MDD500-16N1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> MDD500-16N1

MDD500-16N1: DescriptionRectifier Diode, 1 Phase, 1 Element, 560A, 1600V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size340KB，3 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com; Environmental Compliance

Download Datasheet Parametric Compare View All

MDD500-16N1 Overview

Rectifier Diode, 1 Phase, 1 Element, 560A, 1600V V(RRM), Silicon,

MDD500-16N1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Littelfuse
Reach Compliance Code	compliant
Other features	UL RECOGNIZED
application	POWER
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	R-PUFM-X2
Maximum non-repetitive peak forward current	14400 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	140 °C
Minimum operating temperature	-40 °C
Maximum output current	560 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	1600 V
surface mount	NO
Terminal form	UNSPECIFIED
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

MDD500-16N1 Related Products

	MDD500-16N1	MDD500-20N1	MDD500-18N1	MDD500-22N1	MDD500-14N1	MDD500-12N1
Description	Rectifier Diode, 1 Phase, 1 Element, 560A, 1600V V(RRM), Silicon,	Rectifier Diode, 1 Phase, 1 Element, 560A, 2000V V(RRM), Silicon,	Rectifier Diode, 1 Phase, 1 Element, 560A, 1800V V(RRM), Silicon,	Rectifier Diode, 1 Phase, 1 Element, 560A, 2200V V(RRM), Silicon,	Rectifier Diode, 1 Phase, 1 Element, 560A, 1400V V(RRM), Silicon,	Rectifier Diode, 1 Phase, 1 Element, 560A, 1200V V(RRM), Silicon,
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant
Other features	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED	UL RECOGNIZED
application	POWER	POWER	POWER	POWER	POWER	POWER
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JESD-30 code	R-PUFM-X2	R-PUFM-X2	R-PUFM-X2	R-PUFM-X2	R-PUFM-X2	R-PUFM-X2
Maximum non-repetitive peak forward current	14400 A	14400 A	14400 A	14400 A	14400 A	14400 A
Number of components	1	1	1	1	1	1
Phase	1	1	1	1	1	1
Number of terminals	2	2	2	2	2	2
Maximum operating temperature	140 °C	140 °C	140 °C	140 °C	140 °C	140 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Maximum output current	560 A	560 A	560 A	560 A	560 A	560 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	1600 V	2000 V	1800 V	2200 V	1400 V	1200 V
surface mount	NO	NO	NO	NO	NO	NO
Terminal form	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
Terminal location	UPPER	UPPER	UPPER	UPPER	UPPER	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	-	1	1	1	1	1
package instruction	-	-	R-PUFM-X2	R-PUFM-X2	R-PUFM-X2	R-PUFM-X2
