2006 POWER INDUCTORS
High Reliability Power Inductors
ML322PZA
■
High temperature materials allow operation in ambient
temperatures up to 155°C
■
Lowest profile, ultra-miniature, shielded power inductor
■
Soft saturation makes them ideal for VRM/VRD applications.
■
Special construction allows it to pass vibration testing to
80 G and shock testing to 1000 G.
Terminations
Tin-silver over copper
Core material
Composite
Weight
12 – 13 mg
Ambient temperature
–55°C to +105°C with
Irms
current, +105°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Tape and reel packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000/7″reel; 7500/13″ reel
Plastic tape: 8 mm wide, 0.28 mm thick, 4 mm pocket spacing,
0.76 mm pocket depth
Inductance
2
±20% (µH)
1.0
2.2
3.3
4.7
5.6
6.8
8.2
10.0
15.0
22.0
33.0
47.0
56.0
68.0
82.0
100.0
DCR (Ohms)
3
typ
max
0.153
0.169
0.278
0.306
0.460
0.506
0.665
0.732
0.75
0.825
0.92
1.02
1.08
1.19
1.27
1.40
2.02
2.22
2.78
3.06
4.45
4.90
5.60
6.16
6.65
7.32
8.50
9.35
9.25
10.18
11.10
12.25
SRF (MHz)
4
min
typ
136
170
88
110
70
88
54
68
49
61
45
57
41
51
36
45
29.6
37
24.4
30.5
19.2
24.0
15.6
19.5
13.2
16.5
12.8
16.0
10.8
13.5
10.4
13.0
Isat
(A)
5
10% drop 20% drop 30% drop
0.71
1.0
1.2
0.49
0.69
0.78
0.42
0.56
0.66
0.31
0.44
0.52
0.30
0.43
0.50
0.26
0.35
0.41
0.24
0.33
0.39
0.24
0.31
0.37
0.19
0.25
0.29
0.150
0.205
0.240
0.110
0.150
0.180
0.090
0.130
0.155
0.085
0.120
0.145
0.080
0.115
0.135
0.065
0.090
0.115
0.065
0.090
0.115
Irms
(A)
6
20°C rise 40°C rise
0.910
1.22
0.710
0.950
0.550
0.720
0.500
0.660
0.460
0.600
0.400
0.520
0.370
0.490
0.345
0.440
0.265
0.350
0.235
0.305
0.160
0.205
0.155
0.205
0.145
0.195
0.115
0.155
0.125
0.165
0.100
0.135
Part number
1
ML322PZA102MLZ
ML322PZA222MLZ
ML322PZA332MLZ
ML322PZA472MLZ
ML322PZA562MLZ
ML322PZA682MLZ
ML322PZA822MLZ
ML322PZA103MLZ
ML322PZA153MLZ
ML322PZA223MLZ
ML322PZA333MLZ
ML322PZA473MLZ
ML322PZA563MLZ
ML322PZA683MLZ
ML322PZA823MLZ
ML322PZA104MLZ
1. When ordering, please specify
testing
code:
ML322PZA222MLZ
Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10004
C
= Custom screening (please specify when ordering)
2. Inductance tested at 100 kHz, 0.1 Vrms, 0 Adc.
3. DCR measured on a micro-ohmmeter.
4. SRF measured using Agilent/HP 4395A or equivalent.
5. Typical dc current at which the inductance drops the specified amount from its value without current.
6. Typical current that causes the specified temperature rise from 25°C ambient.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Testing:
®
Specifications subject to change without notice.
Please check our website for latest information.
Document ML763-1
Revised 01/07/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2012
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
