BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BA-4G3Y3E1UI
●
1.
2.
3.
4.
5.
6.
Features :
Emitting area : 5.1×1.78×10（mm）
Low power requirement.
Excellent characters appearance.
Solid state reliability.
Categorized for luminous intensity.
Universal pin out.
●
Package Dimensions :
5.1(.200)
1.78(.070)
E
E
E
Y
Y
Y
G
G
G
G
2.54(.100)
25.30(.996)
2.54(.100)
0.5(.020)
●
1.
2.
Description :
The BA-4G3Y3E1UI is 10 bar graph
array display.
This product use green chips and yellow
chips and hi-eff red chips, the green
chips are made from GaP on GaP,
substrate, the yellow chips are made
from GaAsP on GaP substrate, the
hi-eff red chips are made from GaAsP on
GaP substrate.
0.25(.010)
10.16(.400)
8.0(.315)
3.0(.120) MIN.
7.62(.300)
3.
4.
This product have a gray face and
white segments.
This product doesn't contain restriction
substance, comply ROHS standard.
Notes:
1. All dimensions are in millimeters(inches).
2. Tolerance is ±0.25mm(.01")unless otherwise
specified.
3. Specifications are subject to change without
notice.
●
Internal Circuit Diagram :
Ver.1.0 Page 1 of 4
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BA-4G3Y3E1UI
●
Absolute Maximum Ratings(Ta=25℃)
Parameter
Power Dissipation Per Segment
Forward Current Per Segment
Peak Forward Current Per Segment
Reverse Voltage Per Segment
Operating Temperature
Storage Temperature
Soldering Temperature
(1/16" From Body)
Symbol
Pd
I
F
I
FP
(Duty 1/10, 1KHZ)
V
R
Topr
Tstg
Tsol
Green Yellow
Rating Rating
80
30
150
80
30
150
5
Hi-eff Red
Rating
80
30
150
Unit
mW
mA
mA
V
-
-
-
-40℃~80℃
-40℃~85℃
260℃ For 5 Seconds
●
Electrical And Optical Characteristics(Ta=25℃)
Green
Parameter
Forward Voltage Per Segment
Luminous Intensity Per Segment
Reverse Current Per Segment
Peak Wave Length
Dominant Wave Length
Spectral Line Half-width
Symbol Condition
Vf
Iv
I
R
λp
λd
∆λ
I
F
=10mA
I
F
=10mA
V
R
=5V
I
F
=10mA
I
F
=10mA
I
F
=10mA
Min.
-
-
-
-
569
-
Typ.
2.1
5.0
-
568
-
30
Max.
2.5
-
100
-
574
-
Unit
V
mcd
µA
nm
nm
nm
Ver.1.0 Page 2 of 4
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BA-4G3Y3E1UI
Yellow
Parameter
Forward Voltage Per Segment
Luminous Intensity Per Segment
Reverse Current Per Segment
Peak Wave Length
Dominant Wave Length
Spectral Line Half-width
Symbol Condition
Vf
Iv
I
R
λp
λd
∆λ
I
F
=10mA
I
F
=10mA
V
R
=5V
I
F
=10mA
I
F
=10mA
I
F
=10mA
Min.
-
-
-
-
587
-
Typ.
2.0
4.5
-
585
-
35
Max.
2.5
-
100
-
594
-
Unit
V
mcd
µA
nm
nm
nm
Hi-eff Red
Parameter
Forward Voltage Per Segment
Luminous Intensity Per Segment
Reverse Current Per Segment
Peak Wave Length
Dominant Wave Length
Spectral Line Half-width
Symbol Condition
Vf
Iv
I
R
λp
λd
∆λ
I
F
=10mA
I
F
=10mA
V
R
=5V
I
F
=10mA
I
F
=10mA
I
F
=10mA
Min.
-
-
-
-
626
-
Typ.
1.9
5.0
-
640
-
40
Max.
2.5
-
100
-
636
-
Unit
V
mcd
µA
nm
nm
nm
Ver.1.0 Page 3 of 4
BRIGHT LED ELECTRONICS CORP.
SINCE 1981
BA-4G3Y3E1UI
●
Typical Electro-Optical Characteristics Curves
(25℃ Ambient Temperature Unless Otherwise Noted)
1.0
Fig.1 Relative Radiant Intensity VS. Wavelength
(E)
(G)
(Y)
Relative Radiant Intensity
0.5
0
530
560
590
Wavelength(nm)
620
650
680
710
(E)
(Y)
(G)
Relative Luminous Intensity
(@20mA)
3
4
5
50
Fig.2 Forward Current VS.
Forward Voltage
3.0
2.5
2.0
1.5
1.0
0.5
Fig.3 Relative Luminous
Intensity VS.
Ambient Temperature
Forward Current (mA)
40
30
20
10
0
1
2
Forward Voltage (V)
Fig.4 Relative Luminous
Intensity VS.
Forward Current
(Y)
0
-40
Ambient Temperature Ta( C)
Fig.5 Forward Current
Derating Curve VS.
Ambient Temperature
-20
0
20
40
60
Relative Luminous Intensity
(@20mA)
3.0
50
40
30
20
10
0
2.0
(G)
(E)
1.0
0.0
Forward Current(mA)
0
10
20
30
40
50
Forward Current(mA)
Ambient Temperature Ta( C)
20
40
60
80
100 120
Ver.1.0 Page 4 of 4
