CMX100D6-MS11

Description
Transistor Output SSR, 1-Channel, 2500V Isolation
CategoryLED optoelectronic/LED    photoelectric
File Size1MB,4 Pages
ManufacturerCrydom
Websitehttp://www.crydom.com/en/index.shtml
Download Datasheet Parametric Compare View All

CMX100D6-MS11 Overview

Transistor Output SSR, 1-Channel, 2500V Isolation

CMX100D6-MS11 Parametric

Parameter NameAttribute value
MakerCrydom
Reach Compliance Codeunknown
ConfigurationSINGLE
Maximum insulation voltage2500 V
Number of components1
Maximum on-state current6 A
Maximum on-state resistance0.04 Ω
Maximum operating temperature80 °C
Minimum operating temperature-30 °C
Optoelectronic device typesTRANSISTOR OUTPUT SSR

CMX100D6-MS11 Preview

Series CMX - MS11
6 -10 Amp • 0-100 Vdc • DC Output
DIN Rail Mount
(TS 35)
MOSFET Output
Extra Low On State
Resistance
Input Status LED
DC output SPST-NO solid state relays
use MOSFET output for high switching
capabilities in a DIN Rail (TS-35) mount
air-cooled package.
MODEL NO.
INPUT SPECIFICATIONS (1)
Control Voltage Range
Nominal Input Impedance
Typical Input Current @ 15 Vdc
Must Turn On Voltage
Must Turn Off Voltage
CMX
60
D
10-MS11
10-24 Vdc
300 Ohm
11 mAdc
3.0 Vdc
1.0 Vdc
CMX
100
D
6-MS11
10-24 Vdc
300 Ohm
11 mAdc
3.0 Vdc
1.0 Vdc
OUTPUT SPECIFICATIONS (1)(3)
Operating Voltage Range
Load Current Range
Max. Surge Current, (10 msec)
Max.Off-State Leakage
@ Rated Voltage
Max. On-State Resistance
@ Rated Current (R
DS-ON
)
Max. On-State Voltage Drop
@ Rated Current
Max.Turn-On Time @ 10Vdc Control
Max. Turn-Off TIme @ 10Vdc Control
0-60 Vdc
0-10 Adc
100 Apk
100 µAdc
.018 Ohm
0.18V
1.0 msec
300 µsec
0-100 Vdc
0-6 Adc
100 Apk
100 µAdc
.040 Ohm
0.24V
1.0 msec
300 µsec
© 2008 CRYDOM Inc, Specifications subject to change without notice.
GENERAL NOTES
(1) All parameters at 25 C unless otherwise specified.
º
(2)
D
ielectric and insulation resistance are
measured between input and output.
(3) Inductive loads should be diode suppressed.
(4) At 55 Vdc.
SERIES CMX-MS11.
Rev.
180608
PAGE
1
OF
4
For recommended applications and more information contact:
USA: Sales Support
(877) 502-5500
Tech Support
(877) 702-7700
FAX
(619) 710-8540
Crydom
Inc,
2320 Paseo de las Americas, Ste. 201, San Diego, CA 92154
Email:
sales@crydom.com
WEB SITE:
http://www.crydom.com
UK:
+44 (0)1202
606030
FAX
+44 (0)1202
606035 Crydom SSR Ltd., Arena Business Centre,
Holyrood Close, Poole, Dorset BH17 7FJ,
Email:
sales-europe@crydom.com, tech-europe@crydom.com
GERMANY:
+49 (0)180 3000 506
Series CMX - MS11
6 -10 Amp • 0-100 Vdc • DC Output
GENERAL SPECIFICATIONS
Dielectric Strength
(2)
Insulation Resistance (Min.) @ 500 Vdc
(2)
Max. Capacitance (Input/Output)
Ambient Operating Temperature Range
Ambient Storage Temperature Range
2500 Vrms
109 Ohm
15 pF
-30 to 80°C
-30 to 125°C
30 g
Thermally Conductive Epoxy
MECHANICAL SPECIFICATIONS
Weight: (typical)
Encapsulation(SSR):
CURRENT DERATING CURVES
7.0
6.0
LOAD CURRENT [AMPS]
CMX
100
D
6
CMX
60
D
5
CMX
200
D
3
CRYDOM
Solid State Relay
-A2 +A1
5.0
4.0
3.0
CMX Series
Input
54.0
Output
2.0
1.0
0
20
12.0
LOAD CURRENT [AMPS]
40
60
80
AMBIENT TEMPERATURE [°C]
10.0
8.0
6.0
4.0
2.0
0
20
40
60
80
AMBIENT TEMPERATURE [°C]
DIN Rail TS35
CMX
60
D
10
85.0
12.5
All dimensions are in millimeters (not to scale)
Colour of carrier including terminations - orange
©2008 CRYDOM Inc, Specifications subject to change without notice.
Max. Load Current vs. Temp.
GENERAL NOTES
(1) All parameters at 25º C unless otherwise specified.
(2)
D
ielectric and insulation resistance are
measured between input and output.
(3) Inductive loads should be diode suppressed.
(4) At 55 Vdc.
APPROVALS (SSR ONLY)
UL E116950 (6A & 10A Models)
SERIES CMX-MS
11
.
Rev.
180608
PAGE
2
OF
4
For recommended applications and more information contact:
USA: Sales Support
(877) 502-5500
Tech Support
(877) 702-7700
FAX
(619) 710-8540
Crydom
Inc,
2320 Paseo de las Americas, Ste. 201, San Diego, CA 92154
Email:
sales@crydom.com
WEB SITE:
http://www.crydom.com
UK:
+44 (0)1202
606030
FAX
+44 (0)1202
606035 Crydom SSR Ltd., Arena Business Centre,
Holyrood Close, Poole, Dorset BH17 7FJ,
Email
: sales-europe@crydom.com, tech-europe@crydom.com
GERMANY:
+49 (0)180 3000 506
29.0
DANGER / PELIGRO / DANGER /GEFAHR / PERICOLO / PERIGO
HAZARD OF
ELECTRIC
SHOCK,
EXPLOSION,
OR ARC FLASH.
Disconnect all
power before
installing or
working with
this equipment.
Verify all
connections
and replace all
covers before
turning on
power.
Failure to follow
these
instructions will
result in death
or serious injury.
RIESGO DE
DESCARGA
ELECTRICA O
EXPLOSION.
Desconectar
todos los
