REVISION AA
DO NOT
SCALE FROM
THIS PRINT
HFWJ-XX-XX-XX-X-XX-X
No OF POSITIONS
-01 THRU -24
OPTION
-P: PICK & PLACE PAD
(USE PPP-47, SEE FIG 2)
(-VS ONLY, 3 POSITION MIN)
OPTION
-RA: RIGHT ANGLE (POST)
(N/A WITH -VS OPTION)
-VS: VERTICAL SURFACE MOUNT
(N/A ON -01 POSITION)
ROW SPECIFICATION
-S: SINGLE (USE HFWJ-24-156)
LEAD STYLES 01, 02, 04 & 05
IN-PROCESS
-VS
IN-PROCESS
-RA
LEAD STYLE
SEE TABLE 1
C3
((No OF POS) x .156[3.96]) .010[.25]
((No OF POS -1) x .156[3.96]) .010[.25]
.078 1.97
PLATING SPECIFICATION
-T: TIN (USE T-1S8-XX-T)
-TM: MATTE TIN
(USE T-1S8-XX-T)
.125 3.18
24
HFWJ-24-156
BODY
01
.250 6.35 REF
NOTES:
1. MAX PIN ROTATION IN BODY : 2 DEGREES
2. MINIMUM PUSHOUT FORCE: .5 LB.
3. BURR ALLOWANCE: .0015 MAX.
4. STANDARD & -RA PARTS TO BE BULK PACKAGED.
5. SURFACE MOUNT (-VS) TO BE PACKAGED AS FOLLOWS:
POSITIONS -04 THRU -20 TO BE TUBE PACKAGED.
POSITIONS -02 & -03 TO BE LAYER PACKAGED.
6. MAXIMUM CUT FLASH: .020.
7. MAX HEIGHT VARIATION BETWEEN PINS: .005[.13]
8. POSITIONS -02 THRU -16 TO BE .008[.20]
POSITIONS -17 THRU -24 TO BE .010[.25]
9.
C
REPRESENTS A CRITICAL DIMENSION.
10. -01 POSITION PARTS TO BE BULK PACKAGED.
11. BANDOLIER AREA ON T-1S8 MUST NOT BE ENTIRELY LOCATED
IN THE CONTACT AREA. POSITION ABOUT OR TOWARDS
STANDOFF SIDE OF BODY.
12. BANDOLIER AREA MUST NOT BE LOCATED
IN CONTACT AREA.
"F"
"B"
"E" REF
.045 1.14 SQ. REF
CONTACT AREA
2 MAX SWAY
(EITHER DIRECTION)
90°
90°
+5°
- 0°
"F" .005[.13]
C2
"C"
"B"
(SEE NOTE 1 & 11)
.125 3.18 REF
"A" REF
STANDOFF
PACKAGING VIEW
FIG. 2
-P: PICK & PLACE PAD OPTION
(-VS ONLY, 3 POS. MIN)
C1
SEE NOTE 8
.225 5.72
"D" REF
(SEE NOTE 12)
CONTACT
AREA
.040 1.02 REF
"R"
"S"
"G"
REF
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.300 7.62
REF
.450 11.43
REF
01
NOTE:
"R" = No OF POS x .156[3.96] REF
"S" = {("R" - .450[11.43]) / 2} .020[12.90]
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
INSULATOR: VECTRA E130i, COLOR: NATURAL
CONTACT OR TERMINAL: PHOS BRONZE, 510
.156[3.96] PWER BLOCK ASSEMBLY
TUBE: PT-1-24-01-26
PLUG: TP-25
(SEE NOTE 5)
MAX FLASH ALLOWED: .002
MAX GATE VESTIGE: .002
F:\DWG\MISC\MKTG\HFWJ-XX-XX-XX-X-XX-X-MKT.SLDDRW
HFWJ-XX-XX-XX-X-XX-X
06/06/2002
SHEET
1
OF
1
BY:
T.WERNE
