2SA562TM
TOSHIBA Transistor
Silicon PNP Epitaxial Type (PCT process)
2SA562TM
Audio Frequency Low Power Amplifier Applications
Driver Stage Amplifier Applications
Switching Applications
•
•
•
Excellent h
FE
linearity: h
FE (2)
= 25 (min)
at V
CE
=
−6
V, I
C
=
−400
mA
1 watt amplifier application.
Complementary to 2SC1959.
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature range
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
Rating
−35
−30
−5
−500
−100
500
150
−55~150
Unit
V
V
V
mA
mA
mW
°C
°C
JEDEC
JEITA
TOSHIBA
TO-92
SC-43
2-5F1B
Note: Using continuously under heavy loads (e.g. the application of high
Weight: 0.21 g (typ.)
temperature/current/voltage and the significant change in
temperature, etc.) may cause this product to decrease in the reliability significantly even if the operating
conditions (i.e. operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Collector cut-off current
Emitter cut-off current
Symbol
I
CBO
I
EBO
h
FE (1)
DC current gain
(Note)
h
FE (2)
(Note)
Collector-emitter saturation voltage
Base-emitter voltage
Transition frequency
Collector output capacitance
V
CE (sat)
V
BE
f
T
C
ob
Test Condition
V
CB
= −35
V, I
E
=
0
V
EB
= −5
V, I
C
=
0
V
CE
= −1
V, I
C
= −100
mA
V
CE
= −6
V, I
C
= −400
mA
I
C
= −100
mA, I
B
= −10
mA
V
CE
= −1
V, I
C
= −100
mA
V
CE
= −6
V, I
C
= −20
mA
V
CB
= −6
V, I
E
=
0, f
=
1 MHz
Min
⎯
⎯
70
Typ.
⎯
⎯
⎯
Max
−0.1
−0.1
240
Unit
μA
μA
25
⎯
⎯
⎯
⎯
⎯
−0.1
−0.8
200
13
⎯
−0.25
−1.0
⎯
⎯
V
V
MHz
pF
Note: h
FE (1)
classification O: 70~140, Y: 120~240
h
FE (2)
classification O: 25 (min), Y: 40 (min)
1
2007-11-01
2SA562TM
