2SB1558-A

Description
TRANSISTOR 8 A, 140 V, PNP, Si, POWER TRANSISTOR, 2-16C1A, 3 PIN, BIP General Purpose Power
CategoryDiscrete semiconductor    The transistor
File Size201KB,4 Pages
ManufacturerToshiba Semiconductor
Websitehttp://toshiba-semicon-storage.com/
Download Datasheet Parametric Compare View All

2SB1558-A Overview

TRANSISTOR 8 A, 140 V, PNP, Si, POWER TRANSISTOR, 2-16C1A, 3 PIN, BIP General Purpose Power

2SB1558-A Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
package instructionFLANGE MOUNT, R-PSFM-T3
Contacts3
Reach Compliance Codeunknow
ECCN codeEAR99
Shell connectionCOLLECTOR
Maximum collector current (IC)8 A
Collector-emitter maximum voltage140 V
ConfigurationDARLINGTON WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)5000
JESD-30 codeR-PSFM-T3
Number of components1
Number of terminals3
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Polarity/channel typePNP
Maximum power consumption environment80 W
Maximum power dissipation(Abs)80 W
Certification statusNot Qualified
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
Nominal transition frequency (fT)30 MHz
VCEsat-Max2.5 V
Base Number Matches1
2SB1558
TOSHIBA Transistor Silicon PNP Epitaxial Type (Darlington Power Transistor)
2SB1558
Power Amplifier Applications
Unit: mm
High breakdown voltage: V
CEO
=
−140
V (min)
Complementary to 2SD2387
Maximum Ratings
(Tc = 25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
(Tc = 25°C)
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
−140
−140
−5
−8
−0.1
80
150
−55
to 150
Unit
V
V
V
A
A
W
°C
°C
JEDEC
JEITA
2-16C1A
Equivalent Circuit
COLLECTOR
TOSHIBA
Weight: 4.7 g (typ.)
BASE
100
EMITTER
Electrical Characteristics
(Tc = 25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE (1)
DC current gain
(Note)
h
FE (2)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE (sat)
V
BE
f
T
C
ob
Test Condition
V
CB
=
−140
V, I
E
= 0
V
EB
=
−5
V, I
C
= 0
I
C
=
−50
mA, I
B
= 0
V
CE
=
−5
V, I
C
=
−7
A
V
CE
=
−5
V, I
C
=
−12
A
I
C
=
−7
A, I
B
=
−7
mA
V
CE
=
−5
V, I
C
=
−7
A
V
CE
=
−5
V, I
C
=
−1
A
V
CB
=
−10
V, I
E
= 0, f = 1 MHz
Min
−140
5000
2000
Typ.
30
170
Max
−5.0
−5.0
30000
−2.5
−3.0
V
V
MHz
pF
Unit
µA
µA
V
Note: h
FE (1)
classification
A: 5000 to 12000, B: 9000 to 18000, C: 15000 to 30000
1
2004-07-07

2SB1558-A Related Products

2SB1558-A 2SB1558-C 2SB1558-B
Description TRANSISTOR 8 A, 140 V, PNP, Si, POWER TRANSISTOR, 2-16C1A, 3 PIN, BIP General Purpose Power TRANSISTOR 8 A, 140 V, PNP, Si, POWER TRANSISTOR, 2-16C1A, 3 PIN, BIP General Purpose Power TRANSISTOR 8 A, 140 V, PNP, Si, POWER TRANSISTOR, 2-16C1A, 3 PIN, BIP General Purpose Power
Is it Rohs certified? incompatible incompatible incompatible
package instruction FLANGE MOUNT, R-PSFM-T3 2-16C1A, 3 PIN FLANGE MOUNT, R-PSFM-T3
Contacts 3 3 3
Reach Compliance Code unknow unknow unknow
ECCN code EAR99 EAR99 EAR99
Shell connection COLLECTOR COLLECTOR COLLECTOR
Maximum collector current (IC) 8 A 8 A 8 A
Collector-emitter maximum voltage 140 V 140 V 140 V
Configuration DARLINGTON WITH BUILT-IN RESISTOR DARLINGTON WITH BUILT-IN RESISTOR DARLINGTON WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE) 5000 15000 9000
JESD-30 code R-PSFM-T3 R-PSFM-T3 R-PSFM-T3
Number of components 1 1 1
Number of terminals 3 3 3
Maximum operating temperature 150 °C 150 °C 150 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR
Package form FLANGE MOUNT FLANGE MOUNT FLANGE MOUNT
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Polarity/channel type PNP PNP PNP
Maximum power consumption environment 80 W 80 W 80 W
Maximum power dissipation(Abs) 80 W 80 W 80 W
Certification status Not Qualified Not Qualified Not Qualified
surface mount NO NO NO
Terminal form THROUGH-HOLE THROUGH-HOLE THROUGH-HOLE
Terminal location SINGLE SINGLE SINGLE
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
transistor applications AMPLIFIER AMPLIFIER AMPLIFIER
Transistor component materials SILICON SILICON SILICON
Nominal transition frequency (fT) 30 MHz 30 MHz 30 MHz
VCEsat-Max 2.5 V 2.5 V 2.5 V
Base Number Matches 1 1 1
