BX80528KL150GA/SL4ZT: DescriptionRISC Microprocessor, 32-Bit, 1500MHz, PPGA603; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，116 Pages; ManufacturerIntel; Websitehttp://www.intel.com/

Download Datasheet Parametric Compare View All

BX80528KL150GA/SL4ZT Overview

RISC Microprocessor, 32-Bit, 1500MHz, PPGA603

BX80528KL150GA/SL4ZT Parametric

Parameter Name	Attribute value
Maker	Intel
package instruction	SPGA, PGA603,25X31,50
Reach Compliance Code	unknown
bit size	32
JESD-30 code	R-PPGA-P603
Number of terminals	603
Package body material	PLASTIC/EPOXY
encapsulated code	SPGA
Encapsulate equivalent code	PGA603,25X31,50
Package shape	RECTANGULAR
Package form	GRID ARRAY, SHRINK PITCH
power supply	1.6 V
Certification status	Not Qualified
speed	1500 MHz
Maximum slew rate	44200 mA
Nominal supply voltage	1.6 V
surface mount	NO
Terminal form	PIN/PEG
Terminal pitch	1.27 mm
Terminal location	PERPENDICULAR
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR, RISC

BX80528KL150GA/SL4ZT Preview

Intel

Xeon

™

Processor

at 1.40 GHz, 1.50 GHz, 1.70 GHz and 2 GHz

Datasheet

Product Features

Available at 1.40, 1.50, 1.70 and 2 GHz

Dual processing server/workstation support

Binary compatible with applications

running on previous members of the Intel

microprocessor line

Intel

NetBurst™ micro-architecture

System bus frequency at 400 MHz

— Bandwidth up to 3.2 Gbytes/sec

Rapid Execution Engine: Arithmetic Logic

Units (ALUs) run at twice the processor

core frequency

Hyper Pipelined Technology

Advance Dynamic Execution

— Very deep out-of-order execution

— Enhanced branch prediction

Level 1 Execution Trace Cache stores 12 K

micro-ops and removes decoder latency

from main execution loops

— Includes 8 KB Level 1 data cache

256 KB Advanced Transfer Cache (on-die,

full speed Level 2 (L2) cache) with 8-way

associativity and Error Correcting Code

(ECC)

Enables system support of up to 64 GB of

physical memory

144 new Streaming SIMD Extensions 2

(SSE2) instructions

Enhanced floating point and multimedia

unit for enhanced video, audio, encryption,

and 3D performance

Power Management capabilities

— System Management mode

— Multiple low-power states

Advanced System Management Features

— Processor Information ROM (PIROM)

— OEM Scratch EEPROM

— Machine Check Architecture (MCA)

The Intel

Xeon™ processor is designed for high-performance workstation and server

applications. Based on the new Intel

NetBurst™ micro-architecture, it is binary compatible

with previous Intel Architecture processors. The Intel Xeon processor is scalable to two

processors in a multiprocessor system providing exceptional performance for applications

running on advanced operating systems such as Windows* XP, Windows 2000 and UNIX*. The

Intel Xeon processor extends the power of the Intel

Pentium

III

Xeon™ processor with new

features designed to make this processor the right choice for powerful workstation, advanced

servers, and mission-critical applications. Advanced features simplify system management and

meet the needs of a robust IT environment, resulting in maximized system up time, convenient

system management, and optimal configuration.

Order Number: 249665-002

September 2001

Information in this document is provided in connection with Intel

products. No license, express or implied, by estoppel or otherwise, to any intellectual

property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability

whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to

fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right. Intel products are not

intended for use in medical, life saving, or life sustaining applications.

Intel may make changes to specifications and product descriptions at any time, without notice.

Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel reserves these for

future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future changes to them.

The Intel

Xeon processor may contain design defects or errors known as errata which may cause the product to deviate from published

specifications. Current characterized errata are available on request.

Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.

Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained by calling

1-800-548-4725 or by visiting Intel's website at http://www.intel.com.

Intel, Pentium, Pentium III Xeon, Intel Xeon and Intel NetBurst are trademark or registered trademarks of Intel Corporation or its subsidiaries in the

United States and other countries.

* Other names and brands may be claimed as the property of others.

Datasheet
