198 PHR-SI
Vishay
Aluminum Capacitors
Power High Ripple Current Snap-in
FEATURES
•
Polarized aluminum electrolytic capacitors,
non-solid electrolyte
•
Large types, miniaturized dimensions,
cylindrical aluminum case, insulated with
a blue sleeve
•
Very high ripple current capability
•
Keyed polarity version available
•
Lead (Pb)-free versions are RoHS compliant.
Fig.1 Component outlines.
Pb-free
Available
RoHS*
COMPLIANT
APPLICATIONS
157
PUM-SI
057
PSM-SI
smaller
dimensions
198
PHR-SI
longer life
higher ripple
•
•
•
•
Motor control and industrial systems
Smoothing and filtering
Standard and switched mode power supplies
Energy storage in pulse systems.
QUICK REFERENCE DATA
DESCRIPTION
Nominal case size (∅D
×
L in mm)
Rated capacitance range
(E6/E12 series), C
R
Tolerance on C
R
Rated voltage range, U
R
Category temperature range
Endurance test at 85
°C
Useful life at 85
°C
Shelf life at 0 V, 85
°C
Based on sectional specification
Climatic category IEC 60068
VALUE
22
×
25 to 35
×
60
56 to 680
µF
±
20 %
400 and 450 V
−
25 to + 85
°C
7000 hours
15000 hours
1000 hours
IEC 60384-4/EN130300
25/085/56
MARKING
The capacitors are marked (where possible)
with the following information:
•
Rated capacitance (in
µF).
•
Tolerance code on rated capacitance, code letter in
accordance with IEC 60062 (M for
±
20 %).
•
Rated voltage (in V).
•
Date code (YYMM).
•
Name of manufacturer.
•
Code for factory of origin.
•
‘−’ sign to identify the negative terminal, visible from the top
and side of the capacitor.
•
Code number.
•
Climatic category in accordance with IEC 60068.
SELECTION CHART FOR C
R
, U
R
AND RELEVANT NOMINAL CASE SIZES
(∅D x L in mm)
C
R
(µF)
56
68
82
100
120
150
180
220
270
330
390
470
560
680
U
R
(V)
400
22
×
25
22
×
25
−
−
22
×
30
−
22
×
35
25
×
30
−
22
×
40
25
×
35
25
×
40
30
×
30
35
×
25
25
×
45
30
×
35
35
×
30
30
×
40
35
×
30
30
×
45
35
×
35
30
×
50
35
×
40
35
×
45
35
×
50
35
×
60
450
22
×
25
22
×
30
22
×
30
25
×
25
22
×
35
25
×
30
22
×
40
25
×
30
30
×
25
25
×
40
30
×
30
25
×
40
30
×
35
35
×
25
25
×
50
30
×
40
35
×
30
30
×
45
35
×
35
30
×
50
35
×
40
35
×
45
−
35
×
50
35
×
60
35
×
60
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 28339
Revision: 28-Oct-05
For technical questions contact: aluminumcaps2@vishay.com
www.vishay.com
49
198 PHR-SI
Vishay
Aluminum Capacitors
Power High Ripple Current
DIMENSIONS
in millimeters
AND AVAILABLE FORMS
TWO TERMINAL SNAP-IN
∅D
+
TERMINAL
L
−
TERMINAL
L
+
2 max.
10
±0.1
Bottom view
+0
5.8 -1 mm
∅2 ±0.1
(2×)
The minus terminal can be marked with a black dot or with an
Fig. 2 Two terminal snap-in.
Fig. 3 Mounting hole diagram.
THREE TERMINAL SNAP-IN
∅2 ±0.1
(2×)
∅D
∅2.5 ±0.1
+
TERMINAL
L
−
TERMINAL
minus pole
marking
Bottom view
L
+
2 max.
3.3
±0.1
4
±0.5
10
±0.1
4.75
±0.1
The negative terminal has
TWO
pins which are
BOTH
The 10 mm spacing of the 2 pin snap-in is used as the
base layout and a third hole is added.
The third hole is closer to the negative primary hole so
Fig. 4 Three terminal snap-in.
