Specification
BT45231
BTHQ240064AVB1-EMN-06-LEDWHITE-COG
Doc. No.:
COG-BT240064-34
Version December 2010
DOCUMENT REVISION HISTORY
DOCUMENT
REVISION
FROM
TO
DATE
DESCRIPTION
CHANGED CHECKED
BY
BY
ZHU YANG
NA
A 2010.12.02 First Release.
JIN YOU
PING
2
CONTENTS
Page No.
1.
2.
3.
4.
4.1
4.2
5.
5.1
5.2
5.3
6.
7.
7.1
8.
9.
GENERAL DESCRIPTION
MECHANICAL SPECIFICATIONS
INTERFACE SIGNALS
ABSOLUTE MAXIMUM RATINGS
ELECTRICAL MAXIMUM RATINGS -FOR IC ONLY
ENVIRONMENTAL CONDITION
ELECTRICAL SPECIFICATIONS
TYPICAL ELECTRICAL CHARACTERISTICS
TIMING SPECIFICATIONS
COMMAND TABLE
LCD SPECIFICATIONS
ELECTRO-OPTICAL CHARACTERISTICS
OPTICAL CHARACTERISTICS DEFINITION
LCD COSMETIC CONDITIONS
REMARK
4
4
8
10
10
11
12
12
13
14
16
25
26
27
27
3
Specification
of
LCD Module Type
Model No.: COG-BT240064-34
1.
•
•
•
•
•
•
•
•
2.
General Description
240 x 64 Dots STN , Negative ,blue , Transmissive Dot Matrix LCD Module.
Viewing angle: 6 o’clock.
Driving scheme: 1/65 duty, 1/7 bias.
‘SITRONIX’ ST7565P (COG) 2PCS Dot Matrix LCD Drivers or equivalent.
Logic voltage: 3V.
FPC connection.
White LED05 backlight.
“RoHS” compliance.
Mechanical Specifications
The mechanical detail is shown in Fig. 1 and summarized in Table 1 below.
Table 1
Parameter
Outline dimensions
Viewing area
Active area
Display format
Dot size
Dot spacing
Dot pitch
Weight
Specifications
120.0(W) x 194.82(H) x 5.5(D) (Included FPC)
(Excluded housing & cable of backlight)
102.4(W) x 30.22(H)
98.38(W) x 26.22(H)
240 x 64 Dots
0.39(W) x 0.39(H)
0.02(W) x 0.02(H)
0.41(W) x 0.41(H)
Approx: 42
Unit
mm
mm
mm
dots
mm
mm
mm
gram
4
Figure 1: Module Specification
B 421
T 53
B H 2 0 6 A B -MN 0 -E WHT - O
T Q 4 0 4 V 1E -6L D IEC G
5
