216432-8 Product Details
Live Product Chat
Product View
Eurocard Type C
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
216432-8
T E I nternal N umber: 2 1 6 4 3 2 - 8
Product Highlights:
l
Type C C onnectors
l
Plug
l
Number of Positions = 64
l
Rows Loaded = A, C
l
Terminate To Printed C ircuit Board
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
64 POS. DIN 41612 TYPE C MALE C ONN. WITH AC TION-PIN ...
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Type C C onnectors
l
Gender
= Plug
l
Number of Positions
= 64
l
PC B Retention Feature
= Yes
l
PC B Mount Angle
= Right Angle
l
PC B Thickness (Minimum) (mm [in])
= 1.57 [0.062]
l
Post Type
= C ompliant Post
l
Size
= Standard
l
Make First / Break Last
= No
l
DIN Level
= III
l
Mounting Ears
= Without
l
Toolless (Flat Rock) = Yes
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.90 [0.114]
Body Related Features:
l
Rows Loaded
= A, C
l
PC B Retention Method
= AC TION PIN (C ompliant) Posts
l
C ontact C ross Section (mm [in])
= 0.64 [.025] Sq.
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
Flux-Tight C oating
= Without
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
l
High Temperature Housing
= No
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Additional Product Images:
l
Recommended PC Board Hole Pattern
