36401E22NJ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> inductor> 36401E22NJ

36401E22NJ: Description1 ELEMENT, 2.55uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0402, ROHS COMPLIANT; CategoryPassive components inductor; File Size144KB，5 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

36401E22NJ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	36401E22NJ	-	-	View	Buy Now

36401E22NJ Overview

1 ELEMENT, 2.55uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0402, ROHS COMPLIANT

36401E22NJ Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1646065966
package instruction	0402
Reach Compliance Code	compliant
ECCN code	EAR99
Samacsys Manufacturer	TE Connectivity
Samacsys Modified On	2018-05-11 09:59:22
YTEOL	6.2
uppercase and lowercase codes	0402
DC Resistance	2.65 Ω
Nominal inductance(L)	0.022 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
Number of functions	1
Number of terminals	2
method of packing	TR
Minimum quality factor (at nominal inductance)	13
Maximum rated current	0.09 A
self resonant frequency	2500 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Tolerance	5%

Preview

Download Datasheet

View All

High Frequency Inductors SMD

Type 3640 Series

Key Features

Low Inductor Values

Low DC Resistance

High Q Factor

High Self Resonant

Frequency

Suitable for Reflow

Solder

Lab Kits Available

The 3640 series is an innovative thin film chip inductor designed for high frequency

application in the communications industry. This inductor combines very small size (to 02:01)

with a robustness and durability only previously seen in moulded parts.

Available in values down to 0.2 nanohenry and packaged in 5 standard sizes, this is the

perfect solution for your design requirements. Available via our distribution network.

Characteristics - Electrical - 0201 Package

Inductance

(nH)

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

1.1

1.2

1.3

1.4

1.5

1.6

1.7

1.8

1.9

2.1

2.2

2.3

2.4

2.5

2.6

2.7

2.8

2.9

3.1

3.2

3.3

3.4

Inductance

Tolerance

(% or nH)

±0.1/0.2/0.3 nH

0.1/0.2/0.3 nH

Quality

Factor

(Min)

Measuring

Frequency

(MHz)

500

Resistance

DC/Max.

(Ohm)

0.20

0.25

0.30

0.3

0.35

0.45

0.55

0.7

0.8

1.2

Current

DC/Max.

(mA)

400

350

300

250

200

150

Self Resonant

Frequency/Min.

(GHz)

1773162 CIS WR 03/2012

Dimensions are in millimeters

and inches unless otherwise

specified. Values in brackets

are standard equivalents.

Dimensions are shown for

reference purposes only.

Specifications subject

to change.

For email, phone or live chat, go to:

te.com/help

36401E22NJ Related Products

	36401E22NJ	36401E2N2ATDF	36401E8N2ATDF	LM1084_15	36401E0N4ATDF	36401E1N2ATDF	36401E1N6ATDF	36401E8N0ATDF	36401E0N8ATDF	36401E1N1ATDF
Description	1 ELEMENT, 2.55uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0402, ROHS COMPLIANT	3640 0402 2.2nH +/-0.2nH 1K RL	3640 0402 8.2nH +/-0.2nH 1K RL	LM1084 5-A Low Dropout Positive Regulators	3640 0402 0.4nH +/-0.2nH 1K RL	3640 0402 1.2nH +/-0.2nH 1K RL	3640 0402 1.6nH +/-0.2nH 1K RL	3640 0402 8.0nH +/-0.2nH 1K RL	3640 0402 0.8nH +/-0.2nH 1K RL	3640 0402 1.1nH +/-0.2nH 1K RL
Inductor type	GENERAL PURPOSE INDUCTOR	high frequency	high frequency	-	high frequency	high frequency	high frequency	high frequency	high frequency	high frequency
shield	NO	no	no	-	no	no	no	no	no	no
Tolerance	5%	.2%	.2%	-	.2%	.2%	.2%	.2%	.2%	.2%
Component type	-	thin film	thin film	-	thin film	thin film	thin film	thin film	thin film	thin film
size code	-	0402	0402	-	0402	0402	0402	0402	0402	0402
Inductance (µH)	-	.0022	.0082	-	.0004	.0012	.0016	.008	.0008	.0011
Rated current (max) (mA)	-	440	220	-	800	700	560	220	700	700
DC resistance (Ω)	-	.35	1.25	-	.1	.15	.25	1.25	.15	.15
Self-resonant frequency (GHz)	-	8	5.5	-	14	12	10	5.5	14	12
Lead type	-	surface mount terminals	surface mount terminals	-	surface mount terminals	surface mount terminals	surface mount terminals	surface mount terminals	surface mount terminals	surface mount terminals
Installation method	-	surface mount	surface mount	-	surface mount	surface mount	surface mount	surface mount	surface mount	surface mount
Dimensions (mm)	-	1 x .5 x .32	1 x .5 x .32	-	1 x .5 x .32	1 x .5 x .32	1 x .5 x .32	1 x .5 x .32	1 x .5 x .32	1 x .5 x .32
Encapsulation method	-	stick and roll	stick and roll	-	stick and roll	stick and roll	stick and roll	stick and roll	stick and roll	stick and roll
Quality factor	-	13	13	-	13	13	13	13	13	13
Comment	-	Tolerance .2nH.	Tolerance .2nH.	-	Tolerance .2nH.	Tolerance .2nH.	Tolerance .2nH.	Tolerance .2nH.	Tolerance .2nH.	Tolerance .2nH.
