LS3550B
MONOLITHIC DUAL
PNP TRANSISTOR
Linear Systems Monolithic Dual PNP Transistor
The LS3550B is a monolithic pair of PNP transistors
mounted in a single P-DIP package. The monolithic
dual chip design reduces parasitics and gives better
performance while ensuring extremely tight matching.
The 8 Pin P-DIP provides ease of manufacturing, and
the symmetrical pinout prevents improper orientation.
(See Packaging Information).
LS3550B Features:
Tight matching
Low Output Capacitance
FEATURES
EXCELLENT THERMAL TRACKING
TIGHT V
BE
MATCHING
ABSOLUTE MAXIMUM RATINGS
1
@ 25°C (unless otherwise noted)
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
Maximum Power Dissipation
Continuous Power Dissipation
Maximum Currents
Collector Current
Maximum Voltages
Collector to Collector Voltage
MIN
‐‐
‐‐
‐‐
‐‐
‐‐
TYP
‐‐
‐‐
‐‐
‐‐
‐‐
MAX
5
5
10
0.5
10
UNITS
mV
µV/°C
nA
nA/°C
%
≤5µV/°C
|V
BE1
– V
BE2
|≤5mV
‐65°C to +150°C
‐55°C to +150°C
TBD
10mA
80V
CONDITIONS
I
C
= ‐10mA, V
CE
= ‐5V
I
C
= ‐10mA, V
CE
= ‐5V
T
A
= ‐40°C to +85°C
I
C
= ‐10µA, V
CE
= ‐5V
I
C
= ‐10µA, V
CE
= ‐5V
T
A
= ‐40°C to +85°C
I
C
= 10µA, V
CE
= 5V
MATCHING CHARACTERISTICS @ 25°C (unless otherwise stated)
SYMBOL
CHARACTERISTIC
|V
BE1
– V
BE2
|
Base Emitter Voltage Differential
∆|(V
BE1
– V
BE2
)| / ∆T
Base Emitter Voltage Differential
Change with Temperature
|I
B1
– I
B2
|
Base Current Differential
|∆ (I
B1
– I
B2
)|/∆T
Base Current Differential
Change with Temperature
h
FE1
/h
FE2
DC Current Gain Differential
ELECTRICAL CHARACTERISTICS @ 25°C (unless otherwise noted)
SYMBOL
CHARACTERISTICS
MIN.
BV
CBO
Collector to Base Voltage
‐40
BV
CEO
Collector to Emitter Voltage
‐40
BV
EBO
Emitter‐Base Breakdown Voltage
‐6.2
BV
CCO
Collector to Collector Voltage
‐80
100
DC Current Gain
h
FE
80
80
V
CE
(SAT)
Collector Saturation Voltage
‐‐
I
EBO
Emitter Cutoff Current
‐‐
I
CBO
Collector Cutoff Current
‐‐
C
OBO
Output Capacitance
‐‐
C
C1C2
Collector to Collector Capacitance
‐‐
I
C1C2
Collector to Collector Leakage Current
‐‐
f
T
Current Gain Bandwidth
‐‐
Product(Current)
NF
Narrow Band Noise Figure
‐‐
Click To Buy
TYP.
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
MAX.
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐‐
‐0.25
‐0.2
‐0.2
2
2
‐1
600
3
UNITS
V
V
V
V
V
nA
nA
pF
pF
nA
MHz
dB
CONDITIONS
I
C
= 10µA, I
E
= 0
I
C
= 10µA, I
B
= 0
I
E
= 10µA, I
C
= 0
2
I
C
= 10µA, I
E
= 0
I
C
= ‐1mA, V
CE
= ‐5V
I
C
= ‐10mA, V
CE
= ‐5V
I
C
= ‐100mA, V
CE
= ‐5V
I
C
= ‐100mA, I
B
= ‐10mA
I
E
= 0, V
CB
= ‐3V
I
E
= 0, V
CB
= ‐30V
I
E
= 0, V
CB
= ‐10V
V
CC
= 0V
V
CC
= ±80V
I
C
= ‐1mA, V
CE
= ‐5V
I
C
= ‐100µA, V
CE
= ‐5V, BW=200Hz, R
G
= 10Ω,
f = 1KHz
Notes:
1. Absolute Maximum ratings are limiting values above which serviceability may be impaired
2. The reverse base‐to‐emitter voltage must never exceed 6.2 volts; the reverse base‐to‐emitter current must never exceed 10µA.
P-DIP (Top View)
Available Packages:
LS3550B in P-DIP
LS3550B available as bare die
Please contact Micross for full package and die dimensions:
Email:
chipcomponents@micross.com
Web:
www.micross.com/distribution.aspx
