2SA684: DescriptionRF SMALL SIGNAL TRANSISTOR; CategoryDiscrete semiconductor The transistor; File Size747KB，4 Pages; ManufacturerSECOS; Websitehttp://www.secosgmbh.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

2SA684 Overview

RF SMALL SIGNAL TRANSISTOR

2SA684 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT, PLASTIC, TO-92L, 3 PIN
Reach Compliance Code	compli
ECCN code	EAR99
Maximum collector current (IC)	1 A
Collector-emitter maximum voltage	50 V
Configuration	SINGLE
Minimum DC current gain (hFE)	50
JEDEC-95 code	TO-92
JESD-30 code	O-PBCY-T3
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	PNP
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Transistor component materials	SILICON
Nominal transition frequency (fT)	200 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

2SA684

Elektronische Bauelemente

-1A , -60V

PNP Plastic Encapsulated Transistor

RoHS Compliant Product

A suffix of “-C” specifies halogen & lead-free

FEATURE

Automatic insertion by radial taping possible.

Complementary pair with 2SC1384L.

TO-92L

Emitter

Collector

Base

CLASSIFICATION OF h

Product-Rank

Range

2SA684-Q

85~170

2SA684-R

120~240

2SA684-S

170~340

REF.

Millimeter

Min.

Max.

4.70

5.10

7.80

8.20

13.80

14.20

3.70

4.10

0.35

0.55

0.35

0.45

1.27 TYP.

1.28

1.58

2.44

2.64

0.60

0.80

Collector

Base

Emitter

ABSOLUTE MAXIMUM RATINGS

= 25°C unless otherwise specified)

Parameter

Collector to Base Voltage

Collector to Emitter Voltage

Emitter to Base Voltage

Collector Current - Continuous

Collector Power Dissipation

Junction, Storage Temperature

Symbol

CBO

CEO

EBO

, T

STG

Ratings

-60

-50

-5

-1

150, -55~150

Unit

ELECTRICAL CHARACTERISTICS

= 25°C unless otherwise specified)

Parameter

Collector-Base Breakdown Voltage

Collector-Emitter Breakdown Voltage

Emitter-Base Breakdown Voltage

Collector Cut-off Current

DC Current Gain

Collector to Emitter Saturation Voltage

Base-Emitter Voltage

Transition Frequency

Collector Output Capacitance

Symbol

(BR)CBO

(BR)CEO

(BR)EBO

CBO

FE (1)

FE (2)

CE(sat)

BE(sat)

Min.

-60

-50

-5

Typ.

Max.

-0.1

340

Unit

µA

Test Conditions

= -10µA, I

= -2mA, I

= -10µA, I

= -20V, I

= -10V, I

= -500mA

= -5V, I

= -1A

-0.2

-0.85

200

-0.4

-1.2

MHz

= -500mA, I

= -50mA

= -500mA, I

= -50mA

= -10V, I

=50mA , f=200MHz

= -10V, I

=0, f=1MHz

http://www.SeCoSGmbH.com/

Any changes of specification will not be informed individually.

21-Jan-2011 Rev. B

Page 1 of 3
