www.make-ps.com
E-mail:info@make-ps.com
3000LP series
F
EATURES
•
•
•
•
•
•
•
Single, Dual, Triple Output
DC/DC Converter
6 sided Continuous Shielding
Synchronization and Output Trim
Wide 2:1 Input Voltage Range
Efficiency to 82%
UL 1950 Approved
CSA 22.9-950 Approved
VDE / EN 60950 Approved
,
•
>600 000 Hours MTBF
D
ESCRIPTIONS
The 3000LP series is a family of compact 25W to 30W, high
performance DC/DC converters. These converters are
specifically designed to provide the flexibility, power density,
and reliability required to fulfill local power needs in
applications ranging from telecom switch systems to
portable instrumentation. 24 models operate over 2:1 input
ranges of 9 to 18, 18 to 36 or 36 to 72 VDC; providing single,
dual or triple output combinations of 5, 12, 15, ±5, ±12, ±15,
5±12 and 5±15 VDC. All models are packaged in compact,
low profile 3.0” X 2.56” X 0.4” metal cases.
I
NPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
Input Voltage Range
12 VDC Input Models
9
12
24 VDC Input Models
18 24
48 VDC Input Models
36 48
Over Voltage Shutdown
12 VDC Input Models
20
24 VDC Input Models
40
48 VDC Input Models
74
Remote ON / OFF Control
Supply ON
Supply OFF
Logic Referenced to Negative Input
Reverse Polarity Input Current
Input Filter
Input Fuse Rating
18
36
72
VDC
VDC
VDC
VDC
VDC
VDC
5.5 VDC or Open Circuit
0 VDC to 0.8 VDC
12
Amp
Pi Filter
See Model Selection
Guide
O
UTPUT
C
HARACTERISTICS
Min Typ Max Unit/Comments
Output Voltage Accuracy
Single & Dual Outputs
Triple Outputs - Primary
- Auxiliaries
Output Voltage Adjustment
Voltage Balance:
Dual Outputs
Triple Outputs (Auxiliaries)
Minimum Load
Line Regulation
Single Outputs
Dual Outputs
Triple Outputs - Primary
- Auxiliaries
Load Regulation
Single Outputs
Dual Outputs
Triple Outputs - Primary
- Auxiliaries
Ripple/Noise
5V Outputs
12V and 15V Outputs
Short Circuit Protection
Transient Recovery Time
Temperature Coefficient
Over Voltage Protection
±1.0
±1.0
±5.0
±5.0
%
1
%
1
%
1
%
1
; G Case Only
±2.0 %; Equal Output Loads
±100 mV; Equal Output Loads
10% Full Load
±0.5
±1.0
±0.2
±5.0
±0.5
±1.0
±1.0
±2.0
%
2
%
2
%
2
%
2
%
3
%
3
; Equal Loads
%
3
%
3
; Equal Loads
G
ENERAL
C
HARACTERISTICS
Min Typ Max Unit/Comments
Switching Frequency
kHz
100
Isolation Voltage
VDC, 1 minute
1000
Isolation Resistance
Mohm, 500VDC
1000
Isolation Capacitance
pF, 100kHz, 1Volt
190
MTBF (MIL-HBK-217F)
Single and Dual Outputs 685
Thousand Hours,
+25
o
C, Ground
Benign
Triple Outputs
Thousand Hours,
570
+25
o
C, Ground
Benign
75 mV; p-p, Nom.Line FL,
20Mhz B.W. using
1
μf
bypass capacitor
1 % of Vout
Continuous, Auto-
matic Recovery
100
μS
to within1% error
band for 50% step
load change
±0.01 % per
o
C
See Model Selection Guide
1
2
3
= Output voltage at nominal line & FL
= % Output voltage measured from min. input line to maximum
= Output voltage measured from FL to 10% Load
>> B-200
www.make-ps.com
E
NVIRONMENTAL
S
PECIFICATIONS
Operating Temp. Range
Thermal Shutdown
Protection
Storage Temp. Range
Relative Humidity
Cooling
Min
-40
-40
Typ Max Unit/Comments
+75
o
C; Ambient
o
C; Case Temp.
