SMT POWER INDUCTORS
Toroid - Polecat Series
Height:
5.5mm Max
Footprint:
12.7mm x 12.7mm Max
Current Rating:
up to 8.3A
Inductance Range:
2.0µH to 364µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
11
Part
Number
P0174NL
P0175NL
P0176NL
P0174NL
P0177NL
P0175NL
P0178NL
P0179NL
P0176NL
P0180NL
P0177NL
P0181NL
P0178NL
P0182NL
P0179NL
P0183NL
P0180NL
P0181NL
P0182NL
P0183NL
9,10
Inductance
@ Irated
(µH MIN)
2.0
2.4
5.0
7.0
9.3
8.4
14.1
19.8
17.9
29.3
33.8
42.6
50.9
61.3
71.5
84.2
106.1
154.2
218.9
295.0
Irated
(A)
8.30
7.20
5.20
4.16
3.80
3.78
3.10
2.60
2.60
2.20
1.89
1.80
1.54
1.50
1.30
1.20
1.07
0.89
0.74
0.64
DCR (MAX)
(mΩ)
7.6
10.9
19.0
32.0
29.8
43.6
45.3
66.3
76.0
106
120
151
182
224
266
324
404
604
888
1272
ET
(V-µsec)
7.31
7.81
11.72
14.61
16.12
15.62
19.73
23.45
23.43
28.50
32.25
34.49
39.46
40.85
46.90
46.22
57.00
68.99
81.70
92.43
Inductance
@0A
DC
(µH ±10%)
2.2
2.6
5.5
8.75
10.4
10.4
15.7
22.1
22.45
32.8
41.7
47.6
62.8
67.5
88.2
91.0
131.0
190.3
270.2
364.0
100 Gauss
ET
100
(V-µsec)
1.20
1.33
1.93
2.41
2.65
2.65
3.25
3.86
3.86
4.70
5.30
5.66
6.51
6.75
7.71
7.83
9.40
11.33
13.50
15.66
1 Amp DC
H
1
(Orsted)
5.43
5.97
8.69
10.86
11.95
11.95
14.66
17.38
17.38
21.18
23.89
25.52
29.32
30.41
34.75
35.30
42.36
51.05
60.82
70.59
Connection
Parallel
Parallel
Parallel
Series
Parallel
Series
Parallel
Parallel
Series
Parallel
Series
Parallel
Series
Parallel
Series
Parallel
Series
Series
Series
Series
NOTES:
1. Temperature rise is 50°C in typical buck or boost circuits at 250kHz and with the
reference ET applied to the inductor.
2. Total loss in the inductor is 380mW for a 50°C temperature rise above ambient.
3. To estimate temperature rise in a given application, determine copper and core
losses, divide by 380 and multiply by 50.
4. For the copper loss (mW), calculate I
DC
2
X R
N
.
5. For core loss (mW), using frequency (f in Hertz) and operating flux density (B in
Gauss), calculate 6.11 x 10
-18
x B
2.7
x f
2.04
.
6. For flux density (B in Gauss), calculate ET (V-µsec) for the application, divide by
ET
100
from the table, and multiply by 100.
7. Limit the DC bias (H) to 46 orsteds. Calculate H by multiplying H
1
from the table
by I
DC
of the application.
8. The maximum DCR listed is approximately 17% over the nominal DCR.
9. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to
the part number (i.e. P0174NL becomes P0174NLT). Pulse complies to industry
standard tape and reel specification EIA481.
10. The "NL" suffix indicates an RoHS-compliant part number. Non-NL suffixed parts are
not necessarily RoHS compliant, but are electrically and mechanically equivalent to
NL versions. If a part number does not have the "NL" suffix, but an RoHS compliant
version is required, please contact Pulse for availability.
11. The temperature of the component (ambient plus temperature rise) must be within
the stated operating temperature range.
Mechanical
.500 MAX
12,70
.330
8,38
R
Schematic
1
4
2
.500 MAX
12,70
1
P01XX
Date Code
Country of Origin
4X .060
1,52
4X .175
4,45
2
.410
10,41
3
1:1 ±2%
3
4
Suggested Pad Layout
Weight
. . . . . . . . 1.5 grams
Tape & Reel
. . . . . . 500/reel
Tube
. . . . . . . . . . . .
35/tube
.215 MAX
5,46
.005/0,13
4 SURFACES
.330
8,38
.410
10,41
Dimensions:
Inches
mm
Unless otherwise specified,
all tolerances are ± .010
0,25
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
72
SPM2007 (11/07)
