2SC4542 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> 2SC4542

2SC4542: DescriptionTRANSISTOR 10 A, 600 V, NPN, Si, POWER TRANSISTOR, BIP General Purpose Power; CategoryDiscrete semiconductor The transistor; File Size51KB，1 Pages; ManufacturerToshiba Semiconductor; Websitehttp://toshiba-semicon-storage.com/

Download Datasheet Parametric Compare View All

2SC4542 Overview

TRANSISTOR 10 A, 600 V, NPN, Si, POWER TRANSISTOR, BIP General Purpose Power

2SC4542 Parametric

Parameter Name	Attribute value
package instruction	FLANGE MOUNT, R-PSFM-T3
Reach Compliance Code	unknow
Shell connection	ISOLATED
Maximum collector current (IC)	10 A
Collector-emitter maximum voltage	600 V
Configuration	SINGLE
Minimum DC current gain (hFE)	8
JESD-30 code	R-PSFM-T3
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Polarity/channel type	NPN
Certification status	Not Qualified
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	3 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

2SC4542 Related Products

	2SC4542	2SD1088	2SC4531	HN3GO1J	TC7W125U	TC4F71F
Description	TRANSISTOR 10 A, 600 V, NPN, Si, POWER TRANSISTOR, BIP General Purpose Power	TRANSISTOR 6 A, 250 V, NPN, Si, POWER TRANSISTOR, TO-220AB, BIP General Purpose Power	TRANSISTOR 10 A, 600 V, NPN, Si, POWER TRANSISTOR, BIP General Purpose Power	TRANSISTOR N-CHANNEL, Si, SMALL SIGNAL, JFET, SUPERMINI-5, FET General Purpose Small Signal	IC HC/UH SERIES, QUAD 1-BIT DRIVER, TRUE OUTPUT, PDSO8, SMT-8, Bus Driver/Transceiver	IC 2-INPUT NOR GATE, PDSO5, Gate
package instruction	FLANGE MOUNT, R-PSFM-T3	FLANGE MOUNT, R-PSFM-T3	FLANGE MOUNT, R-PSFM-T3	SMALL OUTLINE, R-PDSO-X5	SOP,	LSSOP,
Reach Compliance Code	unknow	unknow	unknow	unknown	unknown	unknow
JESD-30 code	R-PSFM-T3	R-PSFM-T3	R-PSFM-T3	R-PDSO-X5	R-PDSO-G8	R-PDSO-G5
Number of terminals	3	3	3	5	8	5
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	NO	NO	NO	YES	YES	YES
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	UNSPECIFIED	GULL WING	GULL WING
Terminal location	SINGLE	SINGLE	SINGLE	DUAL	DUAL	DUAL
Configuration	SINGLE	DARLINGTON WITH BUILT-IN RESISTOR	SINGLE WITH BUILT-IN DIODE AND RESISTOR	SINGLE WITH BUILT-IN BIPOLAR TRANSISTOR	-	-
Number of components	1	1	1	1	-	-
Polarity/channel type	NPN	NPN	NPN	N-CHANNEL	-	-
Transistor component materials	SILICON	SILICON	SILICON	SILICON	-	-
Base Number Matches	1	1	1	1	-	-
