PRELIMINARY DATA SHEET
LASER DIODE
NX8567SA Series
EA MODULATOR AND WAVELENGTH MONITOR INTEGRATED
1 550 nm MQW-DFB LASER DIODE MODULE FOR
2.5 Gb/s DWDM ULTRALONG-REACH 240 km, 360 km, 600 km APPLICATIONS
DESCRIPTION
The NX8567SA Series is an Electro-Absorption (EA) modulator and
wavelength monitor integrated, 1 550 nm Multiple Quantum Well (MQW)
structured Distributed Feed-Back (DFB) laser diode module. The module is
capable of 2.5 Gb/s applications of over 240 km, 360 km, 600 km ultralong-
reach and available for Dense Wavelength Division Multiplexing (DWDM)
wavelengths based on ITU-T recommendations, enabling a wide range of
applications.
FEATURES
• Integrated electroabsorption modulator
• Wavelength monitor function (Etalon filter, Wavelength monitor PD)
• Very low dispersion penalty (over 240 km (4320 ps/nm), NX8567SAS Series)
(over 360 km (6480 ps/nm), NX8567SAM Series)
(over 600 km (10800 ps/nm), NX8567SA Series)
• Low modulation voltage
• Available for DWDM wavelengths based on ITU-T recommendations
(50 GHz grid, refer to
ORDERING INFORMATION)
The information in this document is subject to change without notice. Before using this document, please confirm that
this is the latest version.
Not all devices/types available in every country. Please check with local NEC Compound Semiconductor Devices
representative for availability and additional information.
Document No. PL10185EJ01V0DS (1st edition)
Date Published May 2003 CP(K)
Printed in Japan
©
NEC Compound Semiconductor Devices 2003
