AN8803SB/NSB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Consumption circuit> AN8803SB/NSB

AN8803SB/NSB: DescriptionAudio Preamplifier, 1 Channel(s), 1 Func, Bipolar, PDSO36, 0.450 INCH, PLASTIC, SSOP-36; CategoryAnalog mixed-signal IC Consumption circuit; File Size347KB，8 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html

Download Datasheet Parametric Compare View All

AN8803SB/NSB Overview

Audio Preamplifier, 1 Channel(s), 1 Func, Bipolar, PDSO36, 0.450 INCH, PLASTIC, SSOP-36

AN8803SB/NSB Parametric

Parameter Name	Attribute value
Maker	Panasonic
Parts packaging code	SSOP
package instruction	SSOP,
Contacts	36
Reach Compliance Code	unknown
ECCN code	EAR99
Commercial integrated circuit types	AUDIO PREAMPLIFIER
JESD-30 code	R-PDSO-G36
length	15.2 mm
Number of channels	1
Number of functions	1
Number of terminals	36
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Certification status	Not Qualified
Maximum seat height	3.25 mm
Maximum supply voltage (Vsup)	5 V
Minimum supply voltage (Vsup)	5 V
surface mount	YES
technology	BIPOLAR
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	DUAL
width	8.4 mm

Preview

Download Datasheet

View All

AN8803SB/NSB Related Products

	AN8803SB/NSB	MN6625	AN7030S	AN7097SB	MN66181	AN8802SC	AN7035SC	AN8800SC	AN7036FHP	MN6471
Description	Audio Preamplifier, 1 Channel(s), 1 Func, Bipolar, PDSO36, 0.450 INCH, PLASTIC, SSOP-36	Consumer Circuit, CMOS, PQFP64, 18 X 18 MM, PLASTIC, QFP-64	Audio Preamplifier, 1 Channel(s), 1 Func, Bipolar, PDSO42, 0.450 INCH, PLASTIC, SSOP-42	Audio Amplifier, 2 Channel(s), 1 Func, Bipolar, PDSO28, 0.375 INCH, PLASTIC, SSOP-28	Digital Filter, CMOS, PQFP42, 14 X 14 MM, PLASTIC, QFP-42	Audio Preamplifier, 1 Channel(s), 1 Func, Bipolar, PDSO32, 0.375 INCH, PLASTIC, SSOP-32	Consumer Circuit, Bipolar, PDSO32, 0.375 INCH, PLASTIC, SSOP-32	Audio Preamplifier, 1 Channel(s), 1 Func, Bipolar, PDSO42, 0.450 INCH, PLASTIC, SSOP-42	Consumer Circuit, Bipolar, PQFP48, 7 X 7 MM, PLASTIC, QFH-48	D/A Converter, 1 Func, PQFP40, 14 X 14 MM, PLASTIC, QFP-40
Maker	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic	Panasonic
Parts packaging code	SSOP	QFP	SSOP	SSOP	QFP	SSOP	SSOP	SSOP	QFP	QFP
package instruction	SSOP,	QFP,	SSOP,	SSOP,	QFP,	SSOP,	SSOP,	SSOP,	FQFP,	QFP, QFP44,.8SQ,50
Contacts	36	64	42	28	42	32	32	42	48	40
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown
JESD-30 code	R-PDSO-G36	S-PQFP-G64	R-PDSO-G42	R-PDSO-G28	S-PQFP-G42	R-PDSO-G32	R-PDSO-G32	R-PDSO-G42	S-PQFP-G48	S-PQFP-G40
length	15.2 mm	18 mm	21.25 mm	11.6 mm	14 mm	17.81 mm	17.91 mm	21.25 mm	7 mm	14 mm
Number of terminals	36	64	42	28	42	32	32	42	48	40
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SSOP	QFP	SSOP	SSOP	QFP	SSOP	SSOP	SSOP	FQFP	QFP
Package shape	RECTANGULAR	SQUARE	RECTANGULAR	RECTANGULAR	SQUARE	RECTANGULAR	RECTANGULAR	RECTANGULAR	SQUARE	SQUARE
Package form	SMALL OUTLINE, SHRINK PITCH	FLATPACK	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	FLATPACK	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH	FLATPACK, FINE PITCH	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	3.25 mm	2.9 mm	2.4 mm	2.4 mm	2.6 mm	2.4 mm	2.4 mm	2.4 mm	2.9 mm	2.6 mm
surface mount	YES	YES	YES	YES	YES	YES	YES	YES	YES	YES
technology	BIPOLAR	CMOS	BIPOLAR	BIPOLAR	CMOS	BIPOLAR	BIPOLAR	BIPOLAR	BIPOLAR	CMOS
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.8 mm	1 mm	1 mm	0.8 mm	1.27 mm	1 mm	1 mm	1 mm	0.5 mm	1.27 mm
Terminal location	DUAL	QUAD	DUAL	DUAL	QUAD	DUAL	DUAL	DUAL	QUAD	QUAD
width	8.4 mm	18 mm	9.5 mm	7.2 mm	14 mm	7.2 mm	7.2 mm	9.5 mm	7 mm	14 mm
Commercial integrated circuit types	AUDIO PREAMPLIFIER	CONSUMER CIRCUIT	AUDIO PREAMPLIFIER	AUDIO AMPLIFIER	-	AUDIO PREAMPLIFIER	CONSUMER CIRCUIT	AUDIO PREAMPLIFIER	CONSUMER CIRCUIT	-
Number of functions	1	1	1	1	-	1	1	1	1	1
Maximum supply voltage (Vsup)	5 V	5.5 V	5.5 V	6 V	-	5 V	5.5 V	5 V	6 V	-
Minimum supply voltage (Vsup)	5 V	4 V	4.5 V	3 V	-	5 V	4.5 V	5 V	3 V	-
