UNSHIELDED SMD POWER INDUCTOR
AISC-1210H
FEATURES:
• Low DC resistance permits high curent flow
• Suitable for flow and reflow soldering
• Exhibit low voltage drops and inductance variations with respect to
temperature rise and DC current level
Pb
RoHS
Compliant
APPLICATIONS:
3.2 x 2.5 x 2.0mm
| | | | | | | | | | | | | | |
• Excellent for power line DC/DC conversion applications
• Used in video, communications, notebook computer
and other electronic equipment
STANDARD SPECIFICATIONS:
PARAMETERS
ABRACON P/N:
Operating temperature:
Storage temperature:
Part Number
AISC-1210H-R15X
AISC-1210H-R27X
AISC-1210H-R39X
AISC-1210H-R56X
AISC-1210H-R82X
AISC-1210H-1R0X
AISC-1210H-1R2X
AISC-1210H-1R5X
AISC-1210H-1R8X
AISC-1210H-2R2X
AISC-1210H-2R4X
AISC-1210H-2R7X
AISC-1210H-3R3X
AISC-1210H-3R9X
AISC-1210H-4R7X
AISC-1210H-5R6X
AISC-1210H-6R8X
AISC-1210H-8R2X
AISC-1210H-100X
AISC-1210H-120X
AISC-1210H-150X
AISC-1210H-180X
AISC-1210H-220X
AISC-1210H-270X
AISC-1210H-330X
AISC-1210H-390X
AISC-1210H-470X
AISC-1210H-560X
AISC-1210H-680x
AISC-1210H-820X
AISC-1210H-101X
AISC-1210H-121X
AISC-1210H-151X
AISC-1210H-181X
AISC-1210H-271X
AISC-1210H-331X
AISC-1210H-391X
AISC-1210H-471X
OPTIONS & PART IDENTIFICATION:
(Left blank if standard)
AISC-1210H-xxx Series
-25°C to + 85°C
-25°C to + 85°C, 70% RH max.
Test
L (μH)
Frequency
SRF (MHz)
Rdc(mΩ) Ir (A) max.
Rdc(mΩ) Idc (mA)
Min
Max
max.
max.
AISC - 1210H -
-
-
Inductance Code
Please refer to the Table
Test
L (µH)
Condition
0.15
0.27
0.39
0.56
0.82
1.0
1.2
1.5
1.8
2.2
2.4
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
100.0
120.0
150.0
180.0
220.0
270.0
330.0
390.0
470.0
560.0
680.0
AISC-1210H-221X
AISC-1210H-561X
AISC-1210H-681X
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
1.0 MHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
100 KHz
1 KHz
1 KHz
1 KHz
1 KHz
400
250
200
180
150
100
90
80
72
64
62
60
53
45
43
38
32
30
26
26
26
20
19
18
17
16
15
13
12
12
10
8
7
7
6.8
6
5.6
5
4
4
3.2
21
22
33
50
53
63
92
100
110
124
130
132
167
222
247
359
392
450
509
674
760
978
1120
1240
1940
2000
3200
3640
4060
4580
6880
7470
8320
13160
14400
15000
18900
20400
27500
29800
40000
4.40
4.00
3.10
2.90
2.60
2.30
2.10
1.70
1.50
1.30
1.30
1.20
1.15
1.00
0.90
0.78
0.75
0.70
0.65
0.61
0.55
0.45
0.43
0.38
0.35
0.33
0.30
0.25
0.21
0.20
0.18
0.16
0.14
0.12
0.10
0.08
0.06
0.06
0.06
0.05
0.04
Tolerance Code
J
K
M
±5%
±10%
±20%
T
Packaging
Tape & Reel
Revised: 02.08.08
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
UNSHIELDED SMD POWER INDUCTOR
AISC-1210H
OUTLINE DRAWING:
Pb
RoHS
Compliant
3.2 x 2.5 x 2.0mm
| | | | | | | | | | | | | | |
Series
AISC-1210H
A
0.126±0.012
B
0.098±0.012
C
0.079±0.012
D(ref)
0.079
(1.0)
a(ref)
0.039
(2.5)
b(ref)
0.047
(1.2)
c(ref)
0.024
(0.6)
Dimensions: Inches
(mm)
(3.2 ±0.3)
(2.5 ±0.3)
(2.0 ±0.3)
TAPE & REEL:
Tape and reel 4,000pcs/reel
Dimensions of Tape
ABRACON P/N
AISC-1210H
A (mm)
2.88 ± 0.1
B (mm)
3.74 ± 0.1
K (mm)
2.5 ± 0.1
P (mm)
4.0 ± 0.1
W (mm)
8.0 ± 0.3
PCS/REEL
2000
Dimensions of Reel
series
AISC-1210H
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
A
330-0.5
C
8.4+1.5
A
Z
Z
100±1.0
C
Dimensions: mm
Revised: 02.08.08
30332 Esperanza, Rancho Santa Margarita, California 92688
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Visit www.abracon.com for Terms & Conditions of Sale
