IRKT152/04PBF

Description
Silicon Controlled Rectifier, 330A I(T)RMS, 400V V(DRM), 400V V(RRM), 2 Element, INT-A-PAK-7
CategoryAnalog mixed-signal IC    Trigger device
File Size164KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric Compare View All

IRKT152/04PBF Overview

Silicon Controlled Rectifier, 330A I(T)RMS, 400V V(DRM), 400V V(RRM), 2 Element, INT-A-PAK-7

IRKT152/04PBF Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerVishay
package instructionFLANGE MOUNT, R-XUFM-X7
Contacts7
Reach Compliance Codeunknown
Shell connectionISOLATED
ConfigurationSERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Maximum DC gate trigger current150 mA
JESD-30 codeR-XUFM-X7
Number of components2
Number of terminals7
Package body materialUNSPECIFIED
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum rms on-state current330 A
Off-state repetitive peak voltage400 V
Repeated peak reverse voltage400 V
surface mountNO
Terminal formUNSPECIFIED
Terminal locationUPPER
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeSCR

IRKT152/04PBF Preview

Bulletin I27122 rev. D 11/04
IRKT152/04
THYRISTOR/ THYRISTOR
INT-A-pak
TM
Power Module
Features
Electrically Isolated by DBC Ceramic ( Al
2
O
3
)
3500 V
RMS
Isolating Voltage
Industrial Standard Package
High Surge Capability
Glass Passivated Chips
Simple Mounting
UL E78996 approved
150 A
Applications
Battery Charges
Welders
Power Converters
Major Ratings and Characteristics
Parameters
I
T(AV)
@ T
C
I
T(RMS)
I
TSM
I
2
t
2
CASE STYLE NEW INT-A-PAK
Units
A
°C
A
IRKT152/04
150
85
330
@ 50Hz
@ 60Hz
@ 50Hz
@ 60Hz
4000
4200
80
73
800
400
- 40 to 150
- 40 to 125
KA
2
√s
V
°C
KA
2
s
I
√t
V
RRM
T
STG
range
T
J
range
www.irf.com
1
IRKT152/04
Bulletin I27122 rev. D 11/04
ELECTRICAL SPECIFICATIONS
Voltage Ratings
Type number
V
RRM
/V
DRM
, Maximum repetitive
peak reverse voltage
V
RSM
/V
DSM
, Maximum non-repetitive
peak reverse voltage
I
RRM /
I
DRM
@ 125°C
mA
50
V
IRKT152/04
400
V
500
On-state Conduction
Parameter
I
T(AV)
Max. average on-state current
@ Case temperature
Maximum peak, one-cycle
on-state, non-repetitive
surge current
I
2
t
Maximum I
2
t for fusing
IRKT152/04
150
85
330
4000
4200
3350
3500
80
73
56
51
Units Conditions
A
°C
A
A
180° conduction half sine wave
as AC switch
t = 10ms
t = 10ms
KA
2
s
t = 10ms
t = 10ms
KA
√s
2
I
T(RMS)
Maximum RMS on-state current
I
TSM
No voltage
100% V
RRM
No voltage
100% V
RRM
Sine half wave,
Initial T
J
= T
J
max
t = 8.3ms reapplied
t = 8.3ms reapplied
t = 8.3ms reapplied
t = 8.3ms reapplied
t = 0.1 to 10ms, no voltage reapplied
@ T
J
max.
I
pk
=
Π
I
T (AV)
, T
J
= 25°C
T
J
= 25
o
C, anode supply = 6V,
resistive load, gate open circuit
T
J
= 25
o
C, anode supply = 6V, resistive load
V
mΩ
V
mA
I
√t
2
Maximum I
√t
for fusing
2
800
0.82
1.44
1.48
200
400
V
T(TO)
r
t
V
TM
I
H
I
L
Value of threshold voltage
On-state slope resistance
Maximum on-state voltage drop
Maximum Holding Current
Maximum Latching Current
Switching
t
gd
t
gr
t
q
Typical delay time
Typical rise time
Typical turn-off time
1
2
50 - 200
µs
T
J
= 25
o
C
T
J
= 25
o
C
Gate Current=1A dIg/dt=1A/µs
Vd=0,67% V
DRM
I
TM
= 300 A; -dI/dt = 15 A/µs; T
J
= T
J
max
V
r
= 50 V; dV/dt = 20 V/µs; Gate 0 V, 100Ω
Blocking
I
RRM
I
DRM
V
INS
Maximum peak reverse and
off-state leakage current
RMS isolation voltage
3500
1000
V
V/µs
50Hz, circuit to base, all terminals shorted, t = 1s
T
J
= T
J
max., exponential to 67% rated V
DRM
50
mA
T
J
= 125
o
C
dV/dt critical rate of rise of off-state voltage
2
www.irf.com
IRKT152/04
Bulletin I27122 rev. D 11/04
Triggering
Parameter
P
GM
I
GM
-V
GT
V
GT
Max. peak gate power
IRKT152/04
12
3
3
10
4
2.5
1.7
270
150
80
0.3
10
300
Units Conditions
W
W
A
V
V
T
