Peaking Coils
ctparts.com
CT262LY Series
From 0.10 mH to 15 mH
ENGINEERING KIT #4 PAGE 90
Not shown at actual size.
Part
Number
CT262LY-101_
CT262LY-121_
CT262LY-151_
CT262LY-181_
CT262LY-221_
CT262LY-271_
CT262LY-331_
CT262LY-391_
CT262LY-471_
CT262LY-561_
CT262LY-681_
CT262LY-821_
CT262LY-102_
CT262LY-122_
CT262LY-152_
CT262LY-182_
CT262LY-222_
CT262LY-272_
CT262LY-332_
CT262LY-392_
CT262LY-472_
CT262LY-562_
CT262LY-682_
CT262LY-822_
CT262LY-103_
CT262LY-123_
CT262LY-153_
SPECIFICATIONS
Please specify tolerance code when ordering.
CT262LY-101_
J = ±5%, K = ±10%
Inductance
(mH)
.10
.12
.15
.18
.22
.27
.33
.39
.47
.56
.68
.82
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10.0
12.0
15.0
L Test
Freq.
(kHz)
796
796
796
796
796
796
796
796
796
796
796
796
252
252
252
252
252
252
252
252
252
252
252
252
79.6
79.6
79.6
Q
Fact.
Min.
60
60
60
60
60
60
60
60
60
60
60
60
80
80
80
80
80
80
80
80
80
80
80
80
60
60
60
Q Test
Freq.
(kHz)
796
796
796
796
796
796
796
796
796
796
796
796
252
252
252
252
252
252
252
252
252
252
252
252
79.6
79.6
79.6
SRF
Min.
(MHz)
6.1
5.5
5.0
4.7
4.5
4.1
3.8
3.5
3.2
2.9
2.7
2.3
2.1
1.9
1.8
1.6
1.5
1.4
.90
.90
.80
.70
.70
.60
.60
.50
.50
DCR
Max.
Ω
(Ω)
2.0
3.0
3.0
3.0
3.0
3.0
4.0
4.0
5.0
6.0
6.0
7.0
9.0
9.0
11
12
14
15
25
30
32
36
40
45
55
65
80
Rated
DC
(mA)
200
200
200
200
150
150
150
100
100
100
100
50
50
50
50
50
50
50
40
40
40
30
30
30
20
20
20
CHARACTERISTICS
Description:
Radial leaded (low profile) fixed inductor
Applications:
Ideal as a choke coil and a trap coil for low profile
equipment. Winding core is encapsulated in heat shrink plastic
housing providing mechanical and environmental protection
Temperature Coefficient:
440ppm / °C max.
Inductance Tolerance:
±5%, ±10%
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Packaging:
Bulk pack; packaged in styrofoam
Marking:
Sleeving marked with inductance code
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
Max.
6.2
0.24
A
Max.
8
0.32
B
Nom.
5
0.2
C
D
5
0.2
22 AWG
Nom.
0.643
0.03
Volume Manufacturer of Inductive Components
800-684-5322
Inside US
949-453-1811
Outside US
7.12.14.01
Copyright © 2002 by CT Magnetics. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice.
83