suministros de
energia a este
equipo antes
de trabajar
con este equipo.
Verificar todas
las conexiones
y colocar todas
las tapas antes
de energizer
el equipo.
El
incumplimiento
de estas
instrucciones
puede provocar
la muerte o
lesiones serias.
RISQUE DE
DESCHARGE
ELECTRIQUE
OU EXPLOSION
Eteindre
toutes les
sources
d'énergie de
cet appareil
avant de
travailler
dessus de cet
appareil
Vérifier tous
connections, et
remettre tous
couverts en
olace avant de
mettre sous
De non-suivi de
ces instructions
provoquera la
mort ou des
lésions sérieuses
sérieuses.
GEFAHR EINES
ELEKTRISCHE
N SCHLAGES
ODER EINER
EXPLOSION.
Stellen Sie
jeglichen
Strom ab, der
dieses Gerät
versorgt, bevor
Sie an dem
Gerät Arbeiten
durchführen
Vor dem
Drehen auf
Energie alle
Anschlüsse
überprüfen
und alle
Abdeckungen
ersetzen.
Unterlassung
dieser
Anweisungen
können zum
Tode oder zu
schweren
Verletzungen
führen.
RISCHIO DI
SCOSSA
ELETTRICA O
DELL’ESPLOSI
ONE.
Spenga tutta
l'alimentazion
e che fornisce
questa
apparecchiatu
ra prima del
lavorare a questa
apparecchiatu ra
Verificare tutti
i collegamenti
e sostituire
tutte le coperture
prima della
rotazione
sull'alimentazi one
L'omissione di
seguire queste
istruz ioni
provocherà la
morte o di
lesioni serie
RISCO DE
DESCARGA
ELÉTTRICA OU
EXPLOSÃO
Desconectar
o equipamento
de toda á
energia antes
de instalar ou
trabalhar com
este equipamen
to
Verificar todas
as conexões e
recolocar todas
as tampas
antes de religar
o equipamento
O não cumprimento
destas instruções
pode levar á morte
ou lesões sérias.
WARNING / AVERTISSEMENT / WARNUNG /ADVERTENCIA / AVVERTENZA / AVISO
RISK OF MATERIAL DAMAGE AND HOT
ENCLOSURE
The product's side panels may be hot, allow
time for product to cool before touching.
Follow proper mounting instructions including
torque values.
Do not allow liquids or foreign objects to enter
this product.
Failure to follow this instruction can result in
serious injury, or equipment damage.
RISQUE DE DOMMAGE MATERIEL ET DE
SURCHAUFFE DU BOITIER
Les panneaux latéraux du produit peuvent être
chauds. Laisser le produit refroidir avant de le
toucher.
Respecter les consignes de montage, et
notamment les couples de serrage.
Ne pas laisser pénétrer de liquide ni de corps
étrangers à l'intérieur du produit.
Le non-respect de cette directive peut entraîner,
des lésions corporelles graves ou des
dommages matériels.
GEFAHR VON MATERIALSCHÄDEN UND
GEHÄUSEERHITZUNG
Die Seitenwände können heiß sein. Lassen Sie
das Produkt abkühlen, bevor Sie es berühren.
Beachten Sie die Montageanweisungen,
Führen Sie keine Flüssigkeiten oder
Fremdkörper in das Produkt ein.
Die Nichtbeachtung dieser Anweisung kann
Körperverletzung oder Materialschäden
zur Folge haben.
RIESGO DE DAÑOS MATERIALES Y DE
SOBRECALENTAMIENTO DE LA UNIDAD
Los paneles laterales del producto pueden
estar calientes. Esperar que el producto se
enfríe antes de tocarlo.
Respetar las instrucciones de montaje, y en
particular los pares de apretado.
No dejar que penetren líquidos o cuerpos
extraños en el producto.
Si no se respetan estas precauciones pueden
producirse graves lesiones, daños materiales.
RISCHIO DI DANNI MATERIALI E D'INVOLUCRO
CALDO
I pannelli laterali dell'apparecchio possono
scottare; lasciar quindi raffreddare il prodotto
prima di toccarlo.
Seguire le istruzioni di montaggio corrette.
Non far entrare liquidi o oggetti estranei in questo
apparecchio.
La mancata osservanza di questa precauzione può
causare gravi rischi per l'incolumità personale o
danni alle apparecchiature.
RISCO DE DANO MATERIAL E DE AQUECIMENTO
Os painéis laterais do produto podem estar
quentes; dê tempo ao produto para arrefecer
antes de lhe tocar.
Siga devidamente as instruções de montagem.
Não permita a entrada de líquidos e de objectos
estranhos no produto.
A não observância destas precauções pode
provocar a morte, ferimentos graves ou
danos materiais.
SERIES CX-B.
Rev. 102607
PAGE 2 OF 2
ANNEX – ENVIRONMENTAL INFORMATION:
The environmental information disclosed in this annex including the EIP
Pollution logo are in compliance with People’s Republic of China Electronic
Industry Standard SJ/T11364 – 2006, Marking for Control of Pollution
Caused by Electronic Information Products.
Part
Name
Toxic or hazardous Substance and Elements
Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated
(Pb) (Hg)
(Cd)
Chromium
biphenyls
diphenyl ethers
(Cr (VI))
(PBB)
(PBDE)
X
X
O
O
O
O
O
O
O
O
O
O
Semiconductor
die
Solder
-
:
SJ/T11364 - 2006,
(Pb)
X
X
(Hg)
O
O
(Cd)
O
O
(Cr (VI))
O
O
(PBB)
O
O
(PBDE)
O
O
© 2007 CRYDOM Inc., Specifications subject to change without notice.

