ICS85310AYI-21 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> ICS85310AYI-21

ICS85310AYI-21: DescriptionLow Skew Clock Driver, 85310 Series, 5 True Output(s), 0 Inverted Output(s), PQFP32, 7 X 7 MM, 1.40 MM HEIGHT, MS-026BBA, LQFP-32; Categorylogic logic; File Size130KB，12 Pages; ManufacturerIDT (Integrated Device Technology)

Download Datasheet Parametric Compare View All

ICS85310AYI-21 Overview

Low Skew Clock Driver, 85310 Series, 5 True Output(s), 0 Inverted Output(s), PQFP32, 7 X 7 MM, 1.40 MM HEIGHT, MS-026BBA, LQFP-32

ICS85310AYI-21 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	IDT (Integrated Device Technology)
Parts packaging code	QFP
package instruction	LQFP, QFP32,.35SQ,32
Contacts	32
Reach Compliance Code	not_compliant
Other features	ECL MODE: VCC = 0V WITH VEE = -2.375V TO -3.8V
series	85310
Input adjustment	DIFFERENTIAL
JESD-30 code	S-PQFP-G32
JESD-609 code	e0
length	7 mm
Logic integrated circuit type	LOW SKEW CLOCK DRIVER
Humidity sensitivity level	3
Number of functions	2
Number of inverted outputs
Number of terminals	32
Actual output times	5
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	LQFP
Encapsulate equivalent code	QFP32,.35SQ,32
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE
Peak Reflow Temperature (Celsius)	240
power supply	3.3 V
Prop。Delay @ Nom-Sup	2.2 ns
propagation delay (tpd)	2.2 ns
Certification status	Not Qualified
Same Edge Skew-Max（tskwd）	0.05 ns
Maximum seat height	1.6 mm
Maximum supply voltage (Vsup)	3.8 V
Minimum supply voltage (Vsup)	2.375 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn85Pb15)
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	20
width	7 mm

Preview

Download Datasheet

View All

Integrated

Circuit

Systems, Inc.

ICS85310I-21

KEW

, D

UAL

, 1-

-5

IFFERENTIAL

-2.5V/3.3V ECL/LVPECL F

ANOUT

UFFER

EATURES

•

2 differential 2.5V/3.3V LVPECL / ECL bank outputs

•

2 differential clock input pairs

•

CLKx, nCLKx pairs can accept the following differential

input levels: LVDS, LVPECL, LVHSTL, SSTL, HCSL

•

Maximum output frequency: 700MHz

•

Translates any single ended input signal to 3.3V

LVPECL levels with resistor bias on nCLKx input

•

Output skew: 25ps (typical)

•

Part-to-part skew: 270ps (typical)

•

Propagation delay: 1.7ns (typical)

•

LVPECL mode operating voltage supply range:

= 2.375V to 3.8V, V

= 0V

•

ECL mode operating voltage supply range:

= 0V, V

= -2.375V to -3.8V

•

-40°C to 85°C ambient operating temperature

•

Pin compatible with MC100LVEP210

ENERAL

ESCRIPTION

The ICS85310I-21 is a low skew, high perfor-

mance dual 1-to- 5 Differential-to-2.5V/3.3V

HiPerClockS™

ECL/LVPECL Fanout Buffer and a member of

the HiPerClockS™ family of High Performance

Clock Solutions from ICS. The CLKx, nCLKx pairs

can accept most standard differential input levels.

The ICS85310I-21 is characterized to operate from either a

2.5V or a 3.3V power supply. Guaranteed output and part-

to-part skew characteristics make the ICS85310I-21 ideal

for those clock distribution applications demanding well

defined performance and repeatability.

,&6

LOCK

IAGRAM

CLKA

nCLKA

QA0

nQA0

QA1

nQA1

QA2

nQA2

QA3

nQA3

QA4

nQA4

SSIGNMENT

nQA0

nQA1

nQA2

32 31 30 29 28 27 26 25

CLKA

nCLKA

CLKB

9 10 11 12 13 14 15 16

CCO

nQB4

QB4

nQB3

QB3

nQB2

QB2

CCO

ICS85310I-21

QA0

QA1

QA2

QA3

nQA3

QA4

nQA4

QB0

nQB0

QB1

nQB1

CLKB

nCLKB

QB0

nQB0

QB1

nQB1

QB2

nQB2

QB3

nQB3

QB4

nQB4

nCLKB

32-Lead LQFP

7mm x 7mm x 1.4mm package body

Y Package

Top View

85310AYI-21

www.icst.com/products/hiperclocks.html

REV. B OCTOBER 23, 2002
