Pushbutton Switches
Anti-Vandal Pushbutton Switch - Mounting Hole Ø22mm
8 M a x.
18
M22x1
PAV22 Series
9
1.8
L
L=35.8 (Momentary)
L=40.8 (Latching)
2 8 .5
Top View
6
Bottom View
PAV22S...1...
Dot illuminated; 1NO1NC
8 Ma x.
18
13.5
M22x1
1.8
L
L=35.8 (Momentary)
L=40.8 (Latching)
2 8.5
Top View
6
Bottom View
PAV22S...2...
Ring illuminated; 1NO1NC
LAMP RATINGS
Lamp Type
AC/DC6V
Rated Voltage
Rated Amper
LED Colors
Life
AC/DC24V
about 15mA
red, green, yellow, orange, blue, white
40,000 hours (reference)
LED Lamp AC/DC *
AC/DC12V
AC/DC36V
AC/DC110V
AC/DC220V
about 5mA
R
a
b
Lamp
Using AC/DC LED lamp, the terminals have not
Circuit
difference of anode and cathode;
Diagram
Using inner resistance, don’t need to connect
outer resistance.
(PAV16 Series have no inner resistance).
* DC LED and other voltages can be made by request.
SWITCHING
DIAGRAM OF TERMINATION
NO 1
NC 1
1
3
2
4
LED PIN
NC 1
NO 1
The second and third switch
unit are the same.
LED PIN
How to order:
1
2
3
4
5
6
7
Specifications:
CHARACTERISTICS
> Protection Degree: IP65 (for surface of the panel)
> Anti Vandal Degree: IK10
> Front Shape: Flat round
> Switch Rating: 5A 250VAC Max.
> Contact Resistance: 50m Max.
> Insulation Resistance: 1000M Min.
> Dielectric Intensity: 2000VAC
> Operating Temperature: -20°C to +55°C
> Mechanical Life: 1,000,000 cycles
> Electrical Life: 50,000 cycles
> Panel Thickness: 1 to 8 mm
> Torque: 5 to 14 Nm
> Operation Pressure: about 5.5 N
> Operation Distance: about 2.5mm
MATERIAL
> Contact: Silver alloy
> Button: Stainless steel
> Body: Stainless steel
> Base: PA
PAV22
1
CONTACT:
1NO1NC
6
LED VOLTAGE:
No Illumination
AC/DC 6V
AC/DC 12V
AC/DC 24V
AC/DC 110V
AC/DC 220V
(Other Voltage can be made by request)
S
2
OPERATING MODE:
M
Momentary
L
Latching
3
0
6
12
24
110
220
7
TERMINATION:
Solder Lug 2.8x0.5mm
S
4
ENGRAVING:
B
C
D
ILLUMINATION:
No Illumination
Dot Type Illumination
Ring Type Illumination
A
0
1
2
5
E
F
G
H
LED COLOR:
No Illumination
Red
F
Green
Orange
G
Blue
E
Yellow
B
White
J
K
L
M
N
C
D
N
(Other engraving can
be made by request)
