PTMA080152M Overview

Wideband RF LDMOS Integrated Power Amplifier 30 W, 700-1000 MHz

PTMA080152M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Infineon
Reach Compliance Code	compli
Characteristic impedance	50 Ω
structure	COMPONENT
Gain	29 dB
Maximum input power (CW)	42 dBm
JESD-609 code	e3
Maximum operating frequency	1000 MHz
Minimum operating frequency	700 MHz
RF/Microwave Device Types	WIDE BAND HIGH POWER
Terminal surface	Matte Tin (Sn)
Maximum voltage standing wave ratio	10

Preview

Download Datasheet

View All

PTMA080302M

Confidential, Limited Internal Distribution

Wideband RF LDMOS Integrated Power Amplifier

30 W, 700 – 1000 MHz

Description

The PTMA080302M is a wideband, matched, 30-watt, 2-stage

LDMOS integrated amplifier intended for use in all typical modulation

formats from 700 to 1000 MHz. This device is offered in a 20-lead,

thermally-enhanced, overmolded package for cool and reliable

operation.

PTMA080302M

Package PG-DSO-20-63

Features

Broadband Performance

= 28 V, I

DQ1

= 120 mA, I

DQ2

= 280 mA,

fixture tuned for 920 - 960 MHz

•

Designed for wide RF modulation bandwidths,

and low memory effects

On-chip matching, integrated input DC block,

50-ohm input and ~ 8-ohm output

Typical GSM/EDGE performance, 940 MHz, 28 V

- Output power = 15 W Avg.

- Linear gain = 31 dB

- Power added efficiency = 36%

- EVM at 15 W = 1.7 %

- ACPR at 400 kHz = –61 dBc

- ACPR at 600 kHz = –73 dBc

Typical CW performance at 940 MHz, 28 V

- Output power at P–1dB = 32 W

- Linear gain (1 W) = 31 dB

- Power added efficiency = 46%

Capable of handling 10:1 VSWR @ 28 V, 30 W

(CW) output power

Integrated ESD protection. Meets HBM Class 1B

(minimum), per JESD22-A114F

RoHS-compliant package

Gain

-5

-10

-15

Return Loss (dB)

Gain (dB)

•

Return Loss

-20

-25

700 750 800 850 900 950 1000 1050 1100

•

Frequency (MHz)

RF Characteristics

GSM/EDGE Measurements

(not subject to production test—verified by design/characterization in Infineon test fixture)

= 28 V, I

DQ1

= 120 mA, I

DQ2

= 280 mA, ƒ = 920 to 960 MHz, P

OUT

= 15 W Avg.

Characteristic

Gain

Power-added Efficiency

Error Vector Magnitude

Symbol

PAE

EVM (RMS)

Min

—

Typ

1.7

Max

—

Unit

All published data at T

CASE

= 25°C unless otherwise indicated

ESD:

Electrostatic discharge sensitive device—observe handling precautions!

Data Sheet

1 of 11

Rev. 05.1, 2010-11-09
