2-353948-0 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 2-353948-0

2-353948-0: DescriptionCONNECTOR, 20 CONTACT(S), FEMALE, RIGHT ANGLE FFC/FPC CONNECTOR, SURFACE MOUNT; CategoryThe connector The connector; File Size105KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

2-353948-0 Overview

CONNECTOR, 20 CONTACT(S), FEMALE, RIGHT ANGLE FFC/FPC CONNECTOR, SURFACE MOUNT

2-353948-0 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
Other features	LOW PROFILE
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	TIN LEAD
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	0.5 mm
Termination type	SURFACE MOUNT
Total number of contacts	20
UL Flammability Code	94V-0
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Ribbon, SATA/SAS/Mini-SAS & Flat Flex Wire C onnectors

Product Feature Selector

> Product Details

2-353948-0 Product Details

Live Product Chat

Product View

FPC (Flexible Printed Circuit) Connectors

Not re vie we d for R oHS C om plia nce

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

2-353948-0

T E I nternal N umber: 2 - 3 5 3 9 4 8 - 0

Product Highlights:

.50 mm C enterline

Number of Positions = 20

PC B Mount Angle = Right Angle

PC B Mount Style = Surface Mount

C ontact Type = Bottom

View all Features

Obsolete

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

0.5mm Pitch FPC C onnector, ZIF (H) SMT Type 1.2mm Height

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Number of Positions

= 20

PC B Mount Angle

= Right Angle

PC B Mount Style

= Surface Mount

Profile = Standard

Solder Tab Material = Phosphor Bronze

Body Related Features:

C enterline (mm [in])

= 0.50 [0.0197]

Contact Related Features:

C ontact Type

= Bottom

C ontact Base Material = Phosphor Bronze

C ontact Mating Area Plating Material = Tin-Lead

Housing Related Features:

Housing Flammability Rating = UL 94V-0

Housing Material = Thermoplastic

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Packaging Related Features:

Packaging Method = Tape Mounted

Other:

Brand = AMP

Additional Information:

Product Line Information