Fig. 5 Mounting hole diagram.
www.vishay.com
50
For technical questions contact: aluminumcaps2@vishay.com
Document Number: 28339
Revision: 28-Oct-05
Aluminum Capacitors
Power High Ripple Current
Table 1
198 PHR-SI
Vishay
DIMENSIONS
in millimeters,
MASS AND PACKAGING QUANTITIES
NOMINAL
CASE SIZE
∅D ×
L
(mm)
22
×
25
22
×
30
22
×
35
22
×
40
25
×
25
25
×
30
25
×
35
25
×
40
25
×
45
25
×
50
30
×
25
30
×
30
30
×
35
30
×
40
30
×
45
30
×
50
35
×
25
35
×
30
35
×
35
35
×
40
35
×
45
35
×
50
35
×
60
∅D
max
23
23
23
23
26
26
26
26
26
26
31
31
31
31
31
31
36
36
36
36
36
36
36
L
max
27
32
37
42
27
32
37
42
47
52
27
32
37
42
47
52
27
32
37
42
47
52
62
MASS
(g)
≈12
≈16
≈20
≈23
≈20
≈22
≈24
≈27
≈32
≈38
≈25
≈30
≈35
≈40
≈45
≈50
≈33
≈40
≈48
≈55
≈63
≈72
≈87
PACKAGING QUANTITIES
(units per box)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
50
50
50
50
50
50
50
CARDBOARD BOX DIMENSIONS
L
×
W
×
H
260
×
250
×
39
260
×
250
×
44
260
×
250
×
49
260
×
250
×
54
290
×
280
×
39
290
×
280
×
44
290
×
280
×
49
290
×
280
×
54
290
×
280
×
59
290
×
280
×
64
340
×
330
×
39
340
×
330
×
44
340
×
330
×
49
340
×
330
×
54
340
×
330
×
59
340
×
330
×
64
390
×
198
×
39
390
×
198
×
44
390
×
198
×
49
390
×
198
×
54
390
×
198
×
59
390
×
198
×
64
390
×
198
×
74
ELECTRICAL DATA
SYMBOL
C
R
I
R
I
L1
I
L5
ESR
Z
Note
1. Unless otherwise specified, all electrical values in Table 2 apply
at T
amb
= 20
°C,
P = 86 to 106 kPa, RH = 45 to 75 %.
Table 2
DESCRIPTION
rated capacitance at 100 Hz
rated RMS ripple current at 100 Hz, 85
°C
max. leakage current after 1 minute at U
R
max. leakage current after 5 minutes at U
R
typ./max. equivalent series resistance at 100 Hz
typ./max. impedance at 10 kHz
ORDERING EXAMPLE*
Electrolytic capacitor 198 PHR-SI
470
µF/450
V;
±
20 %
Nominal case size:
∅35 ×
50 mm
2-terminal snap-in:
Catalog number: 2222 198 57471.
3-terminal snap-in:
Catalog number: 2222 198 77471.
* Note: To ensure delivery of lead (Pb)-free parts during the
transition period, please contact your Vishay sales agent.
ELECTRICAL DATA AND ORDERING INFORMATION
U
R
(V)
400
C
R
100 Hz
(µF)
56
68
100
120
120
150
NOMINAL
CASE SIZE
∅D ×
L
(mm)
22
×
25
22
×
25
22
×
30
22
×
35
25
×
30
22
×
40
I
R
100 Hz
85
°C
(A)
0.72
0.79
1.00
1.14
1.14
1.33
I
L1
1 min
(µA)
138
167
244
292
292
364
I
L5
5 min
(µA)
49
59
84
100
100
124
TYP.
ESR
100 Hz
(mΩ)
918
762
520
433
438
348
MAX.
ESR
100 Hz
(mΩ)
1706
1405
956
796
796
637
TYP. Z
10 kHz
(mΩ)
521
434
297
247
252
199
MAX. Z
10 kHz
(mΩ)
1085
905
610
450
450
363
CATALOG
NUMBER
2222 198 .....
2-TERM.
56569
56689
56101
46121
36121
66151
3-TERM.
76569
76689
76101
26121
16121
86151
Document Number: 28339
Revision: 28-Oct-05
For technical questions contact: aluminumcaps2@vishay.com
www.vishay.com
51
