15-Dec-2008
Rev. 1
Page: 5 of 14
Prepared by: Josh Chou
Revision
:1
Release Date:2008-12-17 10:03:15.0
Expired Period: Forever
LifecyclePhase:
