PCB terminal block - SMKDS 1/ 2-3,5 BD:1-2 - 1724365
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB terminal block, nominal current: 10 A, nom. voltage: 200 V, pitch: 3.5 mm, number of positions: 2,
connection method: Screw connection with tension sleeve, mounting: Wave soldering, conductor/PCB
connection direction: 35 °, color: green
The figure shows a 10-position
version of the product
Your advantages
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Angled connection enables multi-row arrangement on the PCB
Extremely small design for the respective conductor cross section
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
4046356126328
85369010
1
Technical data
Dimensions
Length [ l ]
Pitch
Dimension a
Width [ w ]
Height
Height [ h ]
Solder pin [P]
Hole diameter
10 mm
3.5 mm
3.5 mm
7.5 mm
9.5 mm
13 mm
3.5 mm
1.1 mm
General
01/15/2019 Page 1 / 4
https://www.phoenixcontact.com/in/products/1724365
PCB terminal block - SMKDS 1/ 2-3,5 BD:1-2 - 1724365
Technical data
General
Range of articles
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Nominal cross section
Stripping length
Number of positions
Screw thread
Tightening torque, min
Tightening torque max
SMKDS 1
2.5 kV
2.5 kV
2.5 kV
160 V
200 V
400 V
EN-VDE
10 A
1 mm²
5 mm
2
M2
0.22 Nm
0.25 Nm
Connection data
Conductor cross section AWG min.
Conductor cross section AWG max.
2 conductors with same cross section, solid min.
2 conductors with same cross section, solid max.
2 conductors with same cross section, stranded min.
2 conductors with same cross section, stranded max.
26
16
0.14 mm²
0.5 mm²
0.14 mm²
0.2 mm²
Standards and Regulations
Connection in acc. with standard
EN-VDE
CSA
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
27141109
27141109
27141190
27261100
27261100
01/15/2019 Page 2 / 4
https://www.phoenixcontact.com/in/products/1724365
PCB terminal block - SMKDS 1/ 2-3,5 BD:1-2 - 1724365
Classifications
eCl@ss
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
27440401
27440401
27440401
ETIM
ETIM 3.0
ETIM 4.0
ETIM 5.0
ETIM 6.0
EC001121
EC002643
EC002643
EC002643
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211801
39121432
39121432
39121432
39121432
Approvals
Approvals
Approvals
CSA / IECEE CB Scheme / SEV / EAC / cULus Recognized
Ex Approvals
Approval details
CSA
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
D
300 V
10 A
28-16
http://www.csagroup.org/services-industries/product-listing/
B
150 V
10 A
28-16
13631
01/15/2019 Page 3 / 4
https://www.phoenixcontact.com/in/products/1724365
PCB terminal block - SMKDS 1/ 2-3,5 BD:1-2 - 1724365
Approvals
IECEE CB Scheme
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://www.iecee.org/
CH-8225
125 V
12 A
1.5
SEV
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
https://www.electrosuisse.ch/de/meta/shop/produktezertifikate.html
125 V
12 A
1.5
IK-3542-M1
EAC
D
300 V
10 A
30-16
B.01742
cULus Recognized
Nominal voltage UN
Nominal current IN
mm²/AWG/kcmil
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-19770427
B
300 V
10 A
30-16
Phoenix Contact 2019 © - all rights reserved
http://www.phoenixcontact.com
01/15/2019 Page 4 / 4