J
= - 40°C
T
J
= 25°C
T
J
= T
J
max.
T
J
= - 40°C
mA
V
mA
A/µs
@ T
J
= T
J
max., I
TM
= 400A rated V
DRM
applied
T
J
= 25°C
T
J
= T
J
max.
@ T
J
= T
J
max., rated V
DRM
applied
Anode supply = 6V, resistive
load; Ra = 1Ω
Anode supply = 6V, resistive
load; Ra = 1Ω
tp
5ms, T
J
= T
J
max.
f=50Hz, T
J
= T
J
max.
tp
5ms, T
J
= T
J
max.
P
G(AV)
Max. average gate power
Max. peak gate current
Max. peak negative
gate voltage
Max. required DC gate
voltage to trigger
I
GT
Max. required DC gate
current to trigger
V
GD
I
GD
di/
dt
Max. gate voltage
that will not trigger
Max. gate current
that will not trigger
Max. rate of rise of
turned-on current
Thermal and Mechanical Specifications
Parameter
T
J
T
stg
R
thJC
R
thCS
T
wt
Max. junction operating
temperature range
Max. storage temperature
range
Max. thermal resistance,
junction to case
Max. thermal resistance,
case to heatsink
Mounting
IAP to heatsink
torque ± 10% busbar to IAP
Approximate weight
Case Style
IRKT152/04
-40 to 125
-40 to 150
0.18
0.05
4 to 6
4 to 6
200 (7.1)
New Int-A-Pak
Units Conditions
°C
°C
K/W
K/W
Nm
g(oz)
DC operation, per junction
Mounting surface smooth, flat and greased
Per module
A mounting compound is recommended and
the torque should be rechecked after a period
of 3 hours to allow for the spread of the
compound. Lubricated threads.
∆R
Conduction (per Junction)
(The following table shows the increment of thermal resistance R
thJC
when devices operate at different conduction angles than DC)
Devices
IRKT152/04
Sinusoidal conduction @ T
J
max.
180
o
Rectangular conduction @ T
J
max.
30
o
120
o
90
o
60
o
180
o
120
o
0.012
90
o
0.014
60
o
0.016
30
o
0.017
Units
K/W
0.007
0.010
0.013
0.016
0.017
0.009
www.irf.com
3
IRKT152/04
Bulletin I27122 rev. D 11/04
Ordering Information Table
Device Code
IRK
1
1
2
3
4
-
-
-
-
T
2
152
3
/
04
4
Module Type
Circuit Configuration
Current Rating
Voltage Rating (04 = 400V)
Outline Table
All dimensions are in millimeters
1
2
3
5 7
4 6
4
www.irf.com
IRKT152/04
Bulletin I27122 rev. D 11/04
Maximum Allowable Case Temperature (°C)
130
120
110
100
90
80
0
Maximum Allowable Case Temperature (°C)
IRKT152
RthJC (DC) = 0.182 K/W
130
120
110
100
90
80
70
60
0
IRKT152
RthJC (DC) = 0.182 K/W
Conduction Angle
Conduction Period
30˚
60˚
90˚
120˚
180˚
30˚
60˚
90˚
120˚
180˚
DC
20 40 60 80 100 120 140 160
Average On-state Current (A)
50
100
150
200
250
Average On-state Current (A)
Fig. 2 - Current Ratings Characteristics
Maximum Average On-state Power Loss (W)
Fig. 1 - Current Ratings Characteristics
Maximum Average On-state Power Loss (W)
220
200
180
160
140
120
100
80
60
40
20
0
0
180˚
120˚
90˚
60˚
30˚
RMS Limit
300
250
200
DC
180˚
120˚
90˚
60˚
30˚
150
RMS Limit
100
50
0
0
50
100
150
200
250
Average On-state Current (A)
Fig. 4 - Forward Power Loss Characteristics
Conduction Period
Conduction Angle
IRKT152
Tj = 125˚C
IRKT152
Tj = 125˚C
20 40 60 80 100 120 140 160
Average On-state Current (A)
Fig. 3 - Forward Power Loss Characteristics
Peak Half Sine Wave On-state Current (A)
Peak Half Sine Wave On-state Current (A)
3600
3400
3200
3000
2800
2600
2400
2200
2000
1800
1600
1
At Any Rated Load Condition And With
Rated Vrrm Applied Following Surge.
Initial Tj = 125˚C
@ 60 Hz 0.0083 s
@ 50 Hz 0.0100 s
4500
Maximum Non Repetitive Surge Current
Versus Pulse Train Duration. Control
Of Conduction May Not Be Maintained.
4000
Initial Tj = 125˚C
No Voltage Reapplied
3500
Rated Vrrm Reapplied
3000
2500
2000
IRKT152
Per Junction
IRKT152
Per Junction
10
100
1500
0.01
0.1
1
Number Of Equal Amplitude Half Cycle Current Pulses (N)
Fig.5 - Maximum Non-Repetitive Surge Current
Pulse Train Duration (s)
Fig. 6 - Maximum Non-Repetitive Surge Current
www.irf.com
5

