K9F2816Q0C-BIB0 datasheet, PDF

Datasheet> All Categories > storage> storage> K9F2816Q0C-BIB0

K9F2816Q0C-BIB0: DescriptionFlash, 8MX16, 30ns, PBGA48, 6 X 8.50 MM, 0.80 MM PITCH, TBGA-48; Categorystorage storage; File Size691KB，33 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/

Download Datasheet Parametric Compare View All

K9F2816Q0C-BIB0 Overview

Flash, 8MX16, 30ns, PBGA48, 6 X 8.50 MM, 0.80 MM PITCH, TBGA-48

K9F2816Q0C-BIB0 Parametric

Parameter Name	Attribute value
Maker	SAMSUNG
Parts packaging code	BGA
package instruction	6 X 8.50 MM, 0.80 MM PITCH, TBGA-48
Contacts	48
Reach Compliance Code	compliant
ECCN code	3A991.B.1.A
Maximum access time	30 ns
Other features	CONTAINS ADDITIONAL 4M BIT NAND FLASH
JESD-30 code	R-PBGA-B48
length	8.5 mm
memory density	134217728 bit
Memory IC Type	FLASH
memory width	16
Number of functions	1
Number of terminals	48
word count	8388608 words
character code	8000000
Operating mode	ASYNCHRONOUS
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
organize	8MX16
Package body material	PLASTIC/EPOXY
encapsulated code	VFBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Parallel/Serial	PARALLEL
Programming voltage	1.8 V
Certification status	Not Qualified
Maximum seat height	1 mm
Maximum supply voltage (Vsup)	1.95 V
Minimum supply voltage (Vsup)	1.65 V
Nominal supply voltage (Vsup)	1.8 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	BALL
Terminal pitch	0.8 mm
Terminal location	BOTTOM
type	SLC NAND TYPE
width	6 mm

Preview

Download Datasheet

View All
