Permanent damage may occur if any of these limits are exceeded.
Applications
Coaxial Connections
RF REF (RF2)
RF IN (RF1)
DC OUT (I)
1
3
2
• monitoring circuits
• leveling circuits
• PLL
FREQUENCY
(MHz)
RF1
RF2
I
DC-50
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Phase Detector Electrical Specifications
SCALE
FACTOR
IMPEDANCE
(ohms)
Output
Load
I
500
POWER
IN
RF1
RF2
(dBm)
7
ISOLATION
(dB)
RF1/RF2
Min.
40
OUTPUT
POLARITY
RF1/RF2
In-Phase
neg.
DC OUTPUT
(mV)
Max.
Typ.
1000
Min.
700
Offset
Typ.
0.2
Max.
1
FIGURE
OF
MERIT
mV/deg.
8
Typ.
143
Outline Drawing
1-100
DC output decreases to 550mV over 1-10 MHz as temperature decreases to -55°C
Typical Performance Data
Frequency
(MHz)
DC Output
mV
—
X
1.00
5.00
8.07
10.00
15.14
20.00
22.21
29.29
36.36
40.00
43.43
50.50
57.57
60.00
64.64
71.71
78.79
85.86
92.93
100.00
ZRPD-1
DC OUTPUT
DC Offset
mV
—
X
0.10
0.11
0.11
0.10
0.11
0.11
0.10
0.11
0.11
0.12
0.12
0.14
0.15
0.15
0.15
0.17
0.18
0.17
0.18
0.23
σ
0.16
0.18
0.18
0.18
0.19
0.19
0.20
0.21
0.22
0.23
0.23
0.25
0.27
0.26
0.27
0.31
0.31
0.31
0.38
0.43
ZRPD-1
DC OFFSET
RF1-RF2 Isolation
(dB)
—
X
76.12
75.09
74.07
73.19
70.19
68.10
67.28
65.14
63.29
62.38
61.76
60.51
59.35
59.18
58.73
57.82
57.35
57.15
56.93
56.36
σ
14.85
8.90
14.44
14.61
17.01
18.91
20.52
22.55
24.77
25.39
26.41
25.99
28.69
33.08
38.60
45.18
51.83
57.31
60.65
74.27
Outline Dimensions (
inch
)
mm
A
2.25
57.15
J
3.25
82.55
B
1.38
35.05
K
.10
2.54
C
1.24
31.50
L
.40
10.16
D
.50
12.70
M
1.15
29.21
E
.150
3.81
N
1.86
47.24
F
3.100
78.74
P
.64
16.26
G
.138
3.51
H
1.238
31.45
S
wt
.150 grams
3.81
74.0
-500
DC OUTPUT (mV)
-600
-700
-800
-900
-1000
0
-769.98
-830.34
-840.24
-843.71
-851.12
-859.20
-861.26
-872.02
-881.57
-886.86
-889.93
-917.82
-927.50
-917.14
-920.62
-925.22
-928.03
-932.34
-932.98
-909.17
at RF/LO power = 7 dBm
0.25
DC OFFSET (mV)
0.20
0.15
0.10
0.05
0.00
20
40
60
FREQUENCY (MHz)
80
100
at RF/LO power = 7 dBm
0
20
40
60
80
100
FREQUENCY (MHz)
ZRPD-1
RF1-RF2 ISOLATION
90
RF1-RF2 ISOLATION
(dB)
80
70
60
50
40
at RF/LO power = 7 dBm
electrical schematic
0
20
40
60
80
100
FREQUENCY (MHz)
Mini-Circuits
TM
®
minicircuits.com
ISO 9001 ISO 14001
AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
