RKZ-KG Series
Silicon Planar Zener Diode for Surge Absorption and Stabilizer
REJ03G1512-0300
Rev.3.00
Feb 02, 2009
Features
•
These diodes are delivered taped.
•
Lineup of environmental friendly Halogen free type (RKZ-KG-P6 Series 6:Pb free & Halogen free).
•
Ultra small Resin Package (URP) is suitable for compact and high-density surface mount design.
Ordering Information
Part No.
RKZ-KG Series
RKZ-KG P6 Series
(Halogen-free type)
Laser Mark
Let to Mark Code
Package Name
URP
Package Code
PTSP0002ZA-A
Taping Abbreviation
(Quantity)
P (3,000 pcs / reel)
Pin Arrangement
Cathode mark
Mark
1
2•0
2
1. Cathode
2. Anode
REJ03G1512-0300 Rev.3.00 Feb 02, 2009
Page 1 of 6
RKZ-KG Series
Absolute Maximum Ratings
(Ta = 25°C)
Item
Power dissipation
Junction temperature
Storage temperature
Note:
1. With P.C. Board.
Symbol
Pd *
Tj
Tstg
1
Value
200
150
–55 to +150
Unit
mW
°C
°C
Electrical Characteristics
(Ta = 25°C)
Zener Voltage
V
Z
(V) *
Min
Max
1.90
2.10
2.30
2.65
2.95
3.25
3.55
3.87
4.15
4.55
4.98
5.49
6.06
6.65
7.28
8.02
8.85
9.77
10.76
11.74
12.91
14.34
15.85
17.56
19.52
21.54
23.72
25.10
28.00
31.00
34.00
2.20
2.40
2.60
2.90
3.20
3.50
3.80
4.10
4.34
4.75
5.20
5.73
6.33
6.93
7.60
8.36
9.23
10.21
11.22
12.24
13.49
14.98
16.51
18.35
20.39
22.47
24.78
28.90
32.00
35.00
38.00
1
Reverse Current
I
R
(μA)
Max
120
120
120
120
50
20
10
10
10
10
5
5
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
Test
Condition
V
R
(V)
0.5
0.7
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.5
3.0
3.5
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
12.0
13.0
15.0
17.0
19.0
21.0
23.0
25.0
27.0
Dynamic Resistance
r
d
(Ω)
Max
100
100
100
110
120
130
130
130
130
130
130
80
50
30
30
30
30
30
30
35
35
40
40
45
50
55
60
70
80
80
90
Test
Condition
I
Z
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
ESD-Capability *
2
— (kV) *
2
Min
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
25
25
25
20
20
15
15
13
8
8
Part No.
RKZ2.0BKG
RKZ2.2BKG
RKZ2.4BKG
RKZ2.7B2KG
RKZ3.0B2KG
RKZ3.3B2KG
RKZ3.6B2KG
RKZ3.9B2KG
RKZ4.3B2KG
RKZ4.7B2KG
RKZ5.1B2KG
RKZ5.6B2KG
RKZ6.2B2KG
RKZ6.8B2KG
RKZ7.5B2KG
RKZ8.2B2KG
RKZ9.1B2KG
RKZ10B2KG
RKZ11B2KG
RKZ12B2KG
RKZ13B2KG
RKZ15B2KG
RKZ16B2KG
RKZ18B2KG
RKZ20B2KG
RKZ22B2KG
RKZ24B2KG
RKZ27BKG
RKZ30BKG
RKZ33BKG
RKZ36BKG
Test
Condition
I
Z
(mA)
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
Notes: 1. Tested with pulse (Pw = 40 ms).
2. C =150 pF, R = 330
Ω,
Both forward and reverse direction 10 pulse
Failure criterion ; According to IR spec
REJ03G1512-0300 Rev.3.00 Feb 02, 2009
Page 2 of 6
RKZ-KG Series
Mark Code
Part No.
RKZ2.0BKG
RKZ2.2BKG
RKZ2.4BKG
RKZ2.7B2KG
RKZ3.0B2KG
RKZ3.3B2KG
RKZ3.6B2KG
RKZ3.9B2KG
RKZ4.3B2KG
RKZ4.7B2KG
RKZ5.1B2KG
RKZ5.6B2KG
RKZ6.2B2KG
RKZ6.8B2KG
RKZ7.5B2KG
RKZ8.2B2KG
Note:
Mark No.
2
•
0
2
•
2
2
•
4
2
•
7
3
•
0
3
•
3
3
•
6
3
•
9
4
•
3
4
•
7
5
•
1
5
•
6
6
•
2
6
•
8
7
•
5
8
•
2
Part No.
RKZ9.1B2KG
RKZ10B2KG
RKZ11B2KG
RKZ12B2KG
RKZ13B2KG
RKZ15B2KG
RKZ16B2KG
RKZ18B2KG
RKZ20B2KG
RKZ22B2KG
RKZ24B2KG
RKZ27BKG
RKZ30BKG
RKZ33BKG
RKZ36BKG
Mark No.
9
•
1
10
•
11
•
12
•
13
•
15
•
16
•
18
•
20
•
22
•
24
•
27
•
30
•
33
•
36
•
1. Example of Marking
2•0
RKZ2.0BKG
10•
RKZ10B2KG
REJ03G1512-0300 Rev.3.00 Feb 02, 2009
Page 3 of 6
RKZ-KG Series
Main Characteristic
RKZ2.4BKG
RKZ3.0B2KG
RKZ3.6B2KG
RKZ4.3B2KG
RKZ5.1B2KG
RKZ6.8B2KG
RKZ7.5B2KG
RKZ8.2B2KG
RKZ9.1B2KG
RKZ10B2KG
RKZ11B2KG
RKZ12B2KG
RKZ13B2KG
RKZ15B2KG
RKZ16B2KG
RKZ18B2KG
RKZ20B2KG
10
8
Zener Current I
Z
(mA)
6
4
RKZ6.2B2KG
RKZ2.0BKG
RKZ22B2KG
RKZ24B2KG
RKZ27BKG
RKZ30BKG
RKZ33BKG
2
0
0
4
8
12
16
20
24
28
32
RKZ36BKG
36
40
Zener Voltage V
Z
(V)
Fig.1 Zener current vs. Zener voltage
0.10
0.08
%/°C
50
40
250
Polyimide board
20hx15wx0.8t
Zener Voltage
Temperature Coefficient
γ
Z
(mV/°C)
Zener Voltage
Temperature Coefficient
γ
Z
(%/°C)
0.06
0.04
mV/°C
0.02
0
-0.02
-0.04
-0.06
-0.08
-0.10
0
5
30
20
10
0
-10
-20
-30
-40
-50
10 15 20 25 30 35 40
Zener Voltage V
Z
(V)
200
1.5
Power Dissipation Pd (mW)
150
3.0
1.5
unit: mm
100
50
0
0
50
100
150
Ambient Temperature Ta (°C)
Fig.3 Power Dissipation vs. Ambient Temperature
Fig.2 Temperature Coefficient vs. Zener voltage
REJ03G1512-0300 Rev.3.00 Feb 02, 2009
Page 4 of 6
0.8
200
RKZ-KG Series
100
P
RSM
RKZ3.9B2KG
RKZ5.6B2KG
RKZ15B2KG
Nonrepetitive Surge Reverses Power P
RSM
(W)
t
Ta = 25°C
nonrepetitive
10
1.0
0
0.1
1.0
Time t
(s)
10
100
Fig.4 Surge Reverse Power Ratings(Reference data)
REJ03G1512-0300 Rev.3.00 Feb 02, 2009
Page 5 of 6
