NPH10 Series
Input
Voltage
18-36 V
10 Watts Single Output
Output
Voltage
3.4 V
5.1 V
12.1 V
15.1 V
3.4 V
5.1 V
12.1 V
15.1 V
Output
Current
2.94 A
1.96 A
0.83 A
0.67 A
2.94 A
1.96 A
0.83 A
0.67 A
Efficiency
79%
83%
86%
86%
80%
83%
86%
87%
Model
Number
NPH10S2403i
NPH10S2405i
NPH10S2412i
NPH10S2415i
NPH10S4803i
NPH10S4805i
NPH10S4812i
NPH10S4815i
36-75 V
For optional SS & ADJ, prefix the ending ‘i’ with an ‘E’ e.g. NPH10S2403Ei.
Input
●
Input Range
See Table
±0.5%
±10%
10%
0.1% over input range
0.5% max
250 ppm/°C max
70 mV rms typical
Continuous
-40 °C to 110 °C case temperature
-40 °C to 125 °C case temperature
1500 V DC (flash tested for 1 sec)
350 kHz typ (330-395 kHz max range)
300 °C/10 s 1.5 mm from case
Leave open circuit for normal operation
320-440 kHz synchronized to drive signal
UL recognised UL1950 E179522
Output
●
Voltage Accuracy
●
Voltage Trimming (ADJ)
(Option -E)
●
Minimum load
●
Line Regulation
●
Load Regulation
(10-100%)
●
Temperature Coefficient
●
Ripple & Noise
(20 MHz Bandwidth)
●
Short Circuit Duration
General
●
●
●
●
●
●
●
Operating Temperature
Storage Temperature
Isolation
Switching Frequency
Lead Temperature
Output Voltage Control Pin
Synchronisation (SS)
(Option -E)
●
Safety Approvals
NOTES:
All dimensions in inches (mm) ±0.01 (±0.25).
Weight : 22 g
*Optional pins.
All pins on a 0.10 (2.54) pitch and within ±0.01 (±0.25) of true pin pitch position.