+95
+125
o
C
95 % Humidity; non-
condensing
Free-Air Convection
E-mail:info@make-ps.com
P
HYSICAL
C
HARACTERISTICS
Case Size
Case Material
Shield Connection
12V and 24V Input Models
48V Input Models
Flammability
Weight
Unit/Comments
2.56 X 3.0 X 0.4 inches
(65.0 X 76.2 X 10.2 mm)
Coated Metal with Non-
Conductive Base
Negative Input
Positive Input
UL94V-0
142 Grams
O
UTLINE
D
RAWING
C
ASE
G
2.56 (65.0)
0.40 0.40 0.40 0.50 0.30 0.30
(10.2) (10.2) (10.2) (12.7) (7.6) (7.6)
0.20
(5.1)
0.040±.005
(1.01)
DIA.
P
IN
O
UT
C
HART
; C
ASE
G
Single
Triple
Dual
Pin
Remote On/Off Remote On/Off Remote On/Off
1
+ Vin
+ Vin
+ Vin
2
- Vin
- Vin
- Vin
3
Sync
Sync
Sync
4
+ Vout (Aux)
+ Vout
5 +Sense/Trim(Down)*
Output Trim
Common(Aux)
Common
6
- Vout
- Vout
7 - Sense/Trim (Up)*
+ Vout*
+ Vout (Primary)
Output Trim
8
- Vout*
- Vout (Primary)
No Pin
9
No Pin
Output Trim (Primary)
No Pin
10
* Connections for single output models without sensing or external trimming:
For proper operation, externally connect Pin 5 (+Sense) to Pin 8 (+Vout)
and Pin 7 (-Sense) to Pin 9 (-Vout)
0.40
(10.2)
10
9
8
1.00
(25.4)
7
6
5
BOTTOM
3.00
(76.2)
1.25
(31.75)
2
1
0.30
(7.6)
0.02 MIN.
(0.5)
SIDE
See Note 2
0.72
(18.3)
4
3
0.70
(17.8)
0.40 0.40 0.60
(10.2) (10.2) (15.2)
C
ASE
G-1
0.48 0.40 0.40 0.40 0.40 0.48
(12.2) (10.2) (10.2) (10.2) (10.2) (12.2)
0.25
(6.35)
P
IN
O
UT
C
HART
; C
ASE
G-1
0.25
(6.4)
6
7
8
9
10
1.25
(31.75)
3.00
(76.2)
1.25
(31.75)
1
0.040±.005
(1.01)
DIA.
0.02 MIN.
(0.5)
0.40
(10.2)
0.50 0.50
(12.7) (12.7)
See
Note 2
5
SIDE
BOTTOM
4
3
2
Pin
1
2
3
4
5
6
7
8
9
10
Single
Triple
Dual
Remote On/Off Remote On/Off Remote On/Off
No Pin
No Pin
No Pin
Input*
Input*
Input*
Input*
Input*
Input*
NC
NC
NC
NC
- Vout (Aux)
- Vout
NC
+ Vout (Aux)
Output Common
- Vout
Output Common Output Common
+ Vout
+ Output (Primary)
+ Vout
Output Trim
Output Trim (Primary)
Output Trim
* For 12V and 24V input models, Pin 3 is Minus (-) and Pin 4 is Plus (+). For
48V models, Pin 3 is (+) and Pin 4 is Minus (-).
2.56 (65.0)
Notes:
1. Unless otherwise specified dimensions are in inches (mm).
Tolerances
Inches
mm
X.XX = ±0.02
X.X = ±0.5
X.XXX= ±0.010
X.XX = ±0.25
2. Mounting inserts: 4-40 X .10 (2.5) Deep
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across output is recommended for operation.
>> B-201
