227835-1 Product Details
Live Product Chat
Product Photo
TNC RF Connectors
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
227835-1
T E I nternal N umber: 2 2 7 8 3 5 - 1
Product Highlights:
l
C onnector
l
Jack
l
Terminate To Printed C ircuit Board
l
Body Style = Straight
l
C onnector Impedance = 50 ?
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
RF C OAXIAL SOLUTIONS FOR C OMMUNIC ATIONS
(PDF, English)
l
RF C OAX PRODUC TS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Jack
l
Body Style
= Straight
l
PC B Mount Angle
= Vertical
l
PC B Retention Feature
= Yes
l
Body Material
= Metal
l
Solder Terminal
= Without
l
Panel Thickness (mm [in]) = 6.10 [0.240]
l
Mounting Posts = With
l
Dielectric Material = Polymethylpentene
Mechanical Attachment:
l
Panel Attachment
= With
l
Panel Attachment Method = Lockwasher and Nut
Electrical Characteristics:
l
C onnector Impedance (?)
= 50
Body Related Features:
l
Body Plating
= Nickel
Contact Related Features:
l
C enter C ontact Plating = Gold
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
