Single & Dual Output
DC/DC Converter
FEATURES:
●
●
●
●
●
●
●
●
10W DIL PACKAGE
2:1 WIDE INPUT RANGE
100% BURNED IN
HIGH EFFICIENCY
UL94V-0 PACKAGE MATERIAL
CUSTOM SOLUTIONS AVAILABLE
RoHS COMPLIANT
Remote Control:On/Off
Series FKC10
10Watt | DC-DC Converter
APPLICATIONS:
●
Wireless Network
●
Telecom/Datacom
●
Industry Control System
●
Measurement Equipment
●
Semiconductor Equipment
M
ODEL
S
ELECTION
C
HART
Input
Voltage
Vdc
9-18
9-18
9-18
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
18-36
18-36
18-36
18-36
36-75
36-75
36-75
36-75
36-75
36-75
Part Number
FKC10-12S03
FKC10-12S05
FKC10-12S12
FKC10-12S15
FKC10-12D05
FKC10-12D12
FKC10-12D15
FKC10-24S03
FKC10-24S05
FKC10-24S12
FKC10-24S15
FKC10-24D05
FKC10-24D12
FKC10-24D15
FKC10-24S03
FKC10-24S05
FKC10-48S12
FKC10-48S15
FKC10-48D05
FKC10-48D12
FKC10-48D15
Input
Current
No-Load
(mA TYP)
Full Load
(mA TYP)
Output
Voltage
Vdc
3.3
5
12
15
±
5
±12
±15
3.3
5
12
15
±5
±12
±15
3.3
5
12
15
±5
±12
±15
Output
Current
Full Load
(mA)
Efficiency
%TYP
82
82
83
83
83
83
83
82
82
83
83
83
83
83
82
82
83
83
83
83
83
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
20
20
20
20
1006
1016
1004
1009
1004
1012
1024
503
508
502
504
502
506
512
251
254
251
252
251
253
256
3000
2000
833
670
±1000
±420
±340
3000
2000
833
670
±1000
±420
±340
3000
2000
833
670
±1000
±420
±340
FKC10-12S03/*** add Suffix SMD for SMD package
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at
rated output load unless otherwise specified.
Temperature Derating Graph
OutPut Power(%)
100
Temperature Derating Graph
Tolerance Envelope Graph
Tolerance Envelope
1 20%
Graph
Output Voltage(%)
75
50
25
0
-40
75
85 100
1 10%
1 00%
90 %
80 %
70 %
4 0%
100%
110%
120%
30 %
80 %
9 0%
10%
20%
50%
60%
70%
Nature Convection
Ambient Temperature(
℃
)
Output Current(%)
1/3
www.make-ps.com
Input Specifications
Parameters
Voltage Types
Filter
Protection
E-mail:info@make-ps.com
Conditions
Min
Typ
Max
2:1
Units
Pi Network
Fuse Recommended
Output Specifications
Parameters
Voltage Tolerance
Short Circuit/ Restart
Over Load Protection
Line Regulation
Load Regulation
Minimum Load
Ripple & Noise
Transient response setting time
Single/Dual
Continuous/ Automatic
Temperature Coefficinet:±0.05%/
℃
Conditions
Min
Typ
150
Max
±2
±0.5
±0.5
100
350
Units
%
%
%
%
mVp-p
us
High Line to Low Line
Single & Dual (F.L-25%F.L)
10% of Full Load
BW=DC To 20MHz (with 1uF Cap.)
current change from 25% to 100%
General Specifications
Parameters
Isolation Resistance
Switching Frequency
Operating Temperature
Humidity
Cooling
Case material
Weight
Dimensions
Potting Material
Radiated Emissions
Conducted Emissions
Efficiency
Isolation Voltage
MTBF
Storage Temperature
Case Temperature
Conditions
500Vdc
Non Condensing
Free air Convection
Appearance size
EN55022
EN55022
For 10 seconds
Min
1000
-40
Typ
400
Max
100
95
Units
MΩ
KHz
℃
%
g
mm
Five-Side Shielded Case
80
900000
-55
17.5
31.6X20.1X10.0
Epoxy (UL94V-0 rated)
CLASS A
CLASS A
1500
+125
+95
MIL-HDBK-217F @25℃ , Ground Benign
%
VDC
Hours
℃
℃
Suggest adding input external filter(C1,C2,L)to meet conducted emissions (En55022 class A)
12uH
L
C1
C2
+Vin
+Vout
Load
DC/DC
Converter
-Vin
-Vout
2.2uF/100V
2.2uF/100V
Recommended Test Circuit
Vin
Cin
GND
12V & 24V & 48V:Cin 100uF,100V
+Vout
Vin
Cin
GND
100uF/25V
+Vout
COM
-Vout
Single
Cout
100uF/25V
Dual
Cout
Cout
100uF/25V
-Vout
24V & 48V:Cin 100uF,100V
2/3
www.make-ps.com
O
UTLINE
D
RAWING
31.80
20.30
E-mail:info@make-ps.com
Package Style and Pinning (mm)
10.20
3.8
2
20.30
2.54
5.10
15.20
DIP24 Package Style
Pin Connections
Pin #
1
2
3
9
11
14
16
22
23
Single
ON/OFF
-Vin
-Vin
NC
NC
+Vout
-Vout
+Vin
+Vin
Dual
ON/OFF
-Vin
-Vin
Com
-Vout
+Vout
Com
+Vin
+Vin
0.25 x 0.50
Rectangular Pin
9
11
1 2 3
Bottom View
23 22
16
14
NC = No Connection
Pin Pitch Tolerance ±0.35 mm
SMD Package Style
32.00
31.40
11.20
10.90
3.81
6.35
21.30
25.40
20.30
SMD Package Style
Same spec. as the original DIP spec. and pin
definition, excl. of the SMD type pin.
2.54
Pin Connections
Pin #
Single
1
ON/OFF
2
-Vin
3
-Vin
9
NC
11
NC
14
+Vout
16
-Vout
22
+Vin
23
+Vin
Others
NC
NC = No Connection
Dual
ON/OFF
-Vin
-Vin
Com
-Vout
+Vout
Com
+Vin
+Vin
NC
Pin area
0.1 x 0.50
1 2 3 4 5
0.50
9 10 11 12
2.54
1.60
2.40
23.40
Bottom View
24 23 22 21 20
16 15 14 13
26.54
24.14
1
Top View
Pin Pitch Tolerance ±0.35 mm
27.94
11 x 2.54
All specifications are typical at nominal input, nominal load and 25
°
C unless otherwise specified.
External, low ESR, 10 microfarad (minimum) capacitor across output is recommended for operation.
Make Power world-class design, development and manufacturing team stands ready to work with you to deliver the exact power
converter you need for your ready to work with you to deliver the exact power converter you need for your demanding, large volum
OEM applications. And ... we ll do it on time and within budget
Our experienced applications and design staffs; quick-turn prototype capability; highly automated, SMT assembly facilities;
and in-line SPC quality-control techniques combine to give us the unique ability to design and deliver any quantity of power
converters to the highest standards of quality and reliability.
We have compiled a large library of DC/DC designs that are currently used in a variety of telecom, medical, computer, railway,
aerospace and industrial applications. We may already have the converter you need.
Contact us. Our goal is to provide you the highest-quality, most cost-effective power converters available.
CUSTOM CAPABILITIES
3/3
