MURH805CT-BP datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> MURH805CT-BP

Preview

MURH805CT-BP: DescriptionRectifier Diode, 1 Phase, 2 Element, 8A, 50V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN; CategoryDiscrete semiconductor diode; File Size696KB，3 Pages; ManufacturerMicro Commercial Components (MCC); Environmental Compliance

Download Datasheet Parametric Compare View All

MURH805CT-BP Overview

Rectifier Diode, 1 Phase, 2 Element, 8A, 50V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN

MURH805CT-BP Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Micro Commercial Components (MCC)
Parts packaging code	TO-220AB
package instruction	TO-220AB, 3 PIN
Contacts	3
Reach Compliance Code	not_compliant
ECCN code	EAR99
application	EFFICIENCY
Shell connection	CATHODE
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	65 A
Number of components	2
Phase	1
Number of terminals	3
Maximum output current	8 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	50 V
Maximum reverse recovery time	0.035 µs
surface mount	NO
Terminal surface	Matte Tin (Sn)
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

MCC

TM

Micro Commercial Components

omponents

20736 Marilla Street Chatsworth

!"#

$ % !"#

Features

•

MURH805CT

THRU

MURH860CT

8 Amp Super Fast

Glass Passivated

Rectifier

50 to 600 Volts

Superfast switching time for hight efficiency

Low reverse leakage current

High surge capacity

Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates

RoHS Compliant. See ordering information)

Case Material: Molded Plastic. UL Flammability

Classification Rating 94V-0

and MSL Rating 1

Maximum Ratings

•

Operating Temperature: -55°C to +150°C

Storage Temperature: -55°C to +150°C

F

TO-220AB

B

C

S

Q

T

A

U

1 2

3

MCC

Catalog

Number

Device

Marking

MURH805CT

MURH810CT

MURH820CT

MURH840CT

MURH860CT

MURH805CT

MURH810CT

MURH820CT

MURH840CT

MURH860CT

Maximum

Recurrent

Peak

Reverse

Voltage

50V

100V

200V

400V

600V

Maximum

RMS

Voltage

Maximum

DC

Blocking

Voltage

50V

100V

200V

400V

600V

35V

70V

140V

280V

420V

H

K

Electrical Characteristics @ 25°C Unless Otherwise Specified

Average Forward

Current

Peak Forward Surge

Current

Maximum Forward

Voltage Drop Per

Element

Maximum DC

Reverse Current At

Rated DC Blocking

Voltage

Maximum Reverse

Recovery Time

MURH805-820CT

MURH840-860CT

L

G

N

PIN 1

PIN 3

V

D

J

R

I

F(AV)

I

FSM

8.0A

65A

T

C

= 120°C

8.3ms, half sine

PIN 2

CASE

V

F

2.2 V

2.8 V

I

R

10 uA

800 uA

MURH805-840CT

MURH860CT

I

FM

= 4 A per

element;

T

A

= 25°C*

T

J

= 25°C

T

J

= 100°C

I

F

=1.0A,

di/dt=50A/uS

DIM

A

B

C

D

F

G

H

J

K

L

N

Q

R

S

T

U

V

DIMENSIONS

INCHES

MM

MIN

MAX

MIN

MAX

.560

.625

14.22

15.88

.380

.420

9.65

10.67

.140

.190

3.56

4.82

.020

.139

.190

---

.012

.500

.045

.190

.100

.080

.045

.230

-----

.045

.161

.110

.250

.025

.580

.060

.210

.135

.115

.055

.270

.050

-----

0.51

3.53

2.29

---

0.30

12.70

1.14

4.83

2.54

2.04

1.14

5.84

-----

1.15

1.14

4.09

2.79

6.35

0.64

14.73

1.52

5.33

3.43

2.92

1.39

6.86

1.27

-----

NOTE

∅

T

rr

35ns

50ns

*Pulse test: Pulse width 300

µsec,

Duty cycle 2%

Revision: 5

www.mccsemi.com

1 of 3

2008/01/01

MURH805CT-BP Related Products

	MURH805CT-BP	MURH860CT-BP	MURH820CT-BP	MURH840CT-BP	MURH810CT-BP
Description	Rectifier Diode, 1 Phase, 2 Element, 8A, 50V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN	Rectifier Diode, 1 Phase, 2 Element, 8A, 600V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN	Rectifier Diode, 1 Phase, 2 Element, 8A, 200V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN	Rectifier Diode, 1 Phase, 2 Element, 8A, 400V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN	Rectifier Diode, 1 Phase, 2 Element, 8A, 100V V(RRM), Silicon, TO-220AB, TO-220AB, 3 PIN
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to
Parts packaging code	TO-220AB	TO-220AB	TO-220AB	TO-220AB	TO-220AB
package instruction	TO-220AB, 3 PIN	TO-220AB, 3 PIN	TO-220AB, 3 PIN	TO-220AB, 3 PIN	TO-220AB, 3 PIN
Contacts	3	3	3	3	3
Reach Compliance Code	not_compliant	compliant	not_compliant	not_compliant	not_compliant
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99
application	EFFICIENCY	EFFICIENCY	EFFICIENCY	EFFICIENCY	EFFICIENCY
Shell connection	CATHODE	CATHODE	CATHODE	CATHODE	CATHODE
Configuration	COMMON CATHODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JEDEC-95 code	TO-220AB	TO-220AB	TO-220AB	TO-220AB	TO-220AB
JESD-30 code	R-PSFM-T3	R-PSFM-T3	R-PSFM-T3	R-PSFM-T3	R-PSFM-T3
JESD-609 code	e3	e3	e3	e3	e3
Humidity sensitivity level	1	1	1	1	1
Maximum non-repetitive peak forward current	65 A	65 A	65 A	65 A	65 A
Number of components	2	2	2	2	2
Phase	1	1	1	1	1
Number of terminals	3	3	3	3	3
Maximum output current	8 A	8 A	8 A	8 A	8 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	50 V	600 V	200 V	400 V	100 V
Maximum reverse recovery time	0.035 µs	0.05 µs	0.035 µs	0.05 µs	0.035 µs
surface mount	NO	NO	NO	NO	NO
Terminal surface	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)	Matte Tin (Sn)
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal location	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Maker	Micro Commercial Components (MCC)	-	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)	Micro Commercial Components (MCC)