CMX100D6-MS11 Related Products

CMX100D6-MS11 CMX60D10-MS11
Description Transistor Output SSR, 1-Channel, 2500V Isolation Transistor Output SSR, 1-Channel, 2500V Isolation
Maker Crydom Crydom
Reach Compliance Code unknown unknown
Configuration SINGLE SINGLE
Maximum insulation voltage 2500 V 2500 V
Number of components 1 1
Maximum on-state current 6 A 10 A
Maximum on-state resistance 0.04 Ω 0.018 Ω
Maximum operating temperature 80 °C 80 °C
Minimum operating temperature -30 °C -30 °C
Optoelectronic device types TRANSISTOR OUTPUT SSR TRANSISTOR OUTPUT SSR
Impact of Antenna and Feeder System Mismatch on Mobile Communications and Its Solutions
The impact of antenna feed system mismatch on mobile communication and its solution The antenna feed system is an important part of the mobile communication system, and its performance is crucial to t...
xtss RF/Wirelessly
Looking for a program to send multi-byte data to a microcontroller, waiting for experts online!
As the title says: Continuously send data: 01 (start bit) 31 (local address) #0A (control command word) __ __ __ (data) 06 (end bit)...
pangxie Embedded System
Make a suggestion to the forum
Can you add a function to query my replies? I often see good things on the forum and reply to them. If you add this function, it will be much easier to find this post in the future....
飞雪008 Suggestions & Announcements
How to use J-LINK to download files to 2410's NAND FLASH
I bought a J-LINK V7 emulator from the Internet, and downloaded the latest driver software from [url=http://www.segger.com/download_jlink.html]http://www.segger.com/download_jlink.html[/url]. After in...
青叶漂零 Embedded System
【NIOS】Advantages of ARM over NIOS
Reason 1: ARM does not make chips, but puts all its energy into the core development, achieving "specialization";people familiar with the ARM architecture know that the ARM core is clearly classified,...
火雨木头 ARM Technology
Huawei Honor Sounding Elf Unboxing
The gift from my friend just arrived on Christmas Day, so I unboxed it to find out what it is.I thought it could monitor formaldehyde, but it turned out to be TVOC. What is TVOC? I don't know. From Ba...
eric_wang Making friends through disassembly

EEWorld
subscription
account

EEWorld
service
account

Automotive
development
circle

Robot
development
community

Index Files: 2564  485  2111  409  1163  52  10  43  9  24
Datasheet   0 1 2 3 4 5 6 7 8 9 A B C D E F G H I J K L M N O P Q R S T U V W X Y Z
Room 1530, 15th Floor, Building B, No. 18 Zhongguancun Street, Haidian District, Beijing Telephone: (010) 82350740 Postal Code: 100190
Copyright © 2005-2026 EEWORLD.com.cn, Inc. All rights reserved 京ICP证060456号 京ICP备10001474号-1 电信业务审批[2006]字第258号函 京公网安备 11010802033920号
