2SK3670
TOSHIBA Field Effect Transistor Silicon N Channel MOS Type (π−MOSV)
2SK3670
Chopper Regulator and DC−DC Converter Applications
2.5V-Gate Drive
Low drain-source ON-resistance: R
DS (ON)
= 1.0
Ω
(typ.)
High forward transfer admittance: |Y
fs
| = 2.1 S (typ.)
Low leakage current: I
DSS
= 100
μA
(max) (V
DS
= 150 V)
Enhancement mode: V
th
= 0.5 to 1.3 V (V
DS
= 10 V, I
D
=200
μA)
Unit: mm
Absolute Maximum Ratings
(Ta = 25°C)
Characteristics
Drain−source voltage
Drain−gate voltage (R
GS
= 20 kΩ)
Gate−source voltage
DC
Drain current
(Note 1)
(Note 1)
Pulse
Drain power dissipation
Single pulse avalanche energy
(Note 2)
Avalanche current
Repetitive avalanche energy
Channel temperature
Storage temperature range
(Note 3)
(Note 1)
Symbol
V
DSS
V
DGR
V
GSS
I
D
I
DP
I
DP
P
D
E
AS
I
AR
E
AR
T
ch
T
stg
Rating
150
150
±12
0.67
1
3
0.9
41
0.67
0.09
150
−55
to 150
W
mJ
A
mJ
°C
°C
A
Unit
V
V
V
Pulse (t
≤
5s)
JEDEC
JEITA
TOSHIBA
TO-92MOD
—
2-5J1C
Weight: 0.36 g (typ.)
Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage and the
significant change in temperature, etc.) may cause this product to decrease in the reliability significantly even
if the operating conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum
ratings.Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability
Handbook (“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e.
reliability test report and estimated failure rate, etc).
Thermal Characteristics
Characteristics
Thermal resistance, channel to ambient
Symbol
R
th (ch−a)
Max
138
Unit
°C / W
3
2
Note 1: Ensure that the channel temperature does not exceed 150℃.
Note 2: V
DS
= 50V、T
ch
= 25°C(initial)、L = 135mH、I
AR
= 0.67A、R
G
= 25Ω
Note 3: Repetitive rating: pulse width limited by maximum channel temperature
This transistor is an electrostatic-sensitive device. Please handle with caution.
1
1
2009-12-21
2SK3670
Electrical Characteristics
(Ta = 25°C)
Characteristics
Gate leakage current
Drain cut−off current
Drain−source breakdown voltage
Gate threshold voltage
Drain−source ON-resistance
Forward transfer admittance
Input capacitance
Reverse transfer capacitance
Output capacitance
Rise time
Symbol
I
GSS
I
DSS
V
(BR) DSS
V
th
R
DS (ON)
|Y
fs
|
C
iss
C
rss
C
oss
t
r
5V
V
GS
0V
Turn−on time
Switching time
Fall time
t
f
V
DD
≈
75 V
t
on
50
Ω
R
L
=150 Ω
—
40
—
ns
—
23
—
I
D
=
0.5 A
OUT
V
DS
= 10 V, V
GS
= 0 V, f = 1 MHz
Test Condition
V
GS
= ±9.6 V, V
DS
= 0 V
V
DS
= 150 V, V
GS
= 0 V
I
D
= 10 mA, V
GS
= 0 V
V
DS
= 10 V, I
D
=200μA
V
GS
= 2.5 V, I
D
= 0.5 A
V
GS
= 4 V, I
D
= 0.5 A
V
DS
= 10 V, I
D
= 0.5 A
Min
—
—
150
0.5
—
—
1.0
—
—
—
—
Typ.
—
—
—
—
1.1
1.0
2.1
230
14
50
16
Max
±10
100
—
1.3
2
1.7
—
—
—
—
—
pF
Unit
μA
μA
V
V
Ω
S
Turn−off time
Total gate charge (gate−source
plus gate−drain)
Gate−source charge
Gate−drain (“miller”) Charge
t
off
Q
g
Q
gs
Q
gd
Duty
≤
1%, t
w
=
10
μs
—
—
95
4.6
2.9
1.7
—
—
—
—
nC
V
DD
≈
120 V, V
GS
= 5 V, I
D
= 1 A
—
—
Source−Drain Ratings and Characteristics
(Ta = 25°C)
Characteristics
Continuous drain reverse current
(Note 1)
Pulse drain reverse current (t=5s)
(Note 1)
Pulse drain reverse current
(Note 1)
Forward voltage (diode)
Reverse recovery time
Reverse recovery charge
Symbol
I
DR
I
DRP
I
DRP
V
DSF
t
rr
Q
rr
Test Condition
—
—
—
I
DR
= 0.5 A, V
GS
= 0 V
I
DR
= 1A, V
GS
= 0V
dI
DR
/ dt = 50A /
μs
Min
—
—
—
—
—
—
Typ.
—
—
—
—
95
110
Max
0.67
1
3
−1.5
—
—
Unit
A
A
A
V
ns
nC
Marking
K3670
Part No. (or abbreviation code)
Lot No.
Note 4
Note 4: A line under a Lot No. identifies the indication of product
Labels.
[[G]]/RoHS COMPATIBLE or [[G]]/RoHS [[Pb]]
Please contact your TOSHIBA sales representative for details as to
environmental matters such as the RoHS compatibility of Product.
The RoHS is the Directive 2002/95/EC of the European Parliament
and of the Council of 27 January 2003 on the restriction of the use of
certain hazardous substances in electrical and electronic equipment.
2
2009-12-21
