BZP61 / BZP62
Silicon Power Zener Diode
Part no.
Description
The BZP61/62 are plastic sealed 35A- forward
current diodes, which are available in different
Zener voltages.
Features
•
•
•
•
Applications
•
•
Forward current 35A
Zener voltages 22V, 27V, 33V or 39V
Plastic sealed press-fit package
Available in different package modifications
Power supplies
Rectifier diode in car alternators
Pinout details
BZP61:
1 - cathode
2 - anode
BZP62:
1 - anode
2 - cathode
Typical application circuit
exciting current
Alternator
1
2
+
3 x BZP61
-
3x BZP62
Ordering information
Device
BZP61-22; …; BZP61-39
BZP62-22; …; BZP62-39
Quantity per box
500
500
Options
The package quantities for the different package
modifications are included in
“PressFitPackageModifications.pdf”
Device marking
Devices are identified by type. Colour of marking: BZP61- black, BZP62 – red
422........................................……. date code 422 = 2004 week 22
ZETEX
BZP61………………………………... diode type
22………………………….……….. Zener voltage V
Z
(in V) 22
Issue 2 – August 2006
© Zetex Semiconductors plc 2006
1
www.zetex.com
BZP61 / BZP62
Absolute maximum ratings
(at T
amb
= 25°C unless otherwise stated)
Parameter
BZP61-22
Z-current
(continuous)
BZP61-27
BZP61-33
BZP61-39
Mean forward current
BZP62-22
BZP62-27
BZP62-33
BZP62-39
I
F(AV)
I
Z
Symbol
5.5
4.5
3.8
3.3
35
600
Surge forward current
I
FSM
500
A
A
sinusoidal,
f = 15 - 1000 Hz
T
J
= 25°C,
half-sine wave,
≤
10 ms
T
J
= 175°C,
half-sine wave,
≤
10 ms
T
J
= 25°C,
half-sine wave,
≤
10 ms
T
J
= 175°C,
half-sine wave,
≤
10 ms
f = 15 - 1000 Hz
sinusoidal,
f = 15 - 1000 Hz
A
T
c
= 25°C
Unit
Test condition
1800
Maximum rated value
∫i²dt
1250
Repetitive peak forward current
Effective forward current
Junction temperature
Storage temperature range
I
FRM
=π*I
F(AV)
I
F(RMS)
T
Jmax
T
stg
110
55
140
- 50 to + 140
A
A
°C
°C
A²s
Thermal resistance
Parameter
Junction to case
Symbol
R
θJC
Value
0.8
Unit
°C/W
Issue 2 – August 2006
© Zetex Semiconductors plc 2006
2
www.zetex.com
BZP61 / BZP62
Electrical characteristics
(at T
amb
= 25°C unless otherwise stated)
Parameter
BZP61-22
Z-voltage
BZP61-27
BZP61-33
BZP61-39
Forward voltage
Reverse current
BZP61-22
Dynamical
resistance
BZP61-27
BZP61-33
BZP61-39
BZP61-22
Dynamical
resistance BZP61-27
(information
BZP61-33
value)
BZP61-39
BZP61-22
Dynamical
resistance BZP61-27
(information
BZP61-33
value)
BZP61-39
BZP62-22
BZP62-27
BZP62-33
BZP62-39
BZP62-22
BZP62-27
BZP62-33
BZP62-39
BZP62-22
BZP62-27
BZP62-33
BZP62-39
r
Z
r
Z
r
Z
BZP62-22
BZP62-27
BZP62-33
BZP62-39
V
F
I
R
V
Z
Symbol
Min.
20.8
25.1
31
37
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Typ.
22
27
33
39
1.0
-
-
-
-
-
-
-
-
-
-
-
-
-
Max.
23.3
28.9
35
41
1.1
200
2
3.5
5
6
200
350
500
700
20
35
50
80
mΩ
at I
Z
= 10A
mΩ
at I
Z
= 1A
Ω
at I
Z
= 100mA
V
µA
I
F
= 35 A,
measuring time
1ms
at V
Z
–5V
V
at I
Z
= 100mA
Unit
Test contitions
Issue 2 – August 2006
© Zetex Semiconductors plc 2006
3
www.zetex.com
BZP61 / BZP62
Packaging details
Package dimensions
Dimensions in millimeters are control dimensions, dimensions in inches are approximate
DIM
A
A1
A2
D
D1
D2
D3
MIN
18,00
5,70
2,10
15,50
12,72
11,50
1,31
Millimeters
TYP
18,50
6,20
2,30
15,70
12,77
11,70
1,36
Inches
TYP
0,728
0,244
0,091
0,618
0,503
0,461
0,054
MAX
19,00
6,70
2,50
15,90
12,82
11,90
1,41
MIN
0,709
0,224
0,083
0,610
0,501
0,453
0,052
MAX
0,748
0,264
0,098
0,626
0,505
0,469
0,056
