Ultra Wide Bandwidth
Amplifier
50Ω,
•
•
•
•
•
•
•
•
•
•
•
•
•
ZX60-14012L
300 KHz to 14 GHz
Features
Wide Bandwidth, 300 KHz to 14 GHz
Reverse voltage connection protected
Over-voltage transient protected
Excellent flatness over frequency range, ±1dB Typ.
+11dBm Typ. output power at 1dB compression
Low cost
Protected by US Patent 6,790,049
CASE STYLE: GC957
Connectors
SMA
Model
ZX60-14012L-S
Price
$172.95 ea.
Qty.
(1-9)
Applications
Broad band
Buffer or low level driver
General purpose
Lab
Instrumentation
Test Equipment
MODEL
NO.
FREQ.
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
Output
(1 dB Comp.)
f
L
- f
U
Flatness
Typ. Min.
12
9
Typ. Max.
±1.0
±2.0
Typ.
11
(Note 3)
Electrical Specifications at T
AMB
= 25
o
C
DYNAMIC
RANGE
NF
(dB)
Typ.
5.5
(Note 1)
VSWR
(:1)
Typ.
IP3
(dBm)
Typ.
20
In
1.3
Out
1.7
ACTIVE
DIRECTIVITY
(dB)
Isolation-Gain
DC
VOLTAGE
@ Pin V+
(V)
(Note 2)
DC
OPERATING
CURRENT @
Pin V+
(mA)
Min.
9
Max.
7.5
Typ.
4.5-8.5
12
Typ.
62
Max.
68
ZX60-14012L
0.3-14000
1. Noise figure tested and guaranteed over the 10-14000 MHz range.
2. Unit is internally voltage regulated over 10.5 to 20 VDC input range.
3. +4 dBm min. power output @ 10000-14000 MHz
Operating Temperature -40
o
C to 80
o
C case
-40
o
C to 55
o
C ambient at 12V
-40
o
C to 50
o
C ambient at 15V
-40
o
C to 40
o
C ambient at 20V
Storage Temperature
-55
o
C to 100
o
C
DC Voltage
20V
Input Power(no Damage)
10dBm
Maximum Ratings
Outline Drawing
Outline Dimensions (
inch
)
mm
A
B
C
D
.74 .75 .46 1.18
18.8 19.1 11.6 30.0
E
.04
1.0
F
G H
.17 .45 .59
4.3 11.4 14.9
J
.33
8.3
K
.21
5.3
L
.22
5.6
M
N
P
.18 1.00 0.37
4.6 25.4 9.4
®
Q
.18
4.6
R
wt.
.09 grams
2.3
23.0
INTERNET
http://www.minicircuits.com
REV.OR
M99235
EDB040201
ZX60-14012L
BLUEC
061121
page 1 of 2
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Mini-Circuits
ISO 9001 & ISO 14001
Certified
Typical Performance Data & Curves at
25
o
C
FREQUENCY
(MHz)
0.3
10
500
750
1000
2000
3000
4000
5000
6000
7000
8000
9000
10000
11000
11500
12000
12500
13000
14000
GAIN
(dB)
11.68
11.29
11.31
10.99
11.03
11.72
11.94
12.87
12.86
12.71
12.45
12.55
11.85
11.98
12.16
12.19
11.86
11.89
11.87
11.41
DIRECTIVITY
(dB)
8.13
7.89
7.86
8.57
8.23
7.03
6.45
4.67
4.55
4.76
5.00
5.35
5.87
5.84
5.61
5.41
5.44
5.59
5.65
5.97
VSWR
IN
(:1)
1.26
1.19
1.21
1.21
1.20
1.26
1.22
1.14
1.19
1.24
1.20
1.34
1.62
1.81
1.73
1.64
1.55
1.48
1.39
1.19
VSWR
OUT
(:1)
1.96
1.72
1.71
1.67
1.57
1.51
1.35
1.24
1.47
1.67
1.67
1.65
1.72
1.77
1.71
1.73
1.72
1.69
1.64
1.39
POWER OUT @1dB
COMPRESSION
(dBm)
10.56
10.99
10.88
11.03
11.54
12.37
12.01
13.22
13.04
13.04
13.03
12.25
11.18
10.57
10.20
9.35
8.37
7.78
7.18
6.98
IP3
(dBm)
24.86
25.44
25.08
25.55
26.40
28.02
27.22
25.58
22.99
21.14
20.91
17.80
16.77
14.99
14.11
12.73
12.38
12.27
11.60
10.94
ZX60-14012L
NF
(dB)
------
5.21
4.83
5.03
5.04
4.72
4.79
4.93
4.90
5.00
5.02
5.23
5.35
5.75
5.77
5.86
5.95
5.96
6.15
6.19
14
12
10
ZX60-14012L
GAIN
10
9
8
7
6
5
4
3
2
1
0
ZX60-14012L
DIRECTIVITY
2.4
2.2
2.0
ZX60-14012L
VSWR
IN
OUT
6
4
2
0
0
2000
4000 6000 8000 10000 12000 14000
FREQUENCY (MHz)
0
2000
4000 6000 8000 10000 12000 14000
FREQUENCY (MHz)
VSWR
8
DIRECTIVITY (dB)
GAIN (dB)
1.8
1.6
1.4
1.2
1.0
0
2000
4000 6000 8000 10000 12000 14000
FREQUENCY (MHz)
14
ZX60-14012L
OUTPUT POWER AT 1dB COMPRESSION
7
ZX60-14012L
NOISE FIGURE
30
25
ZX60-14012L
IP3
OUTPUT POWER (dBm)
10
8
6
4
2
0
0
2000
4000 6000 8000 10000 12000 14000
FREQUENCY (MHz)
NOISE FIGURE (dB)
12
6
5
4
3
2
1
0
0
2000
4000 6000 8000 10000 12000 14000
FREQUENCY (MHz)
IP3 (dBm)
20
15
10
5
0
0
2000
4000 6000 8000 10000 12000 14000
FREQUENCY (MHz)
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
page 2 of 2