IRKT152/04PBF Related Products

IRKT152/04PBF
Description Silicon Controlled Rectifier, 330A I(T)RMS, 400V V(DRM), 400V V(RRM), 2 Element, INT-A-PAK-7
Is it Rohs certified? conform to
Maker Vishay
package instruction FLANGE MOUNT, R-XUFM-X7
Contacts 7
Reach Compliance Code unknown
Shell connection ISOLATED
Configuration SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Maximum DC gate trigger current 150 mA
JESD-30 code R-XUFM-X7
Number of components 2
Number of terminals 7
Package body material UNSPECIFIED
Package shape RECTANGULAR
Package form FLANGE MOUNT
Peak Reflow Temperature (Celsius) NOT SPECIFIED
Certification status Not Qualified
Maximum rms on-state current 330 A
Off-state repetitive peak voltage 400 V
Repeated peak reverse voltage 400 V
surface mount NO
Terminal form UNSPECIFIED
Terminal location UPPER
Maximum time at peak reflow temperature NOT SPECIFIED
Trigger device type SCR
Design Principle of USB Interface on DSP Platform
The USB interface (Universal Serial Bus) is a universal high-speed serial interface. Its main feature is its high-speed transmission characteristics. The theoretical speed limit of USB1.1 can reach 12...
q775499308 Microcontroller MCU
Analyzing the wiring strategy in high-speed PCB design
Differential pairs work by making the received signal equal to the difference between two complementary signals that are referenced to each other, thus greatly reducing the effects of electrical noise...
yuandayuan6999 PCB Design
I want to learn FPGA, can you recommend one?
I want to learn FPGA, can you recommend one? Or are there no different types of FPGA?...
瑶曳风尘 FPGA/CPLD
Why can't I enter the interrupt function?
#includestatic unsigned int results;void main(void) {volatile unsigned int i;//unsigned long int j;WDTCTL = WDTPW+WDTHOLD;// Stop watchdog timerP6SEL |= 0x01;// Enable A/D channel A0ADC12CTL0 = ADC12O...
smartygt Microcontroller MCU
IEEE JSSC papers from the 1960s to 2005 Full collection 15G eMule address
As the original document is too large, the point-to-point method takes up a lot of bandwidth. Now we use Dianluo sharing, which will be very fast. In order to facilitate downloading, it is repackaged ...
PowerAnts Analog electronics
Cyclone V Trial Experience 4: Crystal Oscillator Settings and Power Consumption Monitoring of Test Tools
I have done various tests on LEDs, buttons, display screens, RAM and FLASH using test software before. Today, I wanted to set the crystal oscillator, but it didn't work. It said that the device could ...
ddllxxrr FPGA/CPLD

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

Index Files: 1917  968  1993  1737  467  39  20  41  35  10
Datasheet   0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190
Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号 京ICP备10001474号-1 电信业务审批[2006]字第258号函 京公网安备 11010802033920号
