UPD23C16000WG5-XXX-7JF: DescriptionIC,ROM,1MX16/2MX8,CMOS,TSOP,44PIN,PLASTIC; Categorystorage storage; File Size623KB，19 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

UPD23C16000WG5-XXX-7JF Overview

IC,ROM,1MX16/2MX8,CMOS,TSOP,44PIN,PLASTIC

UPD23C16000WG5-XXX-7JF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Reach Compliance Code	unknown
Maximum access time	120 ns
Spare memory width	8
JESD-30 code	R-PDSO-G44
JESD-609 code	e0
memory density	16777216 bit
Memory IC Type	MASK ROM
memory width	16
Number of terminals	44
word count	1048576 words
character code	1000000
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
organize	1MX16
Package body material	PLASTIC/EPOXY
encapsulated code	TSOP
Encapsulate equivalent code	TSOP44,.46,32
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE
power supply	5 V
Certification status	Not Qualified
Maximum standby current	0.0001 A
Maximum slew rate	0.07 mA
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	DUAL
