2-327175-2 Product Details
Live Product Chat
Product View
Ring and Spade Tongue Terminals
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
2-327175-2
T E I nternal N umber: 2 - 3 2 7 1 7 5 - 2
Product Highlights:
l
Terminal Shape = Ring Tongue
l
Receptacle Style = Straight
l
Body Style = SOLISTRAND
l
Barrel Type = C losed Barrel
l
Wire/C able Type = Regular Wire
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
TERMINAL, RING TONGUE,SOLISTRAND ZTM
(PDF, English)
Catalog Pages/Data Sheets:
l
SOLISTRAND BUDGET AND DIAMOND GRIP UNINSULATED TERMI...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version H)
l
3D Model
(IGES, Version H)
l
3D Model
(STEP, Version H)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Terminal Shape
= Ring Tongue
l
Receptacle Style
= Straight
l
Body Style
= SOLISTRAND
l
Barrel Type
= C losed Barrel
l
Wire/C able Type
= Regular Wire
l
Insulation
= No
l
Insulation Support
= Non-Insulation Support
l
Stud Size = 1/2 [M12]
l
Stud Diameter (mm [in])
= 12.70 [0.500]
l
Shape
= RING-049
l
Heavy Duty
= No
l
Material
= C opper
l
Finish
= Tin
Body Related Features:
l
Wire Range (mm [AWG])
= 21.00² [4]
l
Wire Range (C MA) = 33,100 – 52,600
l
Barrel I.D. Min. (mm [in]) = 7.52 [0.296]
l
Stock Thickness (mm [in]) = 1.85 [0.073]
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Packaging Related Features:
l
Packaging Method = Box
l
Packaging Quantity = 500/Box
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
