Power Inductors - Shielded
ctparts.com
CTIHLP125F Series
From .10 µH to 2.7 µH
Part
Number
CTIHLP125F-R10M
CTIHLP125F-R20M
CTIHLP125F-R22M
CTIHLP125F-R27M
CTIHLP125F-R30M
CTIHLP125F-R33M
CTIHLP125F-R36M
CTIHLP125F-R47M
CTIHLP125F-R50M
CTIHLP125F-R56M
CTIHLP125F-R68M
CTIHLP125F-R82M
CTIHLP125F-1R0M
CTIHLP125F-1R2M
CTIHLP125F-1R5M
CTIHLP125F-1R7M
CTIHLP125F-2R0M
CTIHLP125F-2R2M
CTIHLP125F-2R7M
Not shown at actual size.
SPECIFICATIONS
Parts are only available ±20% inductance tolerance only
*Irms DC current (A) will cause an approximately
ΔT
of 40°C.
**Isat DC current (A) will cause L0 to drop approximately 20%.
L Test
Freq.
(KHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
*Irms
Typ.
(A)
40
35
35
35
30
30
30
30
30
28
35
25
22
22
16
16
14
16
14
**Isat
Typ.
(A)
75
45
50
40
70
70
70
40
40
35
35
32
24
28
16
16
16
14
14
DCR
Max.
Ω
(mΩ)
0.50
0.65
0.65
0.65
1.20
1.20
1.20
1.20
1.20
1.30
1.40
1.50
2.50
2.50
3.30
4.00
5.00
4.50
4.70
Inductance
(µH)
0.10
0.20
0.22
0.27
0.30
0.33
0.36
0.47
0.50
0.56
0.68
0.82
1.00
1.20
1.50
1.70
2.00
2.20
2.70
Compliant
RoHS
PHYSICAL DIMENSIONS
Size
A
Max.
12.9
0.50
B
Max.
13.8
0.54
C
Max.
5.0
0.20
D
Typ.
3.7
0.14
CHARACTERISTICS
Description:
SMD (shielded) power inductor
Applications:
High density DC/DC converters. POL converters.
High current VRM/VRD for notebooks, Servers, and desktop
CPUs. High speed chargers.
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±20%
Testing:
Inductance is tested on an HP4285A at 100KHz, 0.5V
Packaging:
Tape & Reel
Marking:
Parts are marked with inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
mm
inches
B
A
XXX
C
Marking: Inductance Code
D
RECOMMENDED LAND PATTERN
Unit: mm
3.5
5.0
11.5
03.06.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
